压痕应变法应力计算函数和低合金钢力学性能的关系

陈静, 阚盈, 姜云禄, 陈怀宁

陈静, 阚盈, 姜云禄, 陈怀宁. 压痕应变法应力计算函数和低合金钢力学性能的关系[J]. 焊接学报, 2019, 40(7): 133-138. DOI: 10.12073/j.hjxb.2019400195
引用本文: 陈静, 阚盈, 姜云禄, 陈怀宁. 压痕应变法应力计算函数和低合金钢力学性能的关系[J]. 焊接学报, 2019, 40(7): 133-138. DOI: 10.12073/j.hjxb.2019400195
shu
CHEN Jing, KAN Ying, JIANG Yunlu, CHEN Huaining. Relationship between stress calculation function of indentation strain-gage and mechanical properties of low-alloy steel[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(7): 133-138. DOI: 10.12073/j.hjxb.2019400195
Citation: CHEN Jing, KAN Ying, JIANG Yunlu, CHEN Huaining. Relationship between stress calculation function of indentation strain-gage and mechanical properties of low-alloy steel[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(7): 133-138. DOI: 10.12073/j.hjxb.2019400195
shu

压痕应变法应力计算函数和低合金钢力学性能的关系

  • 中国科学院金属研究所 核用材料与安全评价重点实验室, 沈阳 110016

Relationship between stress calculation function of indentation strain-gage and mechanical properties of low-alloy steel

  • Key Laboratory of Nuclear Materials and Safety Assessment, Institute of Metal Research, CAS, Shenyang 110016, China

摘要

    摘要
  • 摘要: 压痕应变法是一种新型无损的应力检测方法，具有快捷方便、测试准确等优点，影响该方法测量精度的主要因素之一就是应力计算函数（压痕应变增量（Δε）与弹性应变（ε）之间的关系）的确定.文中在已有工作基础上，基于有限元数值模拟计算，结合试验标定结果，探讨了12种不同力学性能的低合金钢类材料应力计算函数的存在规律.结果表明，在获得材料拉伸力学性能的情况下，根据材料在零应力情况下的应变增量，可以获得该材料的应力计算函数，从而避免了应力计算函数确定时进行的复杂试验标定或模拟计算问题.
    Abstract: Indentation strain-gage method is one of basically non-destructive stress determination methods. It has some advantages, like quickness, convenience, accuracy and so on. One of the factors influencing the accuracy of stress measurement is determination of stress calculation function (the relationship between strain increment Δε and the elastic strain ε). Based on existing research, the relationship between stress calculation function and mechanical properties for 12 kinds of low-alloy steels was discussed in this paper. The numerical simulation method combined with experimental calibration results was adopted. The study shows that stress calculation function for a certain steel could be extracted if its mechanical properties and Δε0 were obtained. By this way, the complex experimental calibration tests or numerical simulation works could be eliminated.
    • HTML全文
    • 参考文献(13)
  • [1] 陈亮山,董秀中,潘兴.冲击压痕测定残余应力研究[C]//第七次全国焊接学术会议论文集.哈尔滨,1993:21-24.
    [2] 林丽华,陈立功,顾明元.球面压痕测残余应力试验方法研究[J].机械强度, 1998, 20(4):303-307 Lin Lihua, Chen Ligong, Gu Mingyuan. A new method for determining residual stress-a spherical indenter pressed on the structure surface and added a additional stress field[J]. Journal of Mechanical Strength, 1998, 20(4):303-307
    [3] 孙渊,王庆明,夏风芳,等.残余应力测量法中压痕标定实验的分析[J].机械制造, 2006, 44(504):70-72 Sun Yuan, Wang Qingming, Xia Fengfang, et al. Analysis of indentation calibration experiment in residual stress measurement[J]. Machinery, 2006, 44(504):70-72
    [4] 曲鹏程.屈服强度对压痕应变法测量残余应力的影响[D].沈阳:中国科学院金属研究所, 2006.
    [5] 孟宪陆.不同应力场中压痕应变法的数值模拟[D].沈阳:中国科学院金属研究所, 2007.
    [6] 刘生.材料性能和方向性对压痕应变法测量残余应力的影响[D].沈阳:中国科学院金属研究所, 2013.
    [7] 陈静,阚盈,姜云禄,等.压痕应变法应力计算常数的数值模拟[J].焊接学报, 2019, 40(1):147-150 Chen Jing, Kan Ying, Jiang Yunlu, et al. Numerical simulation of stress determination coefficients for indentation strain-gage method[J]. Trasactions of the China Welding Institution, 2019, 40(1):147-150
    [8] 陈静,阚盈,姜云禄,等.一种基于有限元模拟确定压痕应变法应力测量常数的方法:201711277423.8[P].2017-11-27.
    [9] Johnson K J. Contact mechanics[M]. Cambridge University Press, 1985.
    [10] Gao X L. An expanding cavity model incorporating strain-hardening and indentation size effects[J]. International Journal of Solids and Structures, 2006, 43:6615-6629.
    [11] 郑学斌,尚鹏举.应变硬化指数与屈服强度和抗拉强度关系的研究[J].机械工程师, 2017, 5:102-105 Zheng Xuebin, Shang Pengju. Study on influence of strain hardening exponent on yield strength and tensile strength[J]. Mechanical Engineer, 2017, 5:102-105
    [12] 中国国家标准化管理委员会.金属材料残余应力测定压痕应变法:GB/T 24179-2009[S].北京:中国标准出版社, 2009.
    [13] 陈静,黄春玲,陈怀宁.三点弯曲标定实验中双向主应变之间的关系[J].兵器材料科学与工程, 2008, 31(6):37-40 Chen Jing, Huang Chunling, Chen Huaining. Relationship between the two principle strains in the three-point bending calibration experiment[J]. Ordnance Material Science and Engineering, 2008, 31(6):37-40
