选择性阳极键合技术在光栅陀螺中的应用

Application of selective anodic bonding technology in grating gyroscope

  • 摘要: 阳极键合技术广泛应用在晶圆级MEMS器件制造和封装当中,对于有悬臂梁结构器件容易在键合时发生吸合. 采用选择性阳极键合技术防止陀螺在键合中吸合失效. 推导了陀螺梁与玻璃的静电吸合电压公式并建立吸合电压与硅结构-玻璃间隙关系模型. 采用深硅制作陀螺结构,在玻璃基底溅射Al/Cr制作光栅,最后进行阳极键合. 结果表明,键合界面没有缺陷,铬及其氧化物导电抗吸合性使得硅-玻璃阳极键合未发生静电吸合失效现象,对样品进行抗剪强度测试,得出平均键合强度为33.94 MPa,键合质量良好.



    Abstract: Anode bonding technology is widely used in wafer-level MEMS device manufacturing and packaging. For devices with cantilever beam structure, it is easy to attract during bonding. Selective anode bonding technology is used to prevent the gyro from attracting failure during bonding. The formula of electrostatic pull-in voltage between gyro beam and glass was educed, and the relationship model between pull-in voltage and silicon structure glass gap was established. First, the gyroscope structure was made by DRIE, then the grating was made by sputtering Al/Cr on the glass substrate, and finally the anodic bonding was performed. The results showed that the bonding interface has no defects, and the conductivity of Cr and its oxides made the silicon-glass anodic bonding without electrostatic attraction. The average bonding strength was 33.94 MPa, and the bonding quality was good.



/
