高强韧CuZnNiMn纽扣钎料钎焊截齿接头组织与性能

秦建, 董显, 裴夤崟, 路全彬, 韩晓辉

秦建, 董显, 裴夤崟, 路全彬, 韩晓辉. 高强韧CuZnNiMn纽扣钎料钎焊截齿接头组织与性能[J]. 焊接学报, 2019, 40(8): 96-103. DOI: 10.12073/j.hjxb.2019400215
引用本文: 秦建, 董显, 裴夤崟, 路全彬, 韩晓辉. 高强韧CuZnNiMn纽扣钎料钎焊截齿接头组织与性能[J]. 焊接学报, 2019, 40(8): 96-103. DOI: 10.12073/j.hjxb.2019400215
shu
QIN Jian, DONG Xian, PEI Yinyin, LU Quanbin, HAN Xiaohui. Micro-structure and properties of mining bit brazing joint employed by the high strength and ductility CuZnNiMn button materials[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(8): 96-103. DOI: 10.12073/j.hjxb.2019400215
Citation: QIN Jian, DONG Xian, PEI Yinyin, LU Quanbin, HAN Xiaohui. Micro-structure and properties of mining bit brazing joint employed by the high strength and ductility CuZnNiMn button materials[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(8): 96-103. DOI: 10.12073/j.hjxb.2019400215
shu

高强韧CuZnNiMn纽扣钎料钎焊截齿接头组织与性能

  • 1.

    郑州机械研究所有限公司 新型钎焊材料与技术国家重点实验室, 郑州 450001

  • 2.

    中车青岛四方机车车辆股份有限公司, 青岛 266111

基金项目: 国家重点研发计划（战略性国际科技创新合作重点专项）2016YFE0201300

Micro-structure and properties of mining bit brazing joint employed by the high strength and ductility CuZnNiMn button materials

  • 1.

    State Key Laboratory of Advanced Brazing Filler Metals & Technology, Zhengzhou Research Institute of Mechanical Engineering, Zhengzhou 450001, China

  • 2.

    CRRC Qiangdao Sifang Co., LTD., Qiangdao 266111, China

摘要

    摘要
  • 摘要: 针对采煤、掘进机械用截齿，采用短流程方式制备了Cu-Zn-Ni-Mn纽扣型钎料.使用制备的纽扣型钎料，采用高频感应方式完成了实际产品的焊接.焊后分别对焊接接头的宏观形貌、剪切性能、剪切断口形貌、钎焊界面组织及成分进行分析.结果表明，制备的纽扣型钎料能够良好的润湿钢基体和硬质合金，钎焊填缝率达到100%；钎焊接头剪切强度260 MPa以上，剪切形貌为典型的韧窝状韧性断裂.在钢基体-钎料侧，Fe原子与Co原子出现长程扩散，形成Fe基固溶体和Fe-Co-Ni单相固溶体，钎料-硬质合金侧界面的强度依靠钎料向硬质合金内部的扩散与Co元素的固溶获得.
    Abstract: Cu-Zn-Ni-Mn button brazing filler metal was prepared in this paper for mining bit of coal mining and tunneling machines. The welding of the actual product was accomplished by high frequency induction method using the button type brazing filler metal. The macroscopic morphology, shear performance, shear fracture morphology, microstructure and composition of brazing interface were analyzed after brazing. The experimental results show that the filler material can wet the steel matrix and hard alloy well, and the brazing rate reached 100%. The shear strength of the brazed joint reached 270 MPa and the shear morphology shown as typical dimple ductile fracture. At the interface of steel-base solder and cemented carbide, Fe atoms and Co atoms appeared long-term diffusion. The solid solution of Fe base and single phase solid solution of Fe-Co-Ni were formed, which ensures the good strength and toughness of the brazing interface.
    • HTML全文
    • 参考文献(10)
  • [1] 樊润君,朱庆霞.截齿的钎焊工艺[J].金属加工热加工, 2012(8):69-70 Fan Runjun, Zhu Qingxia. Brazing process of minning bit[J]. Metal Working, 2012(8):69-70
    [2] 马淑梅,熊斌.钎缝间隙对截齿钎焊接头抗剪强度的影响[J].热加工工艺, 2014, 43(9):188-190 Ma Shumei, Xiong Bin. Effect of brazing clearance on shearing strength of cutter bit brazed joint[J]. Hot Working Technology, 2014, 43(9):188-190
    [3] 翟秋亚,徐锦锋,蔡再生.细直径YG5FA硬质合金/45Cr钢储能焊工艺分析[J].焊接学报, 2007, 28(8):13-16 Zhai Qiuya, Xu Jinfeng, Cai Zaisheng. Microstructure of small diameter cemented carbide YG5FA/45Cr steel joined by capacitor discharge welding[J]. Transactions of the China Welding Institution, 2007, 28(8):13-16
    [4] 李卓然,刘兵,樊建新,等. YG8硬质合金和低碳钢的高频感应钎焊[J].焊接学报, 2010, 31(10):97-100 Li Zhuoran, Liu Bing, Fan Jianxin. High-frequency induction brazing of YG8 sintered-carbide to mildsteel[J]. Transactions of the China Welding Institution, 2010, 31(10):97-100
    [5] 曲仕尧,王新洪,邹增大. WC硬质合金颗粒堆焊烧损的机理[J].焊接学报, 2001, 22(2):85-88 Qu Shiyao, Wang Xinhong, Zou Zengda. The heat damage mechanism of WC cemented carbide for hardfacing[J]. Transactions of the China Welding Institution, 2001, 22(2):85-88
    [6] Xue Songbai, Qian Yiyu, Hu Xiaoping. Behavior and influence of Pb and Bi in Ag-Cu-Zn brazing alloy[J]. China Welding, 2000, 20(1):42-45.
    [7] 阙仲萍,王海龙. YG8硬质合金与42CrMo钢的真空钎焊连接[J].机械工程材料, 2009, 33(2):35-38 Que Zhongping, Wang Hailong. Vacuum brazing of 42CrMo steel and YG8 hard alloy[J]. Materials for Mechanical Engineering, 2009, 33(2):35-38
    [8] 瞿智明,张福勤,夏莉红. Cu基钎料钎焊紫铜的接头力学性能和微观组织[J].粉末冶金材料科学与工程, 2015, 20(1):133-138 Qu Zhiming, Zhang Fuqin, Xia Lihong. Mechanical properties and microstructure of copper brazing using Cu-based alloy as filler[J]. Materials Science and Engineering of Powder Metallurgy, 2015, 20(1):133-138
    [9] 顾天亮,闫焉服,张绍棋.锰元素对铜基CuZnNi合金钎料性能的影响[J].机械工程材料, 2017, 41(9):81-84 Gu Tianliang, Yan Yanfu, Zhang Shaoqi. Effect of Mn element on properties of copper-based CuZnNi alloy brazing filler[J]. Materials for Mechanical Engineering, 2017, 41(9):81-84
    [10] 龙伟民,张冠星,张青科,等.钎焊过程原位合成高强度银钎料[J].焊接学报, 2015, 36(11):1-4 Long Weimin, Zhang Guanxing, Zhang Qingke, et al. In-situ synthesis of high strength Ag brazing filler metals during brazing process[J]. Transactions of the China Welding Institution, 2015, 36(11):1-4
