TiZrNiCu钎焊(Cf-SiCf)/SiBCN与Nb的界面产物及机理分析

林盼盼, 杨佳, 步澜斌, 林铁松, 龙伟民

林盼盼, 杨佳, 步澜斌, 林铁松, 龙伟民. TiZrNiCu钎焊(Cf-SiCf)/SiBCN与Nb的界面产物及机理分析[J]. 焊接学报, 2019, 40(9): 7-13. DOI: 10.12073/j.hjxb.2019400227
引用本文: 林盼盼, 杨佳, 步澜斌, 林铁松, 龙伟民. TiZrNiCu钎焊(Cf-SiCf)/SiBCN与Nb的界面产物及机理分析[J]. 焊接学报, 2019, 40(9): 7-13. DOI: 10.12073/j.hjxb.2019400227
shu
LIN Panpan, YANG Jia, BU Lanbin, Lin Tiesong, LONG Weiming. Microstructure evolution and joining mechanism of brazing (Cf-SiCf)/SiBCN to Nb with TiZrNiCu[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(9): 7-13. DOI: 10.12073/j.hjxb.2019400227
Citation: LIN Panpan, YANG Jia, BU Lanbin, Lin Tiesong, LONG Weiming. Microstructure evolution and joining mechanism of brazing (Cf-SiCf)/SiBCN to Nb with TiZrNiCu[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(9): 7-13. DOI: 10.12073/j.hjxb.2019400227
shu

TiZrNiCu钎焊(Cf-SiCf)/SiBCN与Nb的界面产物及机理分析

  • 1.

    哈尔滨工业大学 先进焊接与连接国家重点试验室, 哈尔滨 150001

  • 2.

    郑州机械研究所 新型钎焊材料与技术国家重点试验室, 郑州 450001

基金项目: 战略性国际科技创新合作重点专项（2016YFE0201300）；国家自然科学基金青年科学基金项目（51805112）；河南省科技创新人才计划（174200510010）

Microstructure evolution and joining mechanism of brazing (Cf-SiCf)/SiBCN to Nb with TiZrNiCu

  • 1.

    State Key Laboratory of Advanced Welding and Joining, Harbin Institute of Technology, Harbin 150001, China

  • 2.

    State Key Laboratory of Advanced Brazing Filler Metals and Technology, Zhengzhou Research Institute of Mechanical Engineering, Zhengzhou 450001, China

摘要

    摘要
  • 摘要: 采用TiZrNiCu钎料来实现改良的超高温陶瓷（Cf-SiCf）/SiBCN与金属Nb的钎焊连接，研究了温度、时间对界面组织及力学性能的影响规律，对连接机理进行了分析. 结果表明，在900 ℃/20 min的工艺参数下，（Cf-SiCf）/SiBCN-Nb接头室温抗剪强度最高达到36 MPa，接头典型的界面结构为Nb/Ti-Nb固溶体/（Ti， Zr）2（Cu， Ni）/Zr5Si3 + Ti5Si3/TiC + ZrC/（Cf-SiCf）/SiBCN. Cu元素在钎焊过程中逐渐从钎料扩散陶瓷母材中，通过与SiC反应生成Cu-Si脆性化合物进一步促进（Cf-SiCf）/SiBCN陶瓷的分解，同时Cu-Si相是接头断裂路径由钎料层扩展到陶瓷侧的主要原因；保温时间过高时，陶瓷的分解程度增加，接头断裂在陶瓷内部；而温度过高时，固溶体前端与钎料层物相差异增大而引起了贯穿钎料层的裂纹.
    Abstract: In this work, TiZrNiCu was proposed to realize the joining of the improved high temperature ceramic (C f-SiCf)/SiBCN and Nb. The effects of brazing temperature and holding time on interface microstructure and mechanical properties were investigated, and the joining mechanism was detailed described. The joint shear strength reached maximum of 36 MPa at 900℃/20 min, in which typical interface structure was SiBCN/TiC+ZrC/Ti 5Si3 +Zr 5Si3/(Ti,Zr) 2 (Cu,Ni)/(Ti-Nb)ss/Nb. During the brazing process, Cu-Si brittle compounds were formed in the ceramic by infiltration of Cu into the (C f-SiCf)/SiBCN, responsible for the fracture path extended from the solder layer to the ceramic side in most cases. When the holding time was 30 min, the joint was directly broken on the ceramic base material due to the excessive penetration effect of Cu; at excessive temperature, the fracture occured in the filler, since the large difference between the (Ti-Nb)ss and the solder materials.
    • HTML全文
    • 参考文献(11)
  • [1] Weinmann M, Schuhmacher J. Synthesis and thermal behavior of novel Si-B-C-N ceramic precursors[J]. Chemistry of Materials, 2000, 12(3):623-632.
    [2] 潘丽君. Cf表面涂层及Cf/SiBCN复合材料制备与性能[D].哈尔滨:哈尔滨工业大学, 2012.
    [3] Menon E S K, Mendiratta M G. High temperature oxidation in multicomponent Nb alloys[J]. Materials Science Forum, 2005, 475-479(50):717-720.
    [4] Pan R, Kovacevic S, Lin T. Control of residual stresses in 2Si-B-3C-N and Nb joints by the Ag-Cu-Ti+Mo composite interlayer[J]. Materials&Design, 2016, 99:193-200.
    [5] Halbig M C. Diffusion bonding of SiC fiber-bonded ceramics using Ti/Mo and Ti/Cu interlayers[J]. Ceramics International, 2015, 41:2140-2149.
    [6] Yang W, Xing L, Lin T, et al. Microstructural evolution and growth/degradation behavior of in situ TiB whiskers in ZrB2-SiC joints using Ti/Ni/Ti filler[J]. Journal of Alloys&Compounds, 2018, 744:124-131.
    [7] Hui Y. Thickness-dependent phase evolution and bonding strength of SiC ceramics joints with active Ti interlayer[J]. Journal of the European Ceramic Society, 2017, 37:1233-1243.
    [8] 宋雪,张玲. Ti-Ni钎焊Cf/SiBCN陶瓷接头界面组织及机理分析[J].焊接学报, 2017, 38(3):79-83 Song Xue, Zhang Ling. Interfacial microstructure and mechanism analysis of Ti-Ni brazed Cf/SiBCN ceramic joints[J]. Transactions of the China Welding Institution, 2017, 38(3):79-83
    [9] Zhao S T, Zhang X Z, Liu G W, et al. Wetting and interfacial behavior of molten Cu on Co-Si (-Mo) coated SiC[J]. Ceramics International, 2015, 41(10):13493-13501.
    [10] 冯吉才,张丽霞,曹健.陶瓷与金属的连接技术.上册[M].北京:科学出版社, 2016.
    [11] 聂耀庄,谢佑卿,彭红建,等. Zr5Si3及Zr3Ti2Si3弹性性质与热学性质[J].中国有色金属学报, 2007, 17(9):1495-1500 Nie Yaozhuang, Xie Youqing, Peng Hongjian, et al. Elastic and thermal properties of Zr5Si3 and Zr3Ti2Si3[J]. Journal of Chinese Nonferrous Metals, 2007, 17(9):1495-1500
