钎料形态对半固态加压反应钎焊接头的影响

李娟, 秦庆东, 龙琼, 张英哲

李娟, 秦庆东, 龙琼, 张英哲. 钎料形态对半固态加压反应钎焊接头的影响[J]. 焊接学报, 2019, 40(9): 139-144. DOI: 10.12073/j.hjxb.2019400250
引用本文: 李娟, 秦庆东, 龙琼, 张英哲. 钎料形态对半固态加压反应钎焊接头的影响[J]. 焊接学报, 2019, 40(9): 139-144. DOI: 10.12073/j.hjxb.2019400250
shu
LI Juan, QIN Qingdong, LONG Qiong, ZHANG Yingzhe. Influence of the filler metals' forms on semi-solid pressure reaction brazing joints[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(9): 139-144. DOI: 10.12073/j.hjxb.2019400250
Citation: LI Juan, QIN Qingdong, LONG Qiong, ZHANG Yingzhe. Influence of the filler metals' forms on semi-solid pressure reaction brazing joints[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(9): 139-144. DOI: 10.12073/j.hjxb.2019400250
shu

钎料形态对半固态加压反应钎焊接头的影响

  • 贵州理工学院 贵州省特种功能材料2011协同创新中心, 贵阳 550003;贵州理工学院 贵州省轻金属材料制备技术重点实验室, 贵阳 550003

基金项目: 贵州省教育厅青年科技人才成长项目（黔教合KY字[2018]245）

Influence of the filler metals' forms on semi-solid pressure reaction brazing joints

  • 2011 Special Function Materials Collaborative Innovation Center of Guizhou Province, Guiyang, 550003, China;Key Laboratory of Light Metal Materials Processing Technology of Guizhou Province, Guiyang 550003, China

