基于温度函数法的铝合金电弧增材制造残余应力与变形数值模拟
Numerical simulation on residual stress and deformation for WAAM parts of aluminum alloy based on temperature function method
-
摘要: 电弧增材制造是制造大型复杂铝合金部件的新方法，但残余应力和变形对制造件的性能有重要影响. 建立了铝合金电弧增材制造件残余应力和变形的顺序热-力耦合有限元模型，采用移动热源法计算了增材过程的温度场，根据峰值温度的分布和演变特征确定了温度函数的提取方案，并分别采用移动热源法和温度函数法进行了残余应力和变形计算.结果表明，1段，3段，5段温度函数法分别将力学分析时间缩短91%，79%，63%，残余应力和基板变形误差均在20%以内，在满足计算精度的前提下显著提高了计算效率，为大型铝合金电弧增材制造件残余应力与变形的预测提供了途径.Abstract: Wire arc additive manufacture (WAAM) is a new way to fabricate large-scale complex aluminum alloy components, but the performance of the parts is critically influenced by residual stresses and deformation. A sequentially thermal-mechanical coupled model of residual stress and deformation for aluminum alloy WAAM parts was established based on commercial FE software ABAQUS. The temperature field was calculated by the moving heat source (MHS) method. The temperature function was obtained according to the distribution of the peak temperature. Furthermore, the MHS method and segmented temperature function (STF) method were used to calculate the residual stress and deformation. The results show that the STF method satisfies both the efficiency and accuracy requirements. 1-segment, 3-segment, and 5-segment STF methods can shorten the time for mechanical analysis by 91%, 79%, 63%, respectively. The error of the residual stress and deformation are all less than 20%. STF method provides an effective way to predict the residual stress and deformation of large-scale WAAM parts.
-
-
[1] Debroy T, Wei H, Zuback J, et al. Additive manufacturing of metallic components-process, structure and properties[J]. Progress in Materials Science, 2017, 92:112-224. [2] Sames W J, List F A, Pannala S, et al. The metallurgy and processing science of metal additive manufacturing[J]. International Materials Reviews, 2016, 61(5):1-46. [3] Yang Q, Pu Z, Lin C, et al. Finite element modeling and validation of thermomechanical behavior of Ti-6Al-4V in directed energy deposition additive manufacturing[J]. Additive Manufacturing, Part B, 2016, 12:169-177. [4] Dunbar A J, Denlinger E R, Heigel J, et al. Development of experimental method for in situ distortion and temperature measurements during the laser powder bed fusion additive manufacturing process[J]. Additive Manufacturing, Part A, 2016, 12:25-30. [5] Biegler M, Graf B, Rethmeier M. In-situ distortions in LMD additive manufacturing walls can be measured with digital image correlation and predicted using numerical simulations[J]. Additive Manufacturing, 2018, 20:101-110. [6] Xie R, Zhao Y, Chen G, et al. The full-field strain distribution and the evolution behavior during additive manufacturing through in-situ observation[J]. Materials&Design, 2018, 150:49-54. [7] Michaleris P. Modeling metal deposition in heat transfer analyses of additive manufacturing processes[J]. Finite Elements in Analysis and Design, 2014, 86(13):51-60. [8] Ding J, Colegrove P, Mehnen J, et al. Thermo-mechanical analysis of wire and arc additive layer manufacturing process on large multi-layer parts[J]. Computational Materials Science, 2011, 50(12):3315-3322. [9] Ding J, Colegrove P, Mehnen J, et al. A computationally efficient finite element model of wire and arc additive manufacture[J]. The International Journal of Advanced Manufacturing Technology, 2014, 70(1-4):227-236. [10] 陈嵩涛,段庆林,王依宁,等.选区激光烧结过程传热分析的高效无网格法[J].机械工程学报, 2019, 55(7):135-146 Chen Songtao, Duan Qinglin, Wang Yining, et al. Efficient meshfree method for heat conduction in selective laser sintering process[J]. Journal of Mechanical Engineering, 2019, 55(7):135-146 [11] Michaleris P, Zhang L, Bhide S R, et al. Evaluation of 2D, 3D and applied plastic strain methods for predicting buckling welding distortion and residual stress[J]. Science and Technology of Welding and Joining, 2006, 11(6):707-716. [12] 鄢东洋,史清宇,吴爱萍,等.焊接数值模拟中以温度为控制变量的高效算法[J].焊接学报, 2009, 30(8):77-80 Yan Dongyang, Shi Qingyu, Wu Aiping, et al. A high-efficiency welding simulation method based on welding temperature[J]. Transactions of the China Welding Institution, 2009, 30(8):77-80 [13] 李艳军,吴爱萍,刘德博,等. 2219铝合金VPTIG焊接残余应力的数值分析[J].清华大学学报自然科学版, 2016(10):1037-1041 Li Yanjun, Wu Aiping, Liu Debo, et al. Numerical simulation of welding residual stresses in VPTIG joints of the 2219 aluminum alloy[J]. Journal of Tsinghua University (Science and Technology), 2016(10):1037-1041 -
