搅拌针转速对厚板镁合金SSFSW焊缝组织及性能的影响

王大伟, 杨新岐, 唐文珅, 田超博, 徐永生

王大伟, 杨新岐, 唐文珅, 田超博, 徐永生. 搅拌针转速对厚板镁合金SSFSW焊缝组织及性能的影响[J]. 焊接学报, 2023, 44(1): 8-19. DOI: 10.12073/j.hjxb.20220123002
引用本文: 王大伟, 杨新岐, 唐文珅, 田超博, 徐永生. 搅拌针转速对厚板镁合金SSFSW焊缝组织及性能的影响[J]. 焊接学报, 2023, 44(1): 8-19. DOI: 10.12073/j.hjxb.20220123002
WANG Dawei, YANG Xinqi, TANG Wenshen, TIAN Chaobo, XU Yongsheng. Effect of pin rotational speed on microstructure and properties of SSFSW weld for thick-plate magnesium alloy[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2023, 44(1): 8-19. DOI: 10.12073/j.hjxb.20220123002
Citation: WANG Dawei, YANG Xinqi, TANG Wenshen, TIAN Chaobo, XU Yongsheng. Effect of pin rotational speed on microstructure and properties of SSFSW weld for thick-plate magnesium alloy[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2023, 44(1): 8-19. DOI: 10.12073/j.hjxb.20220123002

搅拌针转速对厚板镁合金SSFSW焊缝组织及性能的影响

基金项目: 国家自然科学基金资助项目(51775371)
详细信息
    作者简介:

    王大伟,硕士研究生,主要研究方向为静止轴肩搅拌摩擦焊. Email: dwWang@tju.edu.cn

    通讯作者:

    杨新岐,教授,博士,主要研究方向为固相摩擦焊接技术及焊接结构完整性评定. Email: xqyang@tju.edu.cn.

  • 中图分类号: TG 453.9

Effect of pin rotational speed on microstructure and properties of SSFSW weld for thick-plate magnesium alloy

  • 摘要: 对9 mm厚板AZ31B镁合金进行静止轴肩搅拌摩擦焊(stationary shoulder friction stir welding,SSFSW)工艺试验,探讨搅拌针转速(500 ~ 1000 r/min)对焊缝组织及力学性能的影响规律. 结果表明,在给定焊接速度80 mm/min下,搅拌针转速在600 ~ 800 r/min范围可获得表面光滑、无内部缺陷的对接焊缝,当转速为1 000 r/min时焊缝表面出现不连续凹坑但内部仍无缺陷. 随着转速增加,晶粒尺寸由(11.11 ± 1.68) μm增加到(18.95 ± 1.83) μm;在700 r/min时焊核区晶粒尺寸沿板厚差异最小. 焊缝中间硬度分布具有不均匀性且随转速增加而减小,最大差异为10.97 HV,最低硬度47 HV位于前进侧的热力影响区与焊核区界面处. 在700 r/min下接头力学性能最佳,强度系数为90.2%、对应断后伸长率为母材69.3%. 随着转速增加,断裂模式由韧-脆混合断裂转变为剪切-韧性混合断裂.
    Abstract: The thick-plates of AZ31B magnesium alloy with 9 mm thickness were joined successfully by stationary shoulder friction stir welding (SSFSW) to explore the influence of stirring needle speed (500 – 1000 r/min) on the microstructure and mechanical properties of weld. The results show that the butt weld with smooth surface and no internal defects can be obtained at the rotation speed of 600 − 800 r/min under the given welding speed of 80 mm/min. When the rotation speed is 1000 r/min, discontinuous pits appear on the surface but there are still no defects in the weld. With the increase of rotating speed, the grain size increase from (11.11 ± 1.68) μm to (18.95 ± 1.83) μm. At 700 r/min, the grain size difference in the nugget zone is the smallest along the plate thickness. The inhomogeneity of hardness distribution in the WNZ decreases with the increase of rotational speed. The maximum difference of hardness in the middle of the plate thickness is 10.97 HV, and the minimum hardness is 47 HV at the interface between the heat affected zone and the nugget zone of the advancing side. The joint has the best mechanical properties at 700 r/min, the strength coefficient is 90.2% and the corresponding elongation is 69.3% of the BM. With the increase of rotational speed, the fracture mode changes from ductile-brittle mixed fracture to shear-ductile mixed fracture.
  • 目前,国内开发的船用高强钢焊条及焊剂,其熔渣的设计通常采用CaO-SiO2-CaF2基础渣系或与其相近的渣系类型[1]. 在长期的工程应用中发现,当焊条或焊剂更换原材料批次时,其性能有时会产生较大波动,导致焊接材料的工艺性能或力学性能不能满足工程要求. 产生上述问题的根本原因是原材料批次改变,熔渣关键组元含量发生细微变化,熔化特性发生改变,进而直接影响焊接材料的工艺性能和焊接质量的好坏[2-4]. TiO2 和Al2O3为高强钢焊接材料渣系的关键组元,探明其对渣系黏度、熔化温度、表面张力等熔化特性的影响规律,对改善焊接材料性能、指导焊接材料配方设计等工作具有重要意义.

