激光介入不锈钢自保护药芯焊丝MAG电弧堆焊熔滴受力分析

刘西洋, 杨淼森, 徐锴, 霍树斌, 刘满雨

刘西洋, 杨淼森, 徐锴, 霍树斌, 刘满雨. 激光介入不锈钢自保护药芯焊丝MAG电弧堆焊熔滴受力分析[J]. 焊接学报, 2019, 40(9): 65-70. DOI: 10.12073/j.hjxb.2019400237
引用本文: 刘西洋, 杨淼森, 徐锴, 霍树斌, 刘满雨. 激光介入不锈钢自保护药芯焊丝MAG电弧堆焊熔滴受力分析[J]. 焊接学报, 2019, 40(9): 65-70. DOI: 10.12073/j.hjxb.2019400237
LIU Xiyang, YANG Miaosen, XU Kai, HUO Shubin, LIU Manyu. Force analysis of droplet in MAG arc surfacing with stainless steel self-shielded cored wire as laser intervened[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(9): 65-70. DOI: 10.12073/j.hjxb.2019400237
Citation: LIU Xiyang, YANG Miaosen, XU Kai, HUO Shubin, LIU Manyu. Force analysis of droplet in MAG arc surfacing with stainless steel self-shielded cored wire as laser intervened[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(9): 65-70. DOI: 10.12073/j.hjxb.2019400237

激光介入不锈钢自保护药芯焊丝MAG电弧堆焊熔滴受力分析

基金项目: 国家重大科技专项(2018ZX06004001)

Force analysis of droplet in MAG arc surfacing with stainless steel self-shielded cored wire as laser intervened

  • 摘要: 以不锈钢自保护药芯焊丝为研究对象,借助高速摄像采集了激光介入MAG电弧堆焊的熔滴和电弧图像,研究了激光介入不锈钢自保护药芯焊丝MAG电弧堆焊的熔滴受力. 结果表明,激光的介入改变了焊丝端头熔化状态,焊丝端头发生局部熔化、半熔熔化、全熔熔化三种状态;增大了电磁收缩力、等离子流力在焊丝轴线上的分力,有利于熔滴过渡;减小了表面张力,有利于细化熔滴;增加了气体动力,在合适的激光参数下促进熔滴过渡;熔滴过渡轨迹出现了右偏轴过渡、左偏轴过渡、沿轴过渡三种模式.
    Abstract: Selecting the stainless steel self-shielded flux cored wire as research subject, the pictures of droplet and electric arc were taken using high-speed photography and force on the droplet was analyzed during MAG surfacing intervened by laser. The results showed that laser intervening changed melted state of end of the wire. The melted states were partial melting, half melting and dead melting. Laser intervening made electromagnetic pinch force and the components of plasma flow force in axial line of wire increase, which were beneficial to droplet transfer. Laser intervening made surface tension force reduce, which was beneficial to tessellate droplet. Laser intervening increased atmosphere dynamics and promoted droplet transfer in appropriate laser parameter. The track of droplet transfer had three patterns which were right shaft transfer, left shaft transfer and along the shaft transfer.
  • [1] Guo N, Fu Y, Feng J, et al. Classification of metal transfer mode in underwater wet welding[J]. Welding Journal, 2016, 95(4):133S-140S.
    [2] Wu C S, Yang F, Gao J, et al. Effect of external magnetic field on weld pool flow conditions in high-speed gas metal arc welding[J]. Proceedings of the Institution of Mechanical Engineers Part B Journal of Engineering Manufacture, 2016, 230(1):188-193.
    [3] 陈彦宾,冯杰才,李俐群.高强钢厚板激光-GMAW复合双面同步横焊特性研究[J].机械工程学报, 2016, 52(2):47-55 Chen Yanbin, Feng Jiecai, Li Liqun. Research on the characteristics of double-sided hybrid laser-gmaw synchronous horizontal welding of high-strength thick steel plates[J]. Journal of Mechanical Engineering, 2016, 52(2):47-55
    [4] 刘万强,李彦清,刘凤德,等.激光-电弧复合焊熔滴过渡的电磁收缩力研究[J].应用激光, 2016(2):188-192 Liu Wanqiang, Li Yanqing, Liu Fengde, et al. Study on force behavior of droplet transfer on laser-arc hybrid welding[J]. Applied Laser, 2016(2):188-192
    [5] 何双,陈辉,陈勇,等.激光功率对激光-MAG复合焊熔滴行为的影响[J].激光与光电子学进展, 2018, 55(02):021408 He Shuang, Chen Hui, Chen Yong, et al. Effect of laser power to droplet transfer of laser-MAG hybrid welding[J]. Laser&Optoelectronics Progress, 2018, 55(02):021408
    [6] 徐春鹰,刘双宇,张宏,等.激光-电弧复合焊过程的熔滴过渡特征与受力分析[J].机械工程学报, 2018, 54(6):154-161 Xu Chunying, Liu Shuangyu, Zhang Hong, et al. Study on the characteristics and mechanics of droplet transfer in laser arc hybrid welding process[J]. Journal of Mechanical Engineering, 2018, 54(6):154-161
    [7] 李敏,张旺,华学明,等.光纤激光与GMAW-P复合焊接等离子体及熔滴过渡动态特征研究[J].中国激光, 2017, 44(4):0402008 Li Min, Zhang Wang, Hua Xueming, et al. Investigation of plasma and metal transfer dynamic behavior during fiber laser GMAW-P hubrid welding[J]. Chinese Journal of Lasers, 2017, 44(4):0402008
    [8] 韩丽梅,蔡得涛,张宇鹏,等.光丝间距对304不锈钢激光-MIG复合焊接接头影响的研究[J].激光与光电子学进展, 2018, 55(6):061407 Han Limei, Cai Detao, Zhang Yupeng, et al. Influence of laser-arc distance on joint of 304 stainless steel by laser-MIG hybrid welding[J]. Laser&Optoelectronics Progress, 2018, 55(6):061407
    [9] 张晓枫,李桓,杨立军,等.激光功率对激光-双丝脉冲MIG复合焊接电弧形态及熔滴过渡的影响[J].焊接学报, 2014, 35(11):23-26 Zhang Xiaofeng, Li Huan, Yang Lijun, et al. Effect of laser power on arc behavior and metal transfer in laser-twin-wire pulsed MIG hybrid welding process[J]. Transaction of the China Welding Institution, 2014, 35(11):23-26
    [10] 韦辉亮,李桓,王旭友,等.激光-MIG电弧的复合作用及对熔滴过渡的影响[J].焊接学报, 2011, 32(11):41-44 Wei Huiliang, Li Huan, Wang Xuyou, et al. Hybrid interaction of laser and pulsed MIG arc and its influence on metal transfer[J]. Transaction of the China Welding Institution, 2011, 32(11):41-44
