等离子弧异质异构增材制造构件的组织与力学性能分析

徐俊强, 彭勇, 刘智慧, 周琦, 孔见

徐俊强, 彭勇, 刘智慧, 周琦, 孔见. 等离子弧异质异构增材制造构件的组织与力学性能分析[J]. 焊接学报, 2019, 40(11): 119-124. DOI: 10.12073/j.hjxb.2019400298
引用本文: 徐俊强, 彭勇, 刘智慧, 周琦, 孔见. 等离子弧异质异构增材制造构件的组织与力学性能分析[J]. 焊接学报, 2019, 40(11): 119-124. DOI: 10.12073/j.hjxb.2019400298
shu
XU Junqiang, PENG Yong, LIU Zhihui, ZHOU Qi, KONG Jian. Study on plasma arc additive manufacturing process of dissimilar steels with various composite structures[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(11): 119-124. DOI: 10.12073/j.hjxb.2019400298
Citation: XU Junqiang, PENG Yong, LIU Zhihui, ZHOU Qi, KONG Jian. Study on plasma arc additive manufacturing process of dissimilar steels with various composite structures[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(11): 119-124. DOI: 10.12073/j.hjxb.2019400298
shu

等离子弧异质异构增材制造构件的组织与力学性能分析

  • 1.

    南京理工大学, 南京 210094;南京理工大学 受控电弧智能增材技术工信部重点实验室, 南京 210094

  • 2.

    南京理工大学, 南京 210094;江苏烁石焊接科技有限公司, 南京 211135

基金项目: 国家自然科学基金资助项目（51805265）；国防科技创新特区项目.

Study on plasma arc additive manufacturing process of dissimilar steels with various composite structures

  • 1.

    Nanjing University of Science and Technology, Nanjing 210094, China;Key Laboratory of Controlled Arc Intelligent Additive Technology, Nanjing University of Science and Technology, Nanjing 210094, China

  • 2.

    Nanjing University of Science and Technology, Nanjing 210094, China;Jiangsu Shuoshi Welding Technology Co., Ltd., Nanjing 211135, China

摘要

    摘要
  • 摘要: 采用等离子弧增材系统实现了不锈钢/高强钢异质异构增材构件制备，等离子弧增材构件具有良好的沉积形貌及优异的力学性能.为揭示叠合方式对等离子弧异质增材构件的宏微观组织和力学性能特征影响，研究采用了体视显微镜、金相显微镜、拉伸及硬度等测试方法.结果表明，不锈钢/高强钢异质异构增材构件中存在两种过渡形式，即以奥氏体枝晶过渡和马氏体组织过渡.增材构件横截面硬度波动较大，主要是混合过渡区域的高合金元素导致的组织变化引起的.叠合方式的改变能够显著影响材料性能，在强度下降不多的情况下，提高材料的冲击韧性.
    Abstract: The plasma arc additive manufacturing process was used to realize the deposition of stainless steel/high strength steel with various composite structures. The components fabricated by plasma arc have good depositional morphology and excellent mechanical properties. In order to reveal the effect of the composite structures on the macro/microstructure and mechanical properties of the components, stereo microscope, metallographic microscope, tensile and hardness testing methods were used. The results show that there are two kinds of transition interface:laminated austenite-dendrite transition and martensite transition. The microhardness fluctuation in the cross section of the components were large, which is mainly caused by the change of the structure due to the alloy elements. The various composite structures can significantly affect the properties of materials, and "stainless steel+ high strength steel"alternating structure improves the impact toughness of materials when the strength decreases little.
    • HTML全文
    • 参考文献(12)
  • [1] Xiong J, Yin Z, Zhang W. Closed-loop control of variable layer width for thin-walled parts in wire and arc additive manufacturing[J]. Journal of Materials Processing Technology, 2016, 233:100-106.
    [2] Ding D, Pan Z, Cuiuri D, et al. A practical path planning methodology for wire and arc additive manufacturing of thin-walled structures[J]. Robotics & Computer Integrated Manufacturing, 2015, 34(C):8-19.
    [3] Yang D, He C, Zhang G. Forming characteristics of thin-wall steel parts by double electrode GMAW based additive manufacturing[J]. Journal of Materials Processing Technology, 2016, 227:153-160.
    [4] 张温馨, 姚渭, 刘莹莹, 等. 异种合金的连接工艺特征及其界面的组织性能[J]. 材料导报, 2015, 29(21):98-102 Zhang Wenxin, Yao Wei, Liu Yingying, et al. Joining process feature and interfacial microstructure properties of dissimilar alloy[J]. Materials Reports, 2015, 29(21):98-102
    [5] 冯吉才, 王廷, 张秉刚, 等. 异种材料真空电子束焊接研究现状分析[J]. 焊接学报, 2009, 30(10):108-112 Feng Jicai, Wang Yan, Zhang Bingang, et al. Research status analysis of electron bean welding for joining of dissimilar mateails[J]. Transactions of the China Welding Institution, 2009, 30(10):108-112
    [6] Liu G L, Yang S W, Han W T, et al. Microstructural evolution of dissimilar welded joints between reduced-activation ferritic-martensitic steel and 316L stainless steel during the post weld heat treatment[J]. Materials Science and Engineering:A, 2018, 722:182-196.
    [7] 刘东宇, 李东, 李凯斌, 等. E36与304电子束焊接接头的组织及性能[J]. 航天制造技术, 2014(6):29-33 Liu Dongyu, Li Dong, Li Kaibin, et al. Microstructure and properties of welded joint of E36 steel and 304 stainless steel by electron beam welding[J]. Aeronautical Manufacturing Technology, 2014(6):29-33
    [8] Vidyarthy R S, Kulkarni A, Dwivedi D K. Study of microstructure and mechanical property relationships of A-TIG welded P91-316L dissimilar steel joint[J]. Materials Science and Engineering:A, 2017, 695:249-257.
    [9] Das S, Bourell D L, Babu S S. Metallic materials for 3D printing[J]. MRS Bulletin, 2016, 41(10):729-741.
    [10] 曹嘉明. 电弧熔丝增材制造高强钢零件工艺基础研究[D]. 武汉:华中科技大学. 2017.
    [11] Feng Y, Zhan B, He J, et al. The double-wire feed and plasma arc additive manufacturing process for deposition in Cr-Ni stainless steel[J]. Journal of Materials Processing Technology, 2018, 259:206-215.
    [12] Rajasekhar K, Harendranath C S, Raman R, et al. Microstructural evolution during solidification of austenitic stainless steel weld metals:a color metallographic and electron microprobe analysis study[J]. Materials Characterization, 1997, 38(2):53-65.
