Zr67.8Cu24.7Al3.43Ni4.07非晶合金激光焊接晶化控制及组织性能分析

马焰议, 王海燕, 张宇鹏, 易耀勇, 董福宇

马焰议, 王海燕, 张宇鹏, 易耀勇, 董福宇. Zr67.8Cu24.7Al3.43Ni4.07非晶合金激光焊接晶化控制及组织性能分析[J]. 焊接学报, 2019, 40(12): 138-142. DOI: 10.12073/j.hjxb.2019400327
引用本文: 马焰议, 王海燕, 张宇鹏, 易耀勇, 董福宇. Zr67.8Cu24.7Al3.43Ni4.07非晶合金激光焊接晶化控制及组织性能分析[J]. 焊接学报, 2019, 40(12): 138-142. DOI: 10.12073/j.hjxb.2019400327
shu
MA Yanyi, WANG Haiyan, ZHANG Yupeng, YI Yaoyong, DONG Fuyu. Crystallization control and microstructural properties of laser welded Zr67.8Cu24.7Al3.43Ni4.07 bulk metallic glasses[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(12): 138-142. DOI: 10.12073/j.hjxb.2019400327
Citation: MA Yanyi, WANG Haiyan, ZHANG Yupeng, YI Yaoyong, DONG Fuyu. Crystallization control and microstructural properties of laser welded Zr67.8Cu24.7Al3.43Ni4.07 bulk metallic glasses[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(12): 138-142. DOI: 10.12073/j.hjxb.2019400327
shu

Zr67.8Cu24.7Al3.43Ni4.07非晶合金激光焊接晶化控制及组织性能分析

  • 1.

    广东省焊接技术研究所(广东省中乌研究院)广东省现代焊接技术重点实验室, 广州 510651;沈阳工业大学, 沈阳 110870

  • 2.

    广东省焊接技术研究所(广东省中乌研究院)广东省现代焊接技术重点实验室, 广州 510651

  • 3.

    沈阳工业大学, 沈阳 110870

基金项目: 广东省科学院建设国内一流研究机构行动专项（2019GDASYL-0103075）；广东省科学院综合创新驱动发展能力提升专项（2017GDASCX-01）；广东省科技计划项目（2017A070701026，2018A050506058）；广州市科技项目（ZWY201704002）

Crystallization control and microstructural properties of laser welded Zr67.8Cu24.7Al3.43Ni4.07 bulk metallic glasses

  • 1.

    Guangdong Provincial Key Laboratory of Advanced Welding Technology, Guangdong Welding Institute (China-Ukraine E.O. Paton Institute of Welding), Guangzhou 510651, China;Shenyang University of Technology, Shenyang 110870, China

  • 2.

    Guangdong Provincial Key Laboratory of Advanced Welding Technology, Guangdong Welding Institute (China-Ukraine E.O. Paton Institute of Welding), Guangzhou 510651, China

  • 3.

