TA2-1060-TA2复合板爆炸焊接试验及性能测试

房中行, 史长根, 冯柯, 葛雨珩, 尤峻

房中行, 史长根, 冯柯, 葛雨珩, 尤峻. TA2-1060-TA2复合板爆炸焊接试验及性能测试[J]. 焊接学报, 2019, 40(9): 87-92. DOI: 10.12073/j.hjxb.2019400241
引用本文: 房中行, 史长根, 冯柯, 葛雨珩, 尤峻. TA2-1060-TA2复合板爆炸焊接试验及性能测试[J]. 焊接学报, 2019, 40(9): 87-92. DOI: 10.12073/j.hjxb.2019400241
shu
FANG Zhonghang, SHI Changgen, FENG Ke, GE Yuheng, YOU Jun. Explosive welding experiment and property test of TA2-1060-TA2 cladding plate[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(9): 87-92. DOI: 10.12073/j.hjxb.2019400241
Citation: FANG Zhonghang, SHI Changgen, FENG Ke, GE Yuheng, YOU Jun. Explosive welding experiment and property test of TA2-1060-TA2 cladding plate[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(9): 87-92. DOI: 10.12073/j.hjxb.2019400241
shu

TA2-1060-TA2复合板爆炸焊接试验及性能测试

  • 1.

    中国人民解放军陆军工程大学, 南京 210007

  • 2.

    中国空气动力研究与发展中心, 绵阳 621000

基金项目: 国家自然科学基金资助项目（51541112）

Explosive welding experiment and property test of TA2-1060-TA2 cladding plate

  • 1.

    Army Engineering University of PLA, College of Field Engineering, Nanjing 210007, China

  • 2.

    High Speed Institute of China Aerodynamics Research & Development Center, Mianyang 621000, China

摘要

    摘要
  • 摘要: 为了解决钛-铝在爆炸焊接过程中可焊性低并容易产生脆性金属间化合物等技术难题，选用低爆速粉状乳化炸药为试验用药，下限装药厚度和上限基复板间距为工艺参数，成功获得了100%复合的“1 + 14 + 1”TA2 - 1060 - TA2双面金属复合板. OM， SEM， EDS测试结果表明，复合板界面呈良好小波状结合；基复板流在波峰阻挡以及复板挤压作用下形成漩涡结构，其内部存在包覆熔融金属的铸锭组织；结合界面附件发生不同程度的元素扩散. 力学测试结果表明，复合板的弯曲强度为288 MPa、抗拉强度为165.5 MPa、界面处显微硬度峰值为227 HV，满足工业生产要求.
    Abstract: To solve technical problems of low weldability and easy generation of brittle intermetallic compounds during titanium-aluminum explosive welding, the low-detonation-velocity powdery emulsion explosive, lower limit of charge thickness and upper limit of distance between the flyer and base plates were determined, thereby successfully manufacturing "1 + 14 + 1" TA2-1060-TA2 double-sided metal cladding plate with 100% welding rate. The results of OM, SEM, EDS tests showed that the interfaces of the cladding plate presented the high quality small wavy bonding; under the action of peak blocking and flyer plate extrusion, the flowing of the base and flyer plates generated the vortex structure where the ingot structure wrapping molten metals were observed; different levels of elemental diffusion took place near the bonding interfaces. The mechanical test results showed that the bending strength, tensile strength and microhardness peak value of the cladding plate were 288 MPa, 165.5 MPa and 227 HV, respectively, which met the requirements of industrial production.
    • HTML全文
    • 参考文献(12)
  • [1] 韩小敏,王少刚,黄燕,等. TA10-Q345R爆炸复合板的界面微观结构及力学性能[J].压力容器, 2015, 32(6):24-29 Han Xiaomin, Wang Shaogang, Huang Yan, et al. Interfacial microstructure and mechanical properties of TA10-Q345R composite plate with explosive welding[J]. Pressure Vessel Technology, 2015, 32(6):24-29
    [2] Mali V I, Bataev A A, Maliutina I N, et al. Microstructure and mechanical properties of Ti/Ta/Cu/Ni alloy laminate composite materials produced by explosive welding[J]. International Journal of Advanced Manufacturing Technology, 2017, 93:4285-4294.
    [3] 陈沛,段卫东,曾国伟,等.钛/钢爆炸焊接界面波形及缺陷组织的形成机理[J].爆破, 2019, 36(1):126-132 Chen Pei, Duan Weidong, Zeng Guowei, et al. Formation mechanism of interface waveform and defect microstructure in Ti/steel explosive welding[J]. Blasting, 2019, 36(1):126-132
    [4] Zhang M, Zhang T, Cai J Q, et al. Effect of heat treatment on microstucture and properties of explosive welding clad plate of TA1/Q345[J]. China Welding, 2018, 27(1):26-31.
    [5] Bataev I A, Bataev A A, Mali V I, et al. Structural and mechanical properties of metallic-intermetallic laminate composites produced by explosive welding and annealing[J]. Materials&Design, 2012, 35:225-234.
    [6] Fronczek D M, Wojewoda-Budka J, Chulist R, et al. Structural properties of Ti/Al clads manufactured by explosive welding and annealing[J]. Materials&Design, 2016, 91:80-89.
    [7] 范敏郁,郭训忠,崔圣强,等.钛/铝/钛三层板的一次爆炸复合[J].稀有金属材料与工程, 2017, 46(3):770-776 Fan Minyu, Guo Xunzhong, Cui Shengqiang, et al. One-step explosive bonding preparation of titanium/aluminum/titanium laminates with three layers[J]. Rare Metal Materials and Engineering, 2017, 46(3):770-776
    [8] 史长根,杨旋,候鸿宝,等.爆炸焊接两板间距上限法则分析与试验[J].焊接学报, 2018, 39(1):1-4 Shi Changgen, Yang Xuan, Hou Hongbao, et al. Analysis and experiment on upper limit law of two plates stands in explosive welding[J]. Transactions of the China Welding Institution, 2018, 39(1):1-4
    [9] Shi C G, Wang Y, Li S J, et al. Application and experiment on the least-action principle of explosive welding of stainless steel/steel[J]. Journal of Iron and Steel Research (International), 2014, 21(6):625-629.
    [10] Xia H B, Wang S G, Ben H F. Microstructure and mechanical properties of Ti/Al explosive cladding[J]. Materials&Design, 2014, 56:1014-1019.
    [11] Zhang L J, Pei Q, Zhang J X, et al. Study on the microstructure and mechanical properties of explosive welded 2205/X65 bimetallic sheet[J]. Materials&Design, 2014, 64:462-476.
    [12] 张婷婷,王文先,魏屹,等.钛/铝/镁爆炸焊复合板波形界面及力学性能[J].焊接学报, 2017, 38(8):33-36 Zhang Tingting, Wang Wenxian, Wei Yi, et al. Wavy interface and mechanical properties of explosive welded Ti/Al/Mg cladded plate[J]. Transactions of the China Welding Institution, 2017, 38(8):33-36