    国内外关于渣系的研究主要集中在冶金领域,关于焊接渣系的研究较少. 在组元对熔渣熔化特性影响研究方面,Ju等人[5]研究了电渣重熔中TiO2对低氟CaF2-CaO-Al2O3-MgO-Li2O渣黏度和结构的影响,认为渣系黏度随着TiO2 的增加而降低,但达到一定温度后,TiO2 的加入对降低黏度影响较小. Tuset等人[6]也认为无论化学成分如何变化,当炉渣完全熔化后,黏度不再受温度升高影响. 张平等人[7]采用FactSage软件利用热力学模拟的方法同样证明了该结论的正确性. 在渣系熔化温度研究中,邓永春等人[8]以La2O3-SiO2-Al2O3为基础渣系,采用半球法对设定区域的熔化温度进行了研究,认为SiO2/Al2O3质量比为2时,渣系的熔化温度最低. 在渣系结构研究方面,李生平等人[9]采用XRD及激光拉曼光谱对高钛渣结构进行了初步表征,并对SiO2,CaO和MgO含量变化引起的熔渣结构变化原因进行了分析解释,对组元含量、物理性能及结构间影响关系研究具有一定的参考意义. 在焊接领域,李海新等人[10]重点研究了水下湿法焊接中TiO2 的加入量对焊接熔渣形貌及组织微观结构的影响,认为当药皮中TiO2加入量较大时,熔渣致密松脆,熔渣微观组织中存在粗大的灰白色条状相,有利于熔渣脱渣,能够改善焊接材料工艺性.

    某690 MPa强度级别焊条渣化学成分见表1. 基于该渣成分进行四元焊接熔渣试样的制备,试剂均为分析纯,其纯度和熔点[1]表2. 由XRF分析所得的试验前后四元渣的化学成分及变化见表3.

    表  1  690 MPa强度级别焊条渣系主要化学成分(质量分数,%)
    Table  1.  Main chemical compositions of 690 MPa strength grade electrode slag
    CaOSiO2CaF2TiO2Al2O3MnONa2OFe2O3MgO
    46.5325.7211.275.143.522.523.071.630.60
    下载: 导出CSV
    | 显示表格
    表  2  试验所用化学试剂
    Table  2.  Chemical reagent in present experiment
    试剂纯度 (质量分数,%)熔点T/℃
    CaO98.02 940
    SiO299.81 713
    CaF299.51 418
    TiO299.01 825
    Al2O399.02 050
    下载: 导出CSV
    | 显示表格
    表  3  试验前后焊接渣系的化学成分
    Table  3.  Chemical compositions of welding slag before and after experiment
    试样序号试验前成分 (质量分数,%)试验后成分 (质量分数,%)
    CaOSiO2CaF2TiO2Al2O3CaOSiO2CaF2TiO2Al2O3
    1542818058.2426.2315.530
    2532718257.1925.0415.871.90
    3522618456.8824.1415.363.62
    4512518655.7022.9015.955.45
    5502418854.9922.3815.227.41
    6532720057.9823.9418.080
    75226.5201.557.3423.2217.801.64
    8512620356.7622.7817.692.77
    95025.5204.555.2222.3617.914.51
    10492520654.8721.9417.465.73
    下载: 导出CSV
    | 显示表格

