激光熔覆在AlN陶瓷表面制备铜基金属覆层缺陷分析及控制
Analysis and control of defects in preparing copper-based metal coatings on AlN ceramic surface by laser cladding
-
摘要: 通过脉冲式YAG激光器在AlN陶瓷表面制备铜基金属覆层，分析熔覆层的缺陷，并研究如何能控制熔覆层缺陷的发生，熔覆试样的缺陷主要表现为陶瓷基板炸裂、熔覆层成形不完整、熔覆层微观裂纹和气孔.结果表明，通过调节激光熔覆的热输入可以保证陶瓷基板的完整性并且熔覆层成形良好；通过焊前预热和焊后缓冷的工艺可以降低熔覆层微观裂纹和气孔的形成几率.通过优化激光熔覆工艺参数和工艺方法，可以形成良好的熔覆层，并且AlN陶瓷基板和铜基金属覆层之间形成过渡层，形成良好的冶金结合.Abstract: Copper-based metal coatings were prepared on the surface of AlN ceramics by pulsed YAG lasers. The defects of the cladding layers were analyzed. It was also studied how to control the occurrence of defects in the cladding layers. The defects of the cladding samples were mainly the cracking of the ceramic substrate. Cladding formation incomplete, micro-cracks cracks and pores. The results show that by adjusting the heat input of the laser cladding, the integrity of the ceramic substrate can be ensured and the cladding layer can be well formed. The pre-heating before welding and slow cooling after welding can reduce the micro cracks and the formation probability of the pores. By optimizing the laser cladding process parameters and process methods, a good cladding layer can be formed, and a transition layer is formed between the AlN ceramic substrate and the copper-based metal cladding to form a good metallurgical bond.
-
Keywords:
- laser cladding /
- ceramic substrate integrity /
- micro-cracks /
- gas pore
-
-
[1] 秦典成, 李保忠, 肖永龙. 陶瓷金属化研究现状及发展趋势[J]. 中国陶瓷工业, 2017, 24(5):30-36 Qin Diancheng, Li Baozhong, Xiao Yonglong. Research status and development trend of ceramic metallization[J]. China Ceramic Industry, 2017, 24(5):30-36 [2] 周利, 赵洪运, 舒凤远, 等. AlN陶瓷表面单道激光熔覆铜应力应变数值分析[J]. 焊接学报, 2014, 35(9):57-60 Zhou Li, Zhao Hongyun, Shu Fengyuan, et al. Numerical analysis of stress and strain of single-pass laser cladding copper on AlN ceramic surface[J]. Transactions of the China Welding Society, 2014, 35(9):57-60 [3] 李慧, 秦明礼, 钟小婧, 等. AlN陶瓷活性封接技术的研究概况[J]. 粉末冶金材料科学与工程, 2010, 15(1):8-15 Li Hui, Qin Mingli, Zhong Xiaojing, et al. Overview of AlN ceramic active sealing technology[J]. Powder Metallurgy Materials Science and Engineering, 2010, 15(1):8-15 [4] 舒凤远. AlN陶瓷表面快速制备铜覆层过程数值模拟与实验研究[D]. 哈尔滨:哈尔滨工业大学, 2010. [5] 李嘉宁,刘科高,张元彬. 激光熔覆技术及应用[M]. 北京:化学工业出版社,2015. [6] Chen T, Liu D, Wu F, et al. Effect of CeO2 on microstructure and wear resistance of TiC bioinert coatings on Ti6Al4V alloy by laser cladding[J]. Materials, 2018, 11(1) -58. [7] Yifu Z, Hua Z, Zhengqiang Z, et al. Microstructure, properties and first principles calculation of titanium alloy/steel by Nd:YAG laser self-fluxing welding[J]. China Welding, 2018, 27(3):5-14. [8] Li M, Huang J, Zhu Y Y, et al. Effect of heat input on the microstructure of in-situ synthesized TiN-TiB/Ti based composite coating by laser cladding[J]. Surface & Coatings Technology, 2012, 206(19-20):4021-4026. [9] Tanigawa D, Abe N, Tsukamoto M, et al. The effect of particle size on the heat affected zone during laser cladding of Ni-Cr-Si-B alloy on C45 carbon steel[J]. Optics & Lasers in Engineering, 2018, 101:23-27. [10] Zhuang Qiaoqiao, Zhang Peilei, Li Mingchuan, et al. Microstructure, wear resistance and oxidation behavior of Ni-Ti-Si coatings fabricated on Ti6Al4V by laser cladding[J]. Materials, 2017, 10(11):1248-1253. -
