CO<sub>2</sub>焊的负载伏安动特性及焊缝成形比较分析

翟培卓; 薛松柏; 孙子建; 陈涛; 陈卫中

doi:10.12073/j.hjxb.2019400205

CO₂焊的负载伏安动特性及焊缝成形比较分析

1.
南京航空航天大学, 南京 211106
2.
昆山华恒焊接股份有限公司, 昆山 215347

基金项目: 国家自然科学基金资助项目（51675269）；新型钎焊材料与技术国家重点实验室开放课题基金资助（SKLABFMT201704）；江苏高校优势学科建设工程资助项目

计量
- 文章访问数: 376
- HTML全文浏览量: 11
- PDF下载量: 58
出版历程
- 收稿日期: 2018-08-01

Comparative study on load voltage-ampere characteristic and seam quality of CO₂ arc welding

1.
Nanjing University of Aeronautics and Astronautics, Nanjing 211106, China
2.
Kunshan Huaheng Welding Co., Ltd., Kunshan 215347, China

摘要

摘要: 在CO₂焊短路过渡过程中，针对“电源-电弧-液桥”系统的动态特征行为，提出了负载伏安动特性曲线和单周期负载伏安动特性曲线的概念，统一了不同文献的表述.研究了三款不同焊机在相同的焊接条件和参数下负载伏安动特性曲线的差异，并与这三种焊机焊后的焊缝成形质量进行了比较分析.结果表明，负载伏安动特性曲线越向原点聚拢，焊接的飞溅程度就越小；若曲线的重复度越好，则焊接过程就越稳定，焊缝成形越美观.但是如果曲线围成的面积过大，引起未熔合等焊接缺陷可能性就会增大，同时焊缝的不对称程度增加.
- 电压电流曲线 /
- 短路过渡 /
- 焊缝成形质量
Abstract: In the short-circuiting transfer process of CO₂ arc welding, the concept of load voltage-ampere characteristic curve and single cycle load voltage-ampere characteristic curve were put forward in view of the dynamic characteristic behavior of "power-arc-liquid bridge" system, which integrated the expression of different references. Under same welding conditions and parameters, the difference of load voltage-ampere characteristic curve among three welding machines were studied and their welding seam qualities were compared. The results shown that if the load voltage-ampere characteristic curve was closer to the origin of coordinate, welding spatter degree would be smaller. Additionally, the better repeatability of the curve waa, the more stable welding process and the more beautiful welding seam would be. However, if the area enclosed by curves was too large, the possibility of welding defects, such as incomplete fusion and asymmetry of welding seam, would increase.
- voltage-current curve /
- short-circuiting transfer /
- welding seam quality

HTML全文

参考文献(11)

[1]	Kim I S, Son J S, Kim I G, et al. A study on relationship between process variables and bead penetration for robotic CO₂ arc welding[J]. Journal of Materials Processing Technology, 2003, 136(1-3):139-145.
[2]	Kah P, Suoranta R, Martikainen J. Advanced gas metal arc welding processes[J]. The International Journal of Advanced Manufacturing Technology, 2013, 67(1-4):655-674.
[3]	李桓,李俊岳,杨立军,等. CO₂气体保护焊短路过渡过程的闭环实时控制[J].焊接学报, 2001, 22(1):27-30 Li Huan, Li Junyue, Yang Lijun, et al. The closed-loop real-time controlling of short-circuiting transfer in CO₂ arc welding[J]. Transactions of the Chinese Welding Institution, 2001, 22(1):27-30
[4]	Era T, Ueyama T, Hirata Y. Spatter reduction in gas metal arc welding of stainless steel sheets using controlled bridge transfer process[J]. Science and Technology of Welding and Joining, 2009, 14(8):708-716.
[5]	Zhenmin W, Jiaxiang X, Fei D, et al. An analysis of the dynamic resistance and the instantaneous energy of the CO₂ arc welding process[J]. China Welding, 2007, 16(1):77-82.
[6]	Li R, Lei X, Zhou P. Analysis of welding defects in spot welding process U-I curves[C]//2009 Third International Conference on Genetic and Evolutionary Computing. IEEE, 2009:201-204.
[7]	Kolasa A, Matsunawa A, Arata Y. Dynamic characteristics of variable frequency pulsed TIG arc (welding physics, process&instrument)[J]. Transactions of JWRI, 1986, 15(2):173-177.
[8]	张晓囡. CO₂弧焊电源动特性评定新方法的研究[D].广州:华南理工大学, 1999.
[9]	黄石生,王金祥,蒋志林.电弧为动态模型的电弧焊逆变器的仿真[J].机械工程学报, 1996, 32(4):79-82 Huang Shisheng, Wang Jinxiang, Jiang Zhilin. Simulation on arc welding inverter containing dynamic arc model[J]. Journal of Mechanical Engineering, 1996, 32(4):79-82
[10]	余文松,薛家祥,黄石生,等. CO₂电弧焊动态过程的MATLAB仿真研究[J].焊接学报, 1999, 20(3):153-157 Yu Wensong, Xue Jiaxiang, Huang Shisheng, et al. Simulation study on dynamic process of CO₂ arc welding with MATLAB[J]. Transactions of the Chinese Welding Institution, 1999, 20(3):153-157
[11]	陈茂爱,蒋元宁,武传松.受控短路过渡CO₂焊焊接电流波形参数优化[J].焊接学报, 2014, 35(7):79-82 Chen Maoai, Jiang Yuanning, Wu Chuansong. Optimization of welding current waveform parameters in controlled short circuiting transfer GMAW[J]. Transactions of the Chinese Welding Institution, 2014, 35(7):79-82