    试验中熔渣表面张力采用圆筒(柱)脱离法、黏度采用内圆柱体旋转法进行测量,熔化温度通过读取连续降温黏度曲线上拐点处对应温度值的方法获得,所用的测量设备均为RTW-2010型熔体物性综合测定仪,如图1所示. 该设备可以测量熔体黏度、表面张力、熔化温度、电导率、密度等物理性质,最高测量温度为1 700 ℃. 试验所用测头为钼制,坩埚为高纯石墨坩埚. 采用圆筒脱离法进行熔渣表面张力的测试,测试温度为1 600 ℃恒温,当炉温达到试验温度后保温30 min,使熔渣成分均匀、液面保持稳定,然后进行测定. 表面张力测试完成后,采用内旋转柱体法测量熔渣降温过程中的连续黏度,降温速率为8 ℃/min,试验转速为12 r/min. 并分别对每组高温熔渣淬冷样进行XRF,XRD和拉曼光谱分析.

    图  1  试验设备示意图(mm)
    Figure  1.  Schematic diagram of the experimental equipment

    TiO2对CaO-SiO2-CaF2渣系黏度的影响如图2所示. 由图2可知,对于0 ~ 8%(质量分数)不同TiO2含量的熔渣,其黏度随温度变化趋势基本一致,即随着温度的下降,连续降温黏度曲线上会出现明显的拐点. 当高于拐点温度时,黏度随温度升高无明显变化,黏度值主要集中在0.06 ~ 0.2 Pa·s内. 当低于拐点温度时,黏度随温度下降急剧升高,结晶区间变窄,呈现明显的“短渣”现象(一般将黏度变化数值相同时,相应温度变化范围短的渣称为短渣).

    图  2  CaO-SiO2-CaF2-TiO2四元渣系黏度温度曲线
    Figure  2.  Viscosity-temperature curves of quaternary CaO-SiO2-CaF2-TiO2 slag

    图3可知,TiO2含量与拐点温度存在相关性,随着TiO2含量的增加,拐点温度呈现下降趋势,当TiO2质量分数从0增加至6%时,拐点温度均匀下降,TiO2质量分数每增加2% ,温度下降8 ℃左右;当TiO2质量分数从6%增加到8%时,熔化温度下降显著,约为40 ℃,下降速度达到之前的5倍左右,熔化温度随TiO2含量变化十分敏感,因此,可认为6% ~ 8%的TiO2质量分数范围是熔化温度的“敏感区间”,在焊材配方设计时应予以考虑. 另外,熔化温度随TiO2含量的变化趋势也与氧势理论[1]相符,即TiO2作为酸性氧化物,加入碱性渣中,会使氧势增加,从而黏度下降,熔化温度也随之降低. 通常将熔渣在加热过程中,固体状态的熔渣全部转化为均匀的液体相,或指冷却的过程中,液体状态的熔渣开始析出固体时的温度,定义为熔化温度,因此,拐点温度可表示熔渣的熔化温度[11].

    图  3  熔化温度随TiO2含量的变化曲线
    Figure  3.  Change curve of melt-property temperature with TiO2 content

    TiO2含量对渣系表面张力的影响如图4所示. 随着TiO2含量增加,表面张力呈连续下降趋势,总体位于230 ~ 370 mN/m的区间内, TiO2的质量分数每增加2%,表面张力相对初始渣系表面张力值分别下降了19.4,84.8,87.3和125 mN/m,下降明显,但下降速度有所不同,2% ~ 4%的TiO2质量分数范围是表面张力的“敏感区间”.

    图  4  表面张力随TiO2含量的变化曲线
    Figure  4.  Change curve of surface tension with TiO2 content

    不同TiO2含量对应的熔渣物相的XRD衍射图谱如图5所示. 由图5可知,不同TiO2添加量的衍射峰基本类似,但物相含量及种类发生了一定变化. 当TiO2质量分数为0时,渣中主要物相为Ca4Si2O7F2(枪晶石),Ca2SiO2F2,含有少量CaSiO4和CaSiO3相;当TiO2的质量分数增加到2%及以上时,分别在32°,48°,58°出现了CaTiO3新相,并从衍射峰的强度可以看出,随着TiO2含量的增加,CaTiO3新相含量有增加的趋势,而熔渣主要物相中,Ca4Si2O7F2和Ca2SiO2F2两相含量明显降低,CaSiO4含量显著升高.

