纯铝1060/镀锌钢电阻点钎焊工艺及接头性能
Study on welding process and mechanical properties of resistance spot brazed pure aluminum 1060 to galvanized steel
-
摘要: 采用电阻点钎焊进行了纯铝1060与SGCC热镀锌钢板的搭接试验，研究了接头界面组织，并测试了接头力学性能. 结果表明，试验所用铝硅（Al-Si）合金钎料润湿良好，焊后接头焊缝界面处产生了具有双层结构且厚度不均的金属间化合物，厚度小于10 μm；焊接电流为7.8 kA时，接头抗拉剪载荷达到峰值，约为4.72 kN，在相同工艺参数下，电阻点钎焊接头的抗拉剪载荷明显高于点焊接头；接头断裂大都发生在铝板侧，且主要在热影响区处而不在焊点处，说明点钎焊接头质量良好，但由于焊缝铝侧界面局部存在“未钎合”缺陷，焊缝界面会产生拉应力且在金属间化合物的应力作用下易产生裂纹.Abstract: Resistance spot brazing of pure aluminum 1060 to SGCC hot-dip galvanized steel was investigated. The microstructure of the intermetallic compound (IMC) in the interfacial layer was analyzed, and the mechanical properties of the joint was tested. The results showed that the aluminum-silicon brazing filler metal had a well wettability, and the intermetallic compound with double-layer structure and uneven thickness less than 10 μm generated at the interface of the welded joint. When the welding current was 7.8 kA, the maximum tensile shear load of the joint was 4.72 kN, which was significantly higher than that of the resistance spot welding joint under the same process parameters. The fracture of the joint mostly occured on the side of aluminum plate, and it was mainly in the heat affected zone (HAZ) rather than the welding spot, indicating that the resistance point brazing joint was of good quality. However, the local incomplete brazing was found in the weld interface at the aluminum side, where the tensile stress was generated, and the weld interface tended to crack under the stress of the intermetallic compound.
-
Keywords:
- pure aluminum /
- galvanized steel /
- resistance spot brazing /
- microstructure /
- mechanical properties
-
-
[1] 谢群,宋禹田.轻量化是汽车工业可持续发展的保证[J].轻合金加工技术, 2013, 41(12):14-16 Xie Qun, Song Yutian. Lightening is the guarantee for the sustainable development of automobile industry[J]. Light Alloy Fabrication Technology, 2013, 41(12):14-16 [2] Santos J, Gouveia R M, Silva F J G. Designing a new sustainable approach to the change for lightweight materials in structural components used in truck industry[J]. Journal of Cleaner Production, 2017, 164:115-123. [3] 李亚江,吴娜.钢/铝异种金属焊接的研究现状[J].焊接, 2010(3):5-12 Li Yajiang, Wu Na. Current Research Status of Steel/Aluminum Dissimilar Metal Welding[J]. Welding&Joining, 2010(3):5-12 [4] 李永兵,李亚庭,楼铭,等.轿车车身轻量化及其对连接技术的挑战[J].机械工程学报, 2012, 48(18):44-54 Li Yongbing, Li Yating, Lou Ming, et al. Lightweighting of car body and its challenges to joining technologies[J]. Journal of Mechanical Engineering, 2012, 48(18):44-54 [5] Yang J, Li Y L, Zhang H. Microstructure and mechanical properties of pulsed laser welded Al/steel dissimilar joint[J]. Transactions of Nonferrous Metals Society of China, 2016, 26(4):994-1002. [6] Winnicki M, Małachowska A, Korzeniowski M, et al. Aluminium to steel resistance spot welding with cold sprayed interlayer[J]. Surface Engineering, 2018, 34(3):235-242. [7] Kimura M, Suzuki K, Kusaka M, et al. Effect of friction welding condition on joining phenomena, tensile strength, and bend ductility of friction welded joint between pure aluminium and AISI 304 stainless steel[J]. Journal of Manufacturing Processes, 2017, 25:116-125. [8] 凌展翔,罗震,冯悦峤,等.铝钢点焊铆接复合连接技术[J].焊接学报, 2017, 38(2):101-104 Ling Zhanxiang, Luo Zhen, Feng Yueqiao, et al. A combination joining technology of spot welding and riveting for aluminum and steel[J]. Transactions of the China Welding Institution, 2017, 38(2):101-104 [9] Qiu R, Satonaka S, Iwamoto C. Effect of interfacial reaction layer continuity on the tensile strength of resistance spot welded joints between aluminum alloy and steels[J]. Materials and Design, 2009, 30(9):3686-3689. [10] Qiu R, Satonaka S, Iwamoto C. The influence of reaction layer on the strength of aluminum/steel joint welded by resistance spot welding[J]. Materials Characterization, 2009, 60(2):156-159. [11] 张柯柯,杜宜乐,邱然锋,等. A6061铝合金与Q235钢电阻点焊接头组织与性能[J].材料热处理学报, 2012, 33(12):64-67 Zhang Keke, Du Yile, Qiu Ranfeng, et al. Microstructure and properties of A6061 aluminum alloy/Q235 steel joint welded by resistance spot welding[J]. Transactions of Materials and Heat Treatment, 2012, 33(12):64-67 [12] 何鹏,冯吉才,钱乙余,等.接触反应法解决铝/不锈钢钎焊的缺陷及脆性[J].材料科学与工艺, 2005, 13(1):82-85 He Peng, Feng Jicai, Qian Yiyu, et al. Resolve of fragile and defect problem for a new contact reaction brazing aluminum to stainless steel[J]. Materials Science&Technology, 2005, 13(1):82-85 -
