非对称角根焊中焊枪偏移与熔透形态的关系

岳建锋, 许凯, 刘文吉, 沈振乾

岳建锋, 许凯, 刘文吉, 沈振乾. 非对称角根焊中焊枪偏移与熔透形态的关系[J]. 焊接学报, 2019, 40(9): 71-76. DOI: 10.12073/j.hjxb.2019400238
引用本文: 岳建锋, 许凯, 刘文吉, 沈振乾. 非对称角根焊中焊枪偏移与熔透形态的关系[J]. 焊接学报, 2019, 40(9): 71-76. DOI: 10.12073/j.hjxb.2019400238
shu
YUE Jianfeng, XU Kai, LIU Wenji, SHEN Zhenqian. Relationship between welding torch shift and penetration shape in asymmetrical root welding[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(9): 71-76. DOI: 10.12073/j.hjxb.2019400238
Citation: YUE Jianfeng, XU Kai, LIU Wenji, SHEN Zhenqian. Relationship between welding torch shift and penetration shape in asymmetrical root welding[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(9): 71-76. DOI: 10.12073/j.hjxb.2019400238
shu

非对称角根焊中焊枪偏移与熔透形态的关系

  • 天津工业大学 天津市现代机电装备技术重点实验室, 天津 300087

基金项目: 国家自然科学基金项目（U1733125）；天津市自然科学基金项目（17JCZDJC38700，18JCYBJC19100）

Relationship between welding torch shift and penetration shape in asymmetrical root welding

  • Key Laboratory of Modern Electromechanical Equipment Technology, Tianjin University of Technology, Tianjin 300087, China

摘要

    摘要
  • 摘要: 中厚板单侧开V形坡口角焊缝由于两侧结构不对称，根部焊接时散热差异大，易产生未熔合缺陷. 为保证根部打底焊良好熔透成形，提出根据正面熔池形貌变化实时调整焊枪角度的策略，提升焊接熔透质量. 结果表明，随着焊接角度变化，焊枪相对熔池发生了有规律位置偏移. 对采集到的正面熔池图像进行中值滤波等处理后获取焊枪中心的位置坐标，并研究了不同角度焊接的内部熔透形态，建立了熔池正面焊枪位置偏移量与内部熔透形态的定量关系，为利用正面熔池特征信息预测控制焊接内部熔透形态提供了一种新的方法.
    Abstract: Due to asymmetric structure on both sides of single side V-groove fillet weld of medium and thick plate, there is a great difference in heat dissipation during root welding, which is easy to produce incomplete fusion. In order to ensure a good penetration shape of root welding, the strategy of adjusting the welding torch angle in real time according to the changes of the front weld pool was proposed. The experimental results showed that the position of the torch shifted regularly relative to the welding pool with the change of welding angle. After median filtering and other processing on the acquired images of the front weld pool, the position coordinates of the welding torch center were obtained, and the internal penetration shape with different angles were studied. The quantitative relationship between the position offsets of the welding torch relative to the weld pool and the internal penetration shape were established. This provided a new method for predicting and controlling the internal penetration shape by using the feature information of the front weld pool.
    • HTML全文
    • 参考文献(10)
  • [1] 赵淑珍.提高管壳式换热器换热管与管板角接接头的焊接质量[J].中国特种设备安全, 2012, 28(1):40-42 Zhao Shuzhen. Enhancement of the welding quality of heat exchanger tube and tube plate angle joint[J]. China Special Equipment Safety, 2012, 28(1):40-42
    [2] 董庆.铝合金城轨车辆T型接头焊接缺陷分析及其超生波探测方法研究[J].电力机车与城轨车辆, 2014, 37(3):78-80 Dong Qing. Analysis of welding defects of T joint of aluminum alloy city track vehicle and Research on detection method of bounce wave[J]. Electric Locomotives&Mass Transit Vehicles, 2014, 37(3):78-80
    [3] Nakamura T, Hiraoka K, Takahashi M, et al. GMA welding process with periodically controlling shielding gas composition-Development of ultra-narrow gap GMA welding process[J]. Yosetsu Gakkai Ronbunshu, 2013, 20(2):237-245.
    [4] 张裕明,吴林,李林,等. TIG焊熔透正面监测量的确定[J].焊接学报, 1991, 12(1):39-45 Zhang Yuming, Wu Lin, Li Lin, et al. Determination of top supervision parameters for state of full penetration in TIG welding[J]. Transaction of the China Welding Institution, 1991, 12(1):39-45
    [5] 赵衍华,王溶溶,张芹梅,等.基于CCD视觉传感的铝合金熔透自动控制技术及其在航天贮存箱中的应用[J].航天制造技术, 2015(3):1-7 Zhao Yanhua, Wang Rongrong, Zhang Qinmei, et al. Full penetration automatic control of al alloy based on CCD sensing system and its application in aerospace tank[J]. Aerospace Manufacturing Technology, 2015(3):1-7
    [6] Baskoro AS, Kabutomori M, Suga Y. Automatic welding system of aluminum pipe by monitoring backside image of molten pool using vision sensor[J]. Journal of Solid Mechanics and Materials Engineering, 2008, 2(5):582-592.
    [7] Parvez S, Abid M, Nash D H, et al. Effect of torch angle on arc properties and weld pool shape in stationary GTAW[J]. Journal of Engineering Mechanics, 2013, 139(9):1268-1277.
    [8] 蒋凡,陈树君,王龙,等.焊枪行走角变化对等离子弧穿孔立焊焊缝成形的影响规律[J].焊接学报, 2013, 34(2):22-26 Jiang Fan, Chen Shujun, Wang Long, et al. Influence of welding torch walking angle variation on welding seam formation in plasma arc piercing vertical welding[J]. Transaction of the China Welding Institution, 2013, 34(2):22-26
    [9] 杨嘉佳,王克鸿,吴统立,等.铝合金双丝脉冲MIG焊双向熔池同步视觉传感及图像处理[J].机械工程学报, 2014, 50(12):44-50 Yang Jiajia, Wang Kehong, Wu Tongli, et al. Two-directional synchronous visual sensing and image processing of weld pool in aluminum alloy twin arc pulsed MIG welding[J]. Journal of Mechanical Engineering, 2014, 50(12):44-50
    [10] Zhang G, Fan D, Xue C, et al. PCNN based image processing and feature extraction of dual-bypass gas metal arc weld pool[J]. China Welding, 2013, 22(4):1-7.
