高温蠕变下表面多裂纹扩展行为

郭威, 赵雷, 徐连勇, 韩永典

郭威, 赵雷, 徐连勇, 韩永典. 高温蠕变下表面多裂纹扩展行为[J]. 焊接学报, 2019, 40(8): 44-49. DOI: 10.12073/j.hjxb.2019400207
引用本文: 郭威, 赵雷, 徐连勇, 韩永典. 高温蠕变下表面多裂纹扩展行为[J]. 焊接学报, 2019, 40(8): 44-49. DOI: 10.12073/j.hjxb.2019400207
shu
GUO Wei, ZHAO Lei, XU Lianyong, HAN Yongdian. The analysis of multiple surface cracks growth behavior under the interaction of creep cracks[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(8): 44-49. DOI: 10.12073/j.hjxb.2019400207
Citation: GUO Wei, ZHAO Lei, XU Lianyong, HAN Yongdian. The analysis of multiple surface cracks growth behavior under the interaction of creep cracks[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(8): 44-49. DOI: 10.12073/j.hjxb.2019400207
shu

高温蠕变下表面多裂纹扩展行为

  • 天津大学, 天津 300072;天津市现代连接技术重点实验室, 天津 300072

基金项目: 国家自然科学基金资助项目（51505328）

The analysis of multiple surface cracks growth behavior under the interaction of creep cracks

  • Tianjin University, Tianjin 300072, China;Tianjin Key Laboratory of Advanced Joining Technology, Tianjin 300072, China

摘要

    摘要
  • 摘要: 文中将蠕变损伤模型编写到USDFLD用户子程序中，利用有限元分析软件ABAQUS，通过单元失效技术模拟了表面多裂纹干涉条件下裂纹扩展行为.探究了不同裂纹尺寸、残余应力对高温蠕变表面多裂纹干涉效应及裂纹扩展行为的影响.结果表明，表面裂纹形状比、裂纹深度的增大和裂纹间距离的减小，加强了表面多裂纹之间的干涉效应并促进多裂纹的扩展，而残余应力的存在同样加速了裂纹扩展.基于裂纹扩展速率提出了蠕变下表面多裂纹合并准则，即当蠕变干涉因子超过1.27，应当考虑多裂纹的合并，否则多裂纹仍按照单裂纹处理.
    Abstract: The damage model was implemented into user subroutine of commercial ABAQUS code to calculate the damage accumulation in each time interval and to simulate the crack growth. The influence of crack configurations and residual stress on crack growth behavior in the presence of multiple surface cracks were studied through the variation of crack growth rate. With the relative surface crack sizes (a/t, a/c,) become larger and the distance between two cracks (s/c) becomes close, the interaction between two surface cracks were enhanced and the crack growth behavior was improved. Besides, the existence of residual tensile stress also accelerated the crack growth rate. According to the change of crack growth rates, the critical value of γcreep for combination of multiple creep surface cracks was assumed to be 1.27. As γcreep ≥ 1.27 two interacting cracks should be considered to combine into a new big crack otherwise they can be treated as isolated cracks, respectively.
    • HTML全文
    • 参考文献(12)
  • [1] Kamaya M, Miyokawa E, Kikuchi M. Growth prediction of two interacting surface cracks of dissimilar sizes[J]. Engineering Fracture Mechanics, 2010, 77(16):3120-3131.
    [2] Si J, Xuan F Z, Tu S T. A numerical creep analysis on the interaction of twin semi-elliptical cracks[J]. International Journal of Pressure Vessels and Piping, 2008, 85(7):459-467.
    [3] Xuan F Z, Si J, Tu S T. Rules for the assessment of interacting cracks under creep conditions[J]. Journal of Pressure Vessel Technology, 2010, 132(1):17-23.
    [4] Xu L, Zhao L, Jing H, et al. Evaluation of multiple cracks interaction effect subjected to biaxial tension under creep regime[J]. International Journal of Mechanical Sciences, 2017, 122:203-214.
    [5] Jiao Fujie, Zhang Wenjun, Yuan Zhikang. Nondestructive test of weld residual stresses by acoustoelastic technique[J]. China Welding, 1994, 3(1):45-52.
    [6] 张星.残余应力作用下P92钢蠕变裂纹扩展研究[D].天津:天津大学, 2010.
    [7] 许万剑,杨春丽,赵宏柱,等. 304不锈钢焊管应力腐蚀开裂原因[J].腐蚀与防护, 2014, 35(5):511-513 Xu Wanjian, Yang Chunli, Zhao Hongzhu, et al. Analysis on stress corrosion cracking of welded stainless steel pipe[J]. Corrosion&Protection, 2014, 35(5):511-513
    [8] 赵雷.考虑拘束效应的高温下含缺陷P92管道寿命评估方法研究[D].天津:天津大学, 2012.
    [9] 张文,荆洪阳,徐连勇.含埋藏球形缺陷管道蠕变裂纹萌生寿命的预测[J].焊接学报, 2017, 38(2):75-78 Zhang Wen, Jing Hongyang, Xu Lianyong. Prediction of creep crack initiation time in steel pipes with embedded spherical defects[J]. Transactions of the China Welding Institution, 2017, 38(2):75-78
    [10] Yatomi M, Davies C M, Nikbin K M. Creep crack growth simulations in 316H stainless steel[J]. Engineering Fracture Mechanics, 2008, 75(18):5140-5150.
    [11] 汪建华,陆皓,魏良武.固有应变有限元法预测焊接变形理论及其应用[J].焊接学报, 2002, 23(6):36-40 Wang Jianhau, Lu Hao, Wei Liangwu. Prediction of welding distortions based on theory of inherent strain by FEM and its application[J]. Transactions of the China Welding Institution, 2002, 23(6):36-40
    [12] 梁伟,周亮,孙晓露,等.采用固有应变法预测超薄板的焊接变形[J].焊接学报, 2017, 38(3):103-106 Liang Wei, Zhou Liang, Sun Xiaoxia, et al. Prediction of the welding deformation of ultra-thin plates based on theory of inherent strain[J]. Transactions of the China Welding Institution, 2017, 38(3):103-106