摘要

    摘要
  • 摘要: 采用自制不同形态的Al-Si-Mg-Cu-Ti钎料对70% SiCp/Al复合材料进行了半固态加压反应钎焊，阐述了该焊接方法的内涵，分析了接头组织性能. 结果表明，填充粉末钎料时，钎缝组织为铝合金基体、深灰色环状和块状Ti7Al5Si12和块状Ti；填充片状钎料时，钎缝组织为铝合金基体和短棒状Ti7Al5Si12. 接头界面结合情况是影响接头性能的主要因素. 填充粉末钎料时，钎料与母材结合充分，原子扩散通道多，接头界面结合好，没有明显分界线，接头力学性能好，抗剪强度达92.1 MPa，断口属于韧脆混合断口；填充片状钎料时，界面处有明显分界线，接头力学性能差，抗剪强度为43.9 MPa，断口为脆性断口.
    Abstract: 70% SiCp/Al composites were semi-solid pressure reaction brazed with the Al-Si-Mg-Cu-Ti filler metal in different forms, the connotation of the welding method was expounded, and the microstructures and properties of the joints were analyzed. The results indicated that the joints mainly contain Al matrix, dark gray ringed and massive Ti7Al5Si12 compound, and massive Ti phase when they were filled with pulverous filler metal; the joints mainly contained Al matrix and short clubbed Ti7Al5Si12 compound when they were filled with schistose filler metal. The bonding of interface was the main factor affecting the performance of the joint. The filler metal and the base material were fully combined during brazing when they were filled with powder filler metal, which provided many atomic diffusion channel at the interface of the joint, so that they were well combined without clear dividing line, the shear strength of the joint reached 92.1 MPa, and the fracture was ductile and brittle mixed fracture; There was clear dividing line at the interface when the filler metal was schistose, so that the shear strength of the joint was low, 43.9 MPa, and the fracture was brittle fracture.
    • HTML全文
    • 参考文献(15)
  • [1] Cui Y, Jin T Z, Cao L G, et al. Aging behavior of high volume fraction SiCp/Al composites fabricated by pressureless infiltration[J]. Journal of Alloys and Compounds, 2016, 681:233-239.
    [2] 高增,冯建广,王鹏,等.钎焊温度对SiCp/Al复合材料焊接接头组织与性能的影响[J].兵器材料科学与工程, 2018, 41(05):57-61 Gao Zeng, Feng Jianguang, Wang Peng, et al. Effect of brazing temperature on microstructure and performance of brazed joint of SiCp/Al composite[J]. Ordnance Material Science and Engineering, 2018, 41(05):57-61
    [3] Zhu C M, Gu P, Wu Y Y, et al. Surface roughness prediction model of SiCp/Al composite in grinding[J]. International Journal of Mechanical Science, 2019, 155:98-109.
    [4] Zhang X Z, Wu X L, Liu G W, et al. Wetting of molten Sn-3.5Ag-0.5Cu on Ni-P (-SiC) coatings deposited on high volume faction SiC/Al composite[J]. Transactions of Nonferrous Metals Society of China, 2018, 28(9):1784-1792.
    [5] Zhang X X, Wu L H, Andrä H, et al. Effects of welding speed on the multiscale residual stresses in friction stir welded metal matrix composites[J]. Journal of Materials Science&Technology, 2019, 35(5):824-832.
    [6] Kang Y Q, Shen H R, Fu Y, et al. Microstructure evolution and mechanical properties of the Sip/Zn-Al composite joints by ultrasonic-assisted soldering in air[J]. China Welding, 2018, 27(2):39-44.
    [7] Huang Z Y, Du H Q, Liu L, et al. Ultrasonic effect mechanism on transient liquid phase bonding joints of SiCp reinforced Mg metal matrix composites using Zn-Al-Zn multi-interlayer[J]. Ultrasonics Sonochemistry, 2018, 43:101-109.
    [8] Cui W, Li S Q, Yan J C, et al. Microstructure and mechanical performance of composite joints of sapphire by ultrasonic-assisted brazing[J]. Journal of Materials Processing Technology, 2018, 257:1-6.
    [9] Zhang X Z, Zhao S T, Liu G W, et al. Review on brazing of high volume fraction SiCp/Al composites for electronic packaging applications[J]. Rare Metal Materials and Engineering, 2017, 46(10):2812-2819.
    [10] 李娟,王克鸿.采用Al-Si-Ti-Cu-In钎焊70% SiCp/Al复合材料工艺研究[J].机械工程学报, 2016, 52(12):59-66 Li Juan, Wang Kehong. Study on vacuum brazing of 70% SiCp/Al composites using Al-Si-Ti-Cu-In filler metal[J]. Journal of Mechanical Engineering, 2016, 52(12):59-66
    [11] 陈晓光. SiC陶瓷与Ti-6Al-4V合金超声波辅助钎焊的润湿结合机制及工艺研究[D].哈尔滨.哈尔滨工业大学, 2013.
    [12] Lee J C, Ahn J P, Shim J H, et al. Control of the interface in SiC/Al composites[J]. Scripta Materialia, 1999, 41(8):895-900.
    [13] Li J, Wang K H, Zhang D K, et al. Mechanism of interfacial reaction between Ti and Al-ceramic[J]. Materials and Design, 2016, 105:223-233.
    [14] 李娟,王克鸿,张德库.合金元素对70% SiCp/Al复合材料钎料性能的影响[J].焊接学报, 2015, 36(10):73-76 Li Juan, Wang Kehong, Zhang Deku. Effect of alloying elements on filler metal for brazing of 70% SiCp/Al composites[J]. Transactions of the China Welding Institution, 2015, 36(10):73-76
    [15] Zhang G F, Cai J, Chen B Q, et al. Availability of in-situ reinforced active-transient liquid phase bond with good wettability for 70 vol.% SiCp/A356 composite using Al-Mg-Ga-Ti interlayer[J]. Materials and Design, 2016, 110:653-662.