    图  5  CaO-SiO2-CaF2-TiO2四元渣系物相分析
    Figure  5.  XRD patterns of quaternary CaO-SiO2-CaF2-TiO2 slag

    上述物相分析结果也解释了熔渣的黏度、熔化温度和表面张力三个熔化特性随TiO2添加量的不同而变化的规律. 在CaO-SiO2-CaF2基础焊接渣系中,SiO2的存在会使熔渣中形成硅酸盐网络结构,从而形成颗粒较大的高熔点稳定化合物,随着TiO2添加量的增加,高熔点的硅酸盐结构Ca4Si2O7F2被破坏,转变成了简单四面体结构的[SiO4] 4−,并生成了熔点较低的CaTiO3新相,从而使熔渣的黏度和熔化温度随之下降. 同样,加入的TiO2会与熔体中的O2−结合,形成静电势较小的复合阴离子氧化物[TiO3]2−,其与阳离子间的键能比O2−与阳离子之间形成的键能小的多,从而降低了熔渣表面张力.

    Al2O3含量对CaO-SiO2-CaF2渣系黏度的影响如图6所示. 由图6可知, Al2O3含量不同,渣系黏度曲线也会出现明显的拐点,但变化趋势有所不同. 高于拐点温度时,渣系黏度曲线变化趋势与TiO2影响一致,黏度随温度升高无明显变化,黏度值主要集中在0.1 ~ 0.2 Pa·s. 当低于拐点温度时,Al2O3的质量分数在4.5% ~ 6%,随着温度降低,黏度迅速增大,熔渣快速结晶,呈现明显的“短渣”现象;当Al2O3的质量分数在0 ~ 3%,渣系黏度从结晶开始,经过较宽的温度区间(约50 ℃)才升高到1 Pa·s以上,中间出现了一段“平台期”,说明增加Al2O3含量可缩短熔渣凝固温度区间.

    图  6  CaO-SiO2-CaF2-Al2O3四元渣系黏度温度曲线
    Figure  6.  Viscosity-temperature curves of quaternary CaO-SiO2-CaF2-Al2O3 slag

    Al2O3含量对渣系拐点温度的影响如图7所示.从图7可知,随着Al2O3含量的增加,拐点温度先略有升高后明显降低,Al2O3质量分数在0 ~ 1.5%时,拐点温度升高了13 ℃;Al2O3质量分数在1.5% ~ 6%时,每增加1.5%,拐点温度都会出现较大幅度下降,相对1.5% Al2O3含量渣系拐点温度值分别下降了27、98和135 ℃,说明在该范围内的Al2O3含量对拐点温度的影响较大,尤其在Al2O3的质量分数为3% ~ 4.5%的范围,是熔化温度的“敏感区间”.

    图  7  熔化温度随Al2O3含量的变化曲线
    Figure  7.  Change curve of melt-property temperature with Al2O3 content

    Al2O3含量对渣系表面张力的影响如图8所示.与对拐点温度的影响类似,随着Al2O3含量的增加,表面张力先略有升高后明显降低,Al2O3质量分数为在0 ~ 1.5%时,表面张力增加了6.8 mN/m;Al2O3质量分数为1.5% ~ 6%时,随Al2O3含量升高,表面张力下降较快,Al2O3质量分数每增加1.5%,相对Al2O3的质量分数为1.5%时表面张力值分别下降了19.1,29.6和48.6 mN/m,从变化趋势来看,在Al2O3质量分数为1.5% ~ 3%和4.5% ~ 6%时,表面张力变化较为敏感.

    图  8  表面张力随Al2O3含量的变化曲线
    Figure  8.  Change curve of surface tension with Al2O3 content

    不同Al2O3含量对应的熔渣物相的XRD衍射图谱如图9所示. 由图9可知,不同Al2O3添加量的衍射峰虽有类似之处,但物相含量及种类发生了一定变化. 当Al2O3质量分数为0时,熔渣主要物相为Ca4Si2O7F2,并含有少量CaSiO4和CaSiO3相;当Al2O3质量分数增加至1.5%时,熔渣主要物相基本不变,但产生了少量的Ca2Al(AlSiO7)新相;当Al2O3质量分数增加到3%及以上时,熔渣的衍射峰强度发生了较为明显的变化,熔渣主要物相Ca4Si2O7F2峰强度下降,含量降低,CaSiO4含量升高,并且除了生成的Ca2Al(AlSiO7)新相之外,还分别在28°和47°处出现了CaF2新相.

