Influence of rare earths, Ga element and their synergistic effects on the microstructure and properties of lead-free solders
-
摘要: 稀土元素和低熔点的Ga元素常作为合金化元素添加到无铅钎料中以提高钎料的综合性能和可靠性,而向无铅钎料中复合添加稀土元素和Ga元素时,二者的协同作用可以进一步改善钎料组织和性能,同时Ga元素可以有效抑制含稀土Nd的无铅钎料中锡须的生长. 对单独添加稀土元素和低熔点元素Ga以及复合添加稀土元素和Ga元素的协同效应对无铅钎料显微组织、润湿性能、熔化特性、力学性能和可靠性的影响进行了综述,介绍了含稀土元素的无铅钎料中锡须产生的机理及影响锡须生长的因素. 最后总结了目前含稀土元素和Ga元素的无铅钎料研究中存在的不足,并展望了未来的研究方向.Abstract: Rare earth (RE) elements and low melting-point Ga elements are often added as alloying elements to lead-free solders to improve the overall performance and reliability of the solder. When RE and Ga elements are added in combination, their synergistic effects can further improve the microstructure and properties of the solder. In particular, Ga element can effectively inhibit the growth of Sn whiskers in lead-free solders containing RE Nd. Therefore, this article reviewed the effects of RE, low melting-point Ga element and their synergistic effects on the microstructure, wettability, melting characteristics, mechanical properties and reliability of lead-free solders. What’s more, the mechanism of Sn whiskers formation in lead-free solders bearing RE and the factors affecting the growth of Sn whiskers were introduced. Finally, the deficiencies in the research of lead-free solder containing RE and Ga elements were summarized, and the future research direction was looked-ahead.
-
Keywords:
- rare earths /
- Ga element /
- synergistic effect /
- microstructure /
- property
-
-
图 15 Au/Ni(P)/Cu焊盘钎焊的焊点在室温、3.1 × 104 A/cm2的电流密度下通电744 h后的SEM图像
Figure 15. Microstructure of solder joint with Au/Ni(P)/Cu after 744 h at room temperature under 3.1 × 104 A/cm2 current. (a) Sn-9Zn solder joint without voids; (b) Sn-9Zn solder joint; (c) Sn-9Zn-0.5Ce solder joint with voids; (d) Sn-9Zn-0.5Ce solder joint
图 17 Sn-9Zn-1Nd和Sn-9Zn-0.5Ga-1Nd钎料组织
Figure 17. Microstructure of Sn-9Zn-1Nd and Sn-9Zn-0.5Ga-1Nd solder after aging treatment. (a) Sn-9Zn-1Nd, 60 h at room temperature; (b) Sn-9Zn-1Nd, 720 h at room temperature; (c) Sn-9Zn-0.5Ga-1Nd, 120 h at room temperature; (d) Sn-9Zn-0.5Ga-1Nd, 1 080 h at room temperature; (e) Sn-9Zn-0.5Ga-1Nd, 3 000 h at room temperature
表 1 不同Ga含量的Sn-3.0Ag-0.5Cu钎料熔化特性
Table 1 Melting characteristic of Sn-3.0Ag-0.5Cu-xGa solders
Ga 含量(%) 固相线Ts/℃ 液相线Tv/℃ 熔化区间∆T/℃ 0 217.8 229.6 11.8 0.5 216.1 227.5 11.4 1.0 215.3 226.4 11.1 1.5 213.7 225.1 11.4 表 2 Sn-Eu相的能谱分析结果
Table 2 EDS result of Sn-Eu phase
元素 质量分数w(%) 原子分数a(%) Sn 66.23 71.52 Eu 33.77 28.48 表 3 Sn-9Zn-xGa钎料的熔化特性
Table 3 Melting characteristic of Sn-9Zn-xGa solders
合金 固液相温度
Tonset/℃液相线温度
Tend/℃熔化区间
Tend−Tonset /℃熔化热
ΔH/(J·g−1)Sn-9Zn 198.3 200.3 +2.0 185.3 Sn-9Zn-0.25Ga 196.7 200.1 +3.4 178.5 Sn-9Zn-0.50Ga 195.8 199.7 +3.9 164.7 Sn-9Zn-0.75Ga 193.1 198.3 +5.2 157.8 Sn-9Zn-1.00Ga 192.1 197.8 +5.7 151.0 表 4 Sn-8.55Zn-0.5Ag-xGa的拉伸性能
Table 4 Tensile properfy of Sn-8.55Zn-0.5Ag-xGa
合金 抗拉强度Rm/MPa 断后伸长率A(%) Sn-8.55Zn-0.5Ag 50 50 Sn-8.55Zn-0.5Ag-1.0Ga 78 37 Sn-8.55Zn-0.5Ag-2.0Ga 108 30 Sn-8.55Zn-0.5Ag-3.0Ga 76 7 -
