Ti/Cu异种金属电子束焊接界面行为

郭顺, 罗添元, 彭勇, 周琦, 朱军

郭顺, 罗添元, 彭勇, 周琦, 朱军. Ti/Cu异种金属电子束焊接界面行为[J]. 焊接学报, 2019, 40(8): 26-32. DOI: 10.12073/j.hjxb.2019400204
引用本文: 郭顺, 罗添元, 彭勇, 周琦, 朱军. Ti/Cu异种金属电子束焊接界面行为[J]. 焊接学报, 2019, 40(8): 26-32. DOI: 10.12073/j.hjxb.2019400204
shu
GUO Shun, LUO Tianyuan, PENG Yong, ZHOU Qi, ZHU Jun. Interface behavior and mechanical properties of Ti/Cu dissimilar metals welding by electron beam[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(8): 26-32. DOI: 10.12073/j.hjxb.2019400204
Citation: GUO Shun, LUO Tianyuan, PENG Yong, ZHOU Qi, ZHU Jun. Interface behavior and mechanical properties of Ti/Cu dissimilar metals welding by electron beam[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(8): 26-32. DOI: 10.12073/j.hjxb.2019400204
shu

Ti/Cu异种金属电子束焊接界面行为

  • 1.

    南京理工大学, 南京 210094

  • 2.

    中车长春轨道客车股份有限公司, 长春 130000

  • 3.

    南京工程学院, 南京 211167

基金项目: 国家自然科学基金资助项目（51805265，51505226）

Interface behavior and mechanical properties of Ti/Cu dissimilar metals welding by electron beam

  • 1.

    Nanjing University of Science and Technology, Nanjing 210094, China

  • 2.

    CRRC Changchun Railway Vehicles Co., Ltd., Changchun 130000, China

  • 3.

    Nanjing Institute of Technology, Nanjing 211167, China

摘要

    摘要
  • 摘要: 为了获得高强度T2铜和Ti-6Al-4V钛合金异种金属接头，采用电子束焊方法开展试验，并对接头界面组织及力学性能进行了分析.试验在钛/铜熔钎焊接基础上，通过在高熔点钛侧复合二次焊接，构建钛/铜结合界面金属间化合物层的重熔温度场，进而实现钛/铜金属间化合物层的重熔改性.通过有限元温度场模拟及SEM，XRD等检测.结果表明，钛侧重熔焊接可在结合界面处形成1 000℃左右高温，金属间化合物层发生局域重熔.在随后凝固过程中，由于散热方向及元素再分配，相的形成顺序发生改变，钛原子向铜侧的扩散距离减短，高硬度相TiCu向Ti2Cu转变，相结构优化，最终接头强度得以提升.
    Abstract: In order to obtain high-strength dissimilar metals joints of T2 copper and Ti-6Al-4V titanium alloy, electron beam welding was used to carry out experiments, and the interfacial microstructure and mechanical properties of the joints were analyzed. Based on the Ti/Cu welding-brazing process, the remelting temperature field of intermetallic compounds layer at the Ti/Cu bonding interface was constructed by secondary composite welding on the Ti side of high melting point, and then the remelting modification of Ti/Cu intermetallic compounds layer was realized. By temperature field simulation of FEM and detection of SEM, XRD, the results shown that a high temperature of about 1 000℃ at the interface was formed by remelting welding at titanium side, leading to local remelting of intermetallic compound layer. In the process of solidification, due to the direction of heat dissipation and the redistribution of elements, the formation sequence of the phase was changed, the diffusion distance of titanium atoms was reduced and TiCu with high hardness was transformed to Ti2Cu. The phase structure was optimized and finally the strength of the welded joints improved.
    • HTML全文
    • 参考文献(15)
  • [1] Chen S, Li L, Chen Y, et al. Improving interfacial reaction nohomogeneity during laser welding-brazing aluminum to titanium[J]. Materials&Design, 2011, 32(32):4408-4416.
    [2] Hosseini M, Manesh H D. Bond strength optimization of Ti/Cu/Ti clad composites produced by roll-bonding[J]. Materials&Design, 2015, 81(15):122-132.
    [3] Lin S B, Song J L, Yang C L, et al. Experimental study on dissimilar TIG welding-brazing of 5A06 aluminum alloy to SUS321 stainless steel[J]. China Welding, 2010, 19(1):26-31.
    [4] Guo S, Zhou Q, Kong J, et al. Effect of beam offset on the characteristics of copper/304stainless steel electron beam welding[J]. Vacuum, 2016, 128:205-212.
    [5] Aydın K, Kaya Y, Kahraman N. Experimental study of diffusion welding/bonding of titanium to copper[J]. Materials&Design, 2012, 37:356-368.
    [6] Cao R, Feng Z, Lin Q, et al. Study on cold metal transfer welding-brazing of titanium to copper[J]. Materials&Design, 2014, 56(4):165-173.
    [7] 王亚荣,滕文华,余洋,等.铝/钛异种金属的电子束熔钎焊[J].机械工程学报, 2012, 48(20):88-92 Wang Yarong, Teng Wenhua, Yu Yang, et al. Electron beam welding-brazing of Al/Ti dissimilar alloys[J]. Journal of Mechanical Engineering, 2012, 48(20):88-92
    [8] Shmorgun V G, Gurevich L M, Slautin O V, et al. Formation of Ti-Cu-Based intermetallic coatings on the surface of copper during contact melting[J]. Metallurgist, 2016:1-6.
    [9] Guo S, Zhou Q, Peng Y, et al. Study on strengthening mechanism of Ti/Cu electron beam welding[J]. Materials&Design, 2017, 121(5):51-60.
    [10] Guo S, Zhou Q, Peng Y, et al. Study on strengthening mechanism of Ti/Cu electron beam weiding[J]. Materials&Design, 2017, 121:51-60.
    [11] 赵海生. QCr0.8/TC4异种材料电子束焊接工艺研究[D].哈尔滨:哈尔滨工业大学, 2007.
    [12] 刘伟,陈国庆,张秉刚,等.铜/钛合金电子束焊接工艺优化[J].焊接学报, 2008, 29(5):92-95, 120 Liu Wei, Chen Guoqing, Zhang Binggang, et al. Investigation on process optimization of Cu Ti electron beam welding[J]. Transactions of the China Welding Institution, 2008, 29(5):92-95, 120
    [13] 刘伟,赵海生,何景山,等. QCr0.8/TC4薄板电子束焊接头组织及断裂路径[J].焊接学报, 2007, 28(8):81-84 Liu Wei, Zhao Haisheng, He Jingshan, et al. Microstructure and fracture path of electron beam welded joint of QCr0.8/TC4 sheet[J]. Transactions of the China Welding Institution, 2007, 28(8):81-84
    [14] 刘伟,陈国庆,张秉刚,等.电子束焊接QCr0.8/TC4焊缝反应层结构及成长分析[J].焊接学报, 2008, 29(4):88-91 Liu Wei, Chen Guoqing, Zhang Binggang, et al. Analysis of structure and growth of QCr0.8/TC4 welded reaction layer by electron beam welding[J]. Transactions of the China Welding Institution, 2008, 29(4):88-91
    [15] 张秉刚,王廷,陈国庆,等.钛合金与铬青铜电子束自熔钎焊接头组织与力学性能[J].稀有金属材料与工程, 2012, 41(1):129-133 Zhang Binggang, Wang Ting, Chen Guoqing, et al. Microstructure and mechanical property of electron beam self-melting brazing joint of titanium alloy to chromium bronze[J]. Rare Metal Materials and Engineering, 2012, 41(1):129-133