    图  9  CaO-SiO2-CaF2-Al2O3四元渣系物相分析
    Figure  9.  XRD patterns of quaternary CaO-SiO2-CaF2-Al2O3 slag

    同样,上述物相测试结果也在一定程度上反映了熔渣熔化特性变化的深层次原因. 在Al2O3添加量为0时,基础渣系中存在大量的高熔点相Ca4Si2O7F2 ,故渣系整体黏度较大、熔化温度较高;当Al2O3质量分数增加至1.5%时,产生的Ca2Al(AlSiO7)新相同样结构复杂,并且从衍射峰强度上看,Ca4Si2O7F2相含量也略有增加,这也解释了当Al2O3质量分数为1.5%时,熔渣熔化温度出现了一定上升的原因;当Al2O3质量分数增加至3%及以上时,Ca4Si2O7F2相含量明显减少,转变成了简单四面体结构的[SiO4] 4−,并产生了低熔点的CaF2相,从而使熔渣熔化温度出现了显著降低.

    Al2O3添加量对表面张力的影响,也可通过物相分析结果来解释. 当渣中加入少量Al2O3时,部分Si—O—Si键转变成了Si—O—Al键,后者键能较高,表面张力较大,故使熔渣表面张力上升;但随着Al2O3含量增加,产生了CaF2新相,由于液态CaF2的表面张力在1 470 ℃以上时仅为280 mN/m,可以显著降低熔渣的表面张力[11].

    采用激光拉曼光谱仪对不同TiO2和Al2O3添加量的熔渣进行全波长范围测试分析,并结合渣系XRD测试结果,共同完成渣系的物相和结构的分析及确定,熔渣拉曼光谱分别如图10图11所示.

    图  10  CaO-SiO2-CaF2-TiO2四元渣系拉曼光谱
    Figure  10.  Raman spectra of quaternary CaO-SiO2-CaF2-TiO2 slag
    图  11  CaO-SiO2-CaF2-Al2O3四元渣系拉曼光谱
    Figure  11.  Raman spectra of quaternary CaO-SiO2-CaF2-Al2O3 slag

    图10表4可知,当质量分数为0 ~ 2%时,熔渣显示出3个Raman活性模式,分别为651.8,908.2和974.8 cm−1,其中,651.8 cm−1处峰是[SiO3]2−中的Si—O0弯曲振动所致,908.2 cm−1处峰是[Si2O7]6−中的Si—O对称伸缩振动所致,974.8 cm−1处峰是[SiO3]2−中的Si—O对称伸缩振动所致. 从上述结果可以看出,在不含或含少量TiO2的情况下,熔渣中以复杂的[Si2O7]6−网络结构为主,含有少量未形成网络的[SiO3]2−. 随着TiO2质量分数增加至4% ~ 8%时,熔渣显示出2个新的特征峰,分别位于840和855 cm−1左右,并且含量逐渐增加,根据文献分析,840 cm−1处峰是Ti—O—Ti伸缩振动所致,855 cm−1处峰是[SiO4]4−中的Si—O对称伸缩振动所致,另外从图10中可看出,[Si2O7]6−中的Si—O键含量逐渐减少. 原因可能是随着TiO2含量增加,生成了CaTiO3新物相,夺取了部分硅酸盐网络结构Ca4Si2O7F2中的Ca2 + ,使网络结构遭到破坏,生成了具有简单四面体结构的[SiO4] 4−.

    表  4  CaO-SiO2-CaF2-TiO2四元渣系拉曼峰分析及其参考依据
    Table  4.  Peak analysis of Raman in the quaternary CaO-SiO2-CaF2-TiO2 slag using established references
    拉曼位移ν/cm−1振动模式参考文献
    ω(TiO2) = 0ω(TiO2) = 2%ω(TiO2) = 4%ω(TiO2) = 6%ω(TiO2) = 8%
    651.8651.8651.8651.8651.8[SiO3]2−中Si—O0弯曲振动[12],[13]
    839.8841.7841.7Ti—O—Ti 伸缩振动[5]
    854.3854.3855.2[SiO4]4− 中Si—O对称伸缩振动[12],[13]
    908.2908.2908.2908.2908.2[Si2O7]6− 中Si—O对称伸缩振动[12],[13]
    973.8974.8974.8973.8972.8[SiO3]2−中Si—O对称伸缩振动[12],[13]
    下载: 导出CSV
    | 显示表格

