环保焊枪吸烟对小电流CO2气体保护电弧焊的影响
Influence of extraction fume by environmental welding torch on low current CO2 gas shielded arc welding
-
摘要: 采用环保焊枪进行了小电流二氧化碳气体保护电弧焊平焊位置焊接，通过分析焊接过程中电弧形貌、电流电压和熔滴过渡方式变化以及焊缝成形、焊缝金属拉伸力学性能和X射线探伤结果，评估了吸烟功率变化时的吸烟效果以及吸烟行为对于焊接过程和焊缝质量的影响规律. 结果表明，使用环保焊枪可以显著降低小电流二氧化碳气体保护电弧焊时飘散在周围空间中的焊接烟尘. 吸烟过程虽然使得短路过渡熔滴频率略有增加，悬挂熔滴和电弧的稳定性略为变差，但对焊缝成形和焊接缺陷都无影响，焊缝金属屈服强度略有减小，抗拉强度略有增加.
-
关键词:
- 环保焊枪 /
- 二氧化碳气体保护电弧焊 /
- 短路过渡 /
- 焊接过程 /
- 焊接品质
Abstract: Using environmental welding torch, low current CO2 gas shielded arc welding at flat position was carried out to analyze the change of arc shape, current and voltage, the droplet transfer and weld formation, weld metal tensile mechanics and X-ray radiographic inspection. Fume extraction effect and its influence on welding process and weld quality were evaluated. The results showed that using environmental welding torch is able to dramatically low down the welding fume diffusion to the environment during the low current CO2 gas shielding welding. It will not impact the shape of weld or cause welding defects, although the frequency of droplet transfer of short circuit transition is slightly quickened, the stabilities of suspend droplet and arc get a little worse. The yield strength of weld is slightly decreased, while the tensile strength is slightly increases. -
-
[1] Zhang H W, Su J H, Chen J. Status and development trend of the welding consumables industry in China[J]. China Welding, 2017, 26(2):23-31. [2] 肖诗祥, 施雨湘, 杨世柏. 焊后焊接烟尘粒子的凝并[J]. 武汉交通科技大学学报, 1997, 21(4):414-419
Xiao Shixiang, Shi Yuxiang, Yang Shibo. Aggravation of post-weld fume particle[J]. Journal of Wuhan Transportation University, 1997, 21(4):414-419[3] Hassani H, Golbabaei F, Ghahri A, et al. Occupational exposure to manganese-containing welding fumes and pulmonary function indices among natural gas transmission pipeline welders[J]. Journal of Occupational Health, 2012, 54(4):316-322. [4] Koh D, Lee S W, Ye B, et al. Grouping schemes of welding fume exposure in shipyard welders[J]. Journal of Occupational and Environmental Hygiene, 2018, 15(5):413-421. [5] Floros N. Welding fume main compounds and structure[J]. Welding in the World, 2018, 62(2):311-316. [6] Donoghue A M, Wesdock J C. Pneumococcal vaccination for welders:global deployment within a multi-national corporation[J]. American Journal of Industrial Medicine, 2019, 62(1):69-73. [7] Golbabaei F, Khadem M. Air Pollution in welding processes-assessment and control methods[M]. Rijeka:Intech Open, 2015. [8] Smith L K. Fume exposures from welding with low hydrogen electrodes[J]. Annals of Occupational Hygiene, 1967, 10(2):113-121. [9] Flynn M R, Susi P. Local exhaust ventilation for the control of welding fumes in the construction industry-a literature review[J]. Annals of Occupational Hygiene, 2012, 56(7):764-776. [10] Chen S. Research status of ventilation method in welding workshop[C]//Proceedings of the 2017 International Conference on Society Science (ICoSS 2017), Shenyang:Atlantis Press., 2017:17-19. -