    Shenyang University of Technology, Shenyang 110870, China

摘要

    摘要
  • 摘要: 对Zr67.8Cu24.7Al3.43Ni4.07非晶合金进行激光焊接，研究激光功率和焊接速度变化对接头不同区域微观组织的影响，阐述非晶合金激光焊接接头晶化控制的工艺调控规律，并分析接头不同区域的微观结构特征与其硬度之间的关系.结果表明，采用高焊速及高能量密度的激光焊接有利于使Zr67.8Cu24.7Al3.43Ni4.07非晶合金接头的熔化区保持非晶态结构，同时伴随少量纳米晶产生.热影响区的晶化现象明显，激光功率对接头完全焊透具有较大影响，通过降低激光功率或提高焊接速度以减小热输入，热影响区的晶化程度得到有效控制.焊后接头的熔化区硬度略高于母材，而热影响区的硬度相比于母材显著降低.
    Abstract: Laser welding was employed to weld Zr67.8Cu24.7Al3.43Ni4.07 bulk metallic glasses (BMGs). The effects of laser power and welding speed on the microstructures of different regions in the joints were studied. The crystallization control law of laser welded BMG joints is expounded, and the relationship between microstructure characteristics and hardness of as-welded joints is discussed. The results showed that the laser welding technology with high welding speed and high energy density is beneficial to maintain the amorphous structure of the molten zone in Zr67.8Cu24.7Al3.43Ni4.07 BMG joints, accompanied by some nano-grains forming. The crystallization happening in heat affected zones is severe. Laser power has a great influence on the complete penetration of as-welded joints. The degree of crystallization in heat affected zones can be effectively controlled through lowering laser power or increasing the welding speed to reduce heat input. Vickers hardness tests reveal that the hardness of the molten zones of the welded joint is slightly higher than that of base material, and the hardness of heat affected zones is significantly lower than that of the base material.
    • HTML全文
    • 参考文献(13)
  • [1] 王彦芳, 司爽爽, 宋增金, 等. 电火花沉积非晶涂层的组织结构与摩擦磨损性能[J]. 焊接学报, 2018, 39(7):121-124
    Wang Yanfang, Si Shuangshuang, Song Zengjin, et al. Microstructure and tribology behaviors of Zr-based amorphous coating on ZL101 by electro-spark deposition[J]. Transactions of the China Welding Institution, 2018, 39(7):121-124
    [2] Qiao J, Jia H, Liaw P K. Metallic glass matrix composites[J]. Materials Science and Engineering R Reports, 2016, 100:1-69.
    [3] 王 廷, 石志远, 李 宁, 等. Cu46Zr46Al8非晶合金电子束焊接特性分析[J]. 焊接学报, 2018, 39(8):38-41
    Wang Ting, Shi Zhiyuan, Li Ning, et al. Characteristic of electron beam welded Cu46Zr46Al8 BMGs[J]. Transactions of the China Welding Institution, 2018, 39(8):38-41
    [4] 文 驰. Zr基非晶合金扩散焊技术研究[D]. 武汉:华中科技大学, 2015.
    [5] 张英明, 袁子洲, 孙 慧, 等. 非晶合金连接的研究现状[J]. 材料学报, 2010, 24(9):89-92
    Zhang Yingming, Yuan Zizhou, Sun Hui, et al. Research status of the bonding for amorphous alloys[J]. Materials Reports, 2010, 24(9):89-92
    [6] Williams E, Lavery N. Laser processing of bulk metallic glass:a review[J]. Journal of Materials Processing Technology, 2017, 247:73-91.
    [7] Wirginia P. Structure and properties of Zr-Based bulk metallic glasses in as-cast state and after laser welding[J]. Materials, 2018, 11(7):1-14.
    [8] Wang H S, Chen H G, Jang J S C, et al. Combination of a Nd:YAG laser and a liquid cooling device to (Zr53Cu30Ni9Al8)Si0.5 bulk metallic glass welding[J]. Materials Science & Engineering A, 2010, 528(1):338-341.
    [9] Chen B, Shi T, Li M, et al. Crystallization of Zr55Cu30Al10Ni5 bulk metallic glass in laser welding:simulation and experiment[J]. Advanced Engineering Materials, 2015, 17(4):483-490.
    [10] Wang G, Huang Y J, Shagiev M, et al. Laser welding of Ti40Zr25Ni3Cu12Be20 bulk metallic glass[J]. Materials Science & Engineering A, 2012, 541(9):33-37.
    [11] Wang H S, Chen H G, Jang S C. Microstructure evolution in Nd:YAG laser-welded (Zr53Cu30Ni9Al8)Si0.5 bulk metallic glass alloy[J]. Journal of Alloys & Compounds, 2010, 495(1):224-228.
    [12] Chen H L, Li L J, Lin T L. Formation of segregation morphology in crystalline/amorphous polymer blends:molecular weight effect[J]. Macromolecules, 1998, 31(7):2255-2264.
    [13] 胡 鹏. 锆基非晶合金及复合材料凝固行为的研究[D]. 兰州:兰州理工大学, 2018.