    图11表5可知,当Al2O3质量分数为0 ~ 1.5%时,熔渣显示出3个Raman活性模式,分别位于651.8,908.2和974.8 cm−1,同样以复杂的[Si2O7]6−网络结构为主;当Al2O3质量分数为3% ~ 6%时,熔渣显示出2个新的特征峰,分别位于842.7和855 cm−1左右,根据文献分析,842.7 cm−1处峰是Si—O —Al伸缩振动所致,855 cm−1处峰是[SiO4]4−中的Si—O对称伸缩振动所致. 分析结果可知,随着Al2O3含量不断增加,渣中含有较多的Al3 + ,容易置换出硅酸盐网络结构中的Si4 + ,生成少量含 Si—O—Al键的Ca2Al(AlSiO7)新相,导致网络结构被破坏,转变为结构简单的[SiO4]4−. 总体来看,TiO2 和Al2O3的加入均会促进复杂的硅酸盐网络结构解聚.

    表  5  CaO-SiO2-CaF2-Al2O3四元渣系拉曼峰分析及其参考依据
    Table  5.  Peak analysis of Raman in the quaternary CaO-SiO2-CaF2-Al2O3 slag using established references
    拉曼位移ν/cm−1振动模式参考文献
    ω(Al2O3) = 0ω(Al2O3) = 1.5%ω(Al2O3) = 3%ω(Al2O3) = 4.5%ω(Al2O3) = 6%
    651.8651.8651.8651.8651.8[SiO3]2−中Si—O0弯曲振动[12],[13]
    842.7842.7842.7Si—O—Al 伸缩振动[14],[15],[16]
    855.2855.2855.2[SiO4]4− 中Si—O对称伸缩振动[12],[13]
    908.2908.2908.2909.2910.2[Si2O7]6− 中Si—O对称伸缩振动[12],[13]
    974.8974.8974.8974.8974.8[SiO3]2−中Si—O对称伸缩振动[12],[13]
    下载: 导出CSV
    | 显示表格

    (1)焊接渣系黏度在降温过程中具有明显的拐点,高于拐点温度,黏度较低且基本保持不变,含TiO2 渣约为0.06 ~ 0.2 Pa·s,含Al2O3渣约为0.1 ~ 0.2 Pa·s. 在拐点附近,黏度随温度降低迅速增大,具有明显的短渣特性.

    (2)随着TiO2含量上升,四元渣系的熔化温度和表面张力均随之下降;随着Al2O3含量上升,四元渣系的熔化温度和表面张力均随之先升高再降低. 并且发现了对熔渣熔化特性影响较大的TiO2和Al2O3含量敏感区间,对高强钢配套焊材配方设计具有一定的参考意义.

    (3)经XRD和拉曼光谱分析可知,四元焊接熔渣中主要含具有硅酸盐网络结构的Ca4Si2O7F2高熔点化合物. TiO2的加入会夺取网络结构中的Ca2+,生成熔点较低的CaTiO3新相,并使复杂的硅酸盐网络结构转变成了简单四面体结构的[SiO4]4−;Al2O3的加入会置换出硅酸盐网络结构中的Si4+,同样使其解聚成简单的[SiO4]4−四面体结构,同时产生少量Ca2Al(AlSiO7)新相和低熔点的CaF2相.

  • 图  1   SSFSW焊接夹具及搅拌工具

    Figure  1.   Fixtures and stir tool of SSFSW

    图  2   SSFSW工艺示意图及试样切割位置

    Figure  2.   Schematic diagram of SSFSW process and cutting positions of specimens

    图  3   焊缝表面和接头截面宏观形貌

    Figure  3.   Weld surface and Macroscopic of cross-sections of SSFSW joints. (a) 500 r/min; (b) 600 r/min; (c) 700 r/min; (d) 800 r/min; (e) 1 000 r/min

    图  4   转速对WNZ尺寸的影响

    Figure  4.   Effect of rotational speed on size of WNZ

    图  5   SSFSW接头典型宏观形貌以及不同区域的显微组织

    Figure  5.   Typical macrostructure of SSFSW joint and microstructure of different areas. (a) Typical macrostructure; (b) BM; (c) top of WNZ; (d) middle of WNZ; (e) bottom of WNZ; (f) AS-TMAZ; (g) RS-TMAZ; (h) AS-HAZ; (i) RS-HAZ.

