面向虚拟现实人机协作焊接系统的运动控制策略

肖珺, 温涛, 陈树君, 李锐

肖珺, 温涛, 陈树君, 李锐. 面向虚拟现实人机协作焊接系统的运动控制策略[J]. 焊接学报, 2019, 40(11): 13-20. DOI: 10.12073/j.hjxb.2019400281
引用本文: 肖珺, 温涛, 陈树君, 李锐. 面向虚拟现实人机协作焊接系统的运动控制策略[J]. 焊接学报, 2019, 40(11): 13-20. DOI: 10.12073/j.hjxb.2019400281
shu
XIAO Jun, WEN Tao, CHEN Shujun, LI Rui. Teleoperation strategy research for collaborative welding system based on virtual reality[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(11): 13-20. DOI: 10.12073/j.hjxb.2019400281
Citation: XIAO Jun, WEN Tao, CHEN Shujun, LI Rui. Teleoperation strategy research for collaborative welding system based on virtual reality[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(11): 13-20. DOI: 10.12073/j.hjxb.2019400281
shu

面向虚拟现实人机协作焊接系统的运动控制策略

  • 1.

    北京工业大学 智能成形装备及系统研究所, 北京 100124;汽车结构部件先进制造技术教育部工程研究中心, 北京 100124

  • 2.

    哈尔滨市锅炉压力容器检验研究院, 哈尔滨 150076

Teleoperation strategy research for collaborative welding system based on virtual reality

  • 1.

    Institute of Intelligent Forming Equipment and System, Beijing University of Technology, Beijing 100124, China;Engineering Research Center of Advanced Manufacturing Technology for Automotive Components, Ministry of Education, Beijing 100124, China

  • 2.

    Harbin Boiler and Pressure Vessel Inspection Research Institute, Harbin 150076, China

摘要

    摘要
  • 摘要: 以发挥人的优势为目标，设计虚拟现实人机协作焊接系统的运动控制策略并研究其针对焊接任务的可靠性.远程协作焊接过程可以将空间六自由度控制器的输入信号转换为目标焊枪的位姿变化、速度变化或加速度变化.面向焊接的任务性质，设计静态位姿型、动态位姿型、速度型、加速度型四种控制策略.在虚拟现实环境下开发用于检验运动控制策略可靠性的焊接跟随试验测试分析系统，研究遥控焊枪跟随物体沿直线轨迹、曲线轨迹、空间曲线轨迹运动时，四种运动策略的跟踪精度.结果表明，动态位姿型控制策略是应用于虚拟现实人机协作焊接系统中总体表现最稳定、适应性最强的运动控制策略.
    Abstract: Teleoperation control strategies for collaborative welding system which is targeting at giving full play to human's superiority is designed and the fitness for teleoperation welding task of which are studied. During the teleoperation welding process, 6-DOF controller's signal can be converted into welding torch's position, velocity or acceleration changing which is being controlled. For welding purposes, control strategies of four modes are designed, which are static position and posture mode, dynamic position and posture mode, velocity mode and acceleration mode. A test and analysis system for testing the tracking accuracy and reliability of control strategy based on virtual reality is developed. The tracking accuracies of the four control strategies are studied in the following tests with straight line trajectory, curve trajectory or space curve trajectory. The results show that the control strategy in dynamic position and posture mode has best stability and strong adaptability which is most suitable for the teleoperation system.
    • HTML全文
    • 参考文献(13)
  • [1] Masubuchi K, Gaudiano A V, Reynolds T J. Technologies and practices of underwater welding[J]. Underwater Welding, 1983(1):49-70.
    [2] Agapakis J E, Masubuchi K, Von Alt C. Fundamentals and advances in the development of remote welding fabrication systems[J]. Welding Journal, 1986, 65(9):21-32.
    [3] Tung P, Wu M, Hwang Y. An image-guided mobile robotic welding system for SMAW repair processes[J]. International Journal of Machine Tools & Manufacture, 2004, 44(11):1223-1233.
    [4] 魏秀权, 李海超, 高洪明, 等. 基于人机交互的遥控焊接虚拟环境标定技术[J]. 焊接学报, 2006, 27(4):37-40 Wei Xiuquan, Li Haichao, Gao Hongming, et al. Virtual environment calibration based on human-machine interaction for remote welding[J]. Transactions of the China Welding Institution, 2006, 27(4):37-40
    [5] Wei X, Li H, Gao H, et al. Operational space calibration for remote welding based on surface tracking with shared force control[J]. Journal of Computing and Information Science in Engineering, 2008, 8(4):041005-1-041005-7.
    [6] 韦有双, 王飞, 冯允成. 虚拟现实与系统仿真[J]. 计算机仿真, 1999(2):63-66 Wei Youshuang, Wang Fei, Feng Yuncheng. Virtual reality and system simulation[J]. Computer Simulation, 1999(2):63-66
    [7] 杨宝民. 分布式虚拟现实技术及其应用[M]. 北京:科学出版社, 2000.
    [8] 陈洪堂, 李海超, 高洪明, 等. 基于人机工程的主从机器人遥控焊接焊缝跟踪误差分析[J]. 焊接学报, 2012, 33(5):9-12 Chen Hongtang, Li Haichao, Gao Hongming, et al. Error analysis of seam tracking in master-slave robot remote welding based on ergonomics[J]. Transactions of the China Welding Institution, 2012, 33(5):9-12
    [9] John V. Quaternions for computer graphics[M]. Springer London, 2011.
    [10] Hasegawa I. The use of unstable training for enhancing sport performance[J]. Nacas Performance Training Journal, 2005, 4(4):15-17.
    [11] Travis B. Core flexibility static and dynamic strengths for the core[J]. NACA's Performance Training, 2005, 4(4):8-10.
    [12] 关亚军, 马忠权. 核心力量的定义及作用机制探讨[J]. 北京体育大学学报, 2010(1):106-108 Guan Yajun, Ma Zhongquan. Core force definition and action mechanism discussion[J]. Journal of Beijing Sport University, 2010(1):106-108
    [13] 于红妍, 王虎, 冯春辉, 等. 核心力量训练与传统力量训练之间关系的理论思考——核心稳定性训练[J]. 天津体育学院学报, 2008, 23(6):509-511 Yu Hongyan, Wang Hu, Feng Chunhui, et al. Theoretical consideration on the relationship between core strength training and traditional strength training——core stability training[J]. Journal of Tianjin University of Sport, 2008, 23(6):509-511