    图  6   顶部晶粒尺寸

    Figure  6.   The grain size of the top WNZ. (a) 500 r/min; (b) 600 r/min; (c) 700 r/min; (d) 800 r/min; (e) 1 000 r/min

    图  7   中部晶粒尺寸

    Figure  7.   The grain size of the middle WNZ. (a) 500 r/min; (b) 600 r/min; (c) 700 r/min; (d) 800 r/min; (e) 1 000 r/min

    图  8   底部晶粒尺寸

    Figure  8.   The grain size of the bottom WNZ. (a) 500 r/min; (b) 600 r/min; (c) 700 r/min; (d) 800 r/min; (e) 1 000 r/min

    图  9   不同转速下WNZ晶粒尺寸

    Figure  9.   The grain size of WNZ at different rotational speed

    图  10   WNZ晶粒尺寸模型

    Figure  10.   Model of grain size in WNZ

    图  11   700 r/min接头截面显微硬度分布

    Figure  11.   Cross-sectional hardness profiles of joints at 700 r/min

    图  12   不同转速下WNZ硬度值分布

    Figure  12.   Microhardness distributions in WNZ at different rotational speed. (a) Microhardness distributions of the top WNZ; (b) Microhardness distributions of the middle WNZ; (c) Microhardness distributions of the bottom WNZ; (d) Microhardness distributions along WNZ thickness direction

    图  13   WNZ不同位置(0001)极图分布

    Figure  13.   (0001) pole figures in WNZ at different location

    图  14   BM和SSFSW接头的拉伸性能

    Figure  14.   Tensile properties of BM and SSFSW joints. (a) True stress-strain curve; (b) Tensile properties of BM and SSFSW joints

    图  15   BM和接头的硬化能力和硬化指数

    Figure  15.   The Hc and n1 of BM and joints

    图  16   BM和接头的应变硬化行为

    Figure  16.   Strain hardening behavior of BM and joints

    图  17   SSFSW接头失效宏观形貌

    Figure  17.   Macroscopic appearance of failed SSFSW joints

    图  18   断口不同区域SEM图像

    Figure  18.   SEM images of different areas of fracture. (a) 600 r/min; (b) 700 r/min; (c) 800 r/min; (d) 1000 r/min

    表  1   AZ31B化学成分(质量分数,%)

    Table  1   The chemical compositions of AZ31B

    AlZnMnSiFeCuNiCaMg
    3.10.990.38<0.08<0.003<0.01<0.001<0.04余量
    下载: 导出CSV

    表  2   AZ31B物理性能

    Table  2   Physical properties of AZ31B

    抗拉强度Rm/MPa屈服强度Rel/MPa断后伸长率A50(%)熔点T/℃热导率λ/W·(m−1·K−1)硬度H/HV
    256 156 14 650 155 52 ~ 59
    下载: 导出CSV

    表  3   不同转速下WNZ硬度值的平均值和方差

    Table  3   Mean and variance of Microhardness distributions in WNZ at different rotational speed

    转速w/(r·min−1)WNZ顶部 WNZ中部WNZ底部沿WNZ厚度方向
    硬度平均值H/HV方差硬度平均值H/HV方差硬度平均值H/HV方差硬度平均值H/HV方差
    60056.3810.90 54.226.30 52.415.28 57.714.07
    70054.072.5354.6510.9752.935.2460.833.28
    80056.026.9055.119.8253.653.8456.704.08
    1 00056.682.3959.239.0254.653.0059.635.40
    下载: 导出CSV

    表  4   SSFSW接头和BM的拉伸性能

    Table  4   Tensile properties of SSFSW joint and BM

    转速w/(r·min−1)抗拉强度Rm/MPa屈服强度Rel/MPa断后伸长率A(%)强度系数B(%)
    600205885.580.1
    700231969.790.2
    800227949.388.7
    1000227938.988.7
    下载: 导出CSV
