新型双脉冲MIG焊接电源

钟启明, 谢芳祥, 王振民

钟启明, 谢芳祥, 王振民. 新型双脉冲MIG焊接电源[J]. 焊接学报, 2019, 40(7): 94-99. DOI: 10.12073/j.hjxb.2019400188
引用本文: 钟启明, 谢芳祥, 王振民. 新型双脉冲MIG焊接电源[J]. 焊接学报, 2019, 40(7): 94-99. DOI: 10.12073/j.hjxb.2019400188
shu
ZHONG Qiming, XIE Fangxiang, WANG Zhenmin. Research of a novel double-pulsed MIG welding power supply[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(7): 94-99. DOI: 10.12073/j.hjxb.2019400188
Citation: ZHONG Qiming, XIE Fangxiang, WANG Zhenmin. Research of a novel double-pulsed MIG welding power supply[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(7): 94-99. DOI: 10.12073/j.hjxb.2019400188
shu

新型双脉冲MIG焊接电源

  • 华南理工大学, 广州 510640

基金项目: 国家自然科学基金项目（E51875212）；广东省科技计划项目（2016B090927008，201807010035，2018A030313192）

Research of a novel double-pulsed MIG welding power supply

  • South China University of Technology, Guangzhou 510640, China

摘要

    摘要
  • 摘要: 为提升双脉冲MIG焊接设备的整体性能，研制了一台基于全碳化硅功率器件的双脉冲MIG逆变焊接电源，逆变频率可达100 kHz，有利于实现电弧的精细化控制.以STM32F405RGT6为控制核心，搭建了逆变焊机的控制系统硬件电路，其由主控制电路、数字面板以及送丝控制电路等构成.根据双脉冲MIG焊的任务需求设计了相应的控制软件，采用增量式PID算法控制输出量，通过单脉冲输出+脉动送丝控制，实现双脉冲焊接.结果表明，所研制的逆变焊接电源具有快速的动态响应，能有效配合脉动送丝进行焊接，焊缝鱼鳞纹清晰，无明显缺陷.
    Abstract: In order to improve the overall performance of double-pulsed MIG welding equipment, a novel welding power is developed based on silicon carbide power devices. The inverting frequency is up to 100 kHz, which is beneficial to precisely control welding arc. Control circuit of the proposed welding power is composed of the main control circuit, a digital panel, wire feeder control circuit, in which STM32F405RGT6 is the control core. A corresponding control software is designed according to double-pulsed MIG welding task requirements. The incremental PID algorithm is used to control the output and double-pulsed welding is realized by single pulse output with pulsating wire feeding. Test result shows that the proposed welding power supply has a fast-dynamic response, which can effectively cooperate with the pulsating wire feeding to weld. The fish scales of the weld are clear without obvious defects.
    • HTML全文
    • 参考文献(11)
  • [1] 马德.数字控制铝合金双脉冲MIG焊工艺的研究[D].北京:北京工业大学, 2004.
    [2] Hazra S, De A, Cheng L, et al. High switching performance of 1700-V, 50-A SiC power MOSFET over Si IGBT/BiMOSFET for advanced power conversion applications[J]. IEEE Transactions on Power Electronics, 2016, 31(7):4742-4754.
    [3] Wang G, Mookken J, Rice J, et al. Dynamic and static behavior of packaged silicon carbide MOSFETs in paralleled applications[C]//Applied Power Electronics Conference, 2014:1478-1483.
    [4] 王振民,汪倩,王鹏飞,等.新一代WBG弧焊逆变电源[J].焊接学报, 2016, 37(7):49-52 Wang Zhenmin, Wang Qian, Wang Pengfei, et al. A new generation WBG arc welding inverter[J]. Transactions of the China Welding Institution, 2016, 37(7):49-52
    [5] 沙德尚,廖晓钟.双脉冲MIG/MAG焊全数字控制策略[J].北京理工大学学报, 2009, 29(7):605-607 Sha Deshang, Liao Xiaozhong. Full digital control strategy of double pulsed MIG/MAG welding[J]. Transactions of Beijing Institute of Technology, 2009, 29(7):605-607
    [6] 钱金川,朱守敏.全桥式逆变电源主电路设计[J].电工电气, 2010(04):12-19 Qian Jinchuan, Zhu Shoumin. Main circuit design of full-bridge reverse converter power supply[J]. Electrotechnics Electric, 2010(04):12-19
    [7] Hazra S, Madhusoodhanan S, Moghaddam G, et al. Design considerations and performance evaluation of 1200 V, 100 A SiC MOSFET based converter for high power density application[J]. IEEE Transactions on Industry Applications, 2013, 52(5):4527-4268.
    [8] Rice J, Mookken J. SiC MOSFET gate drive design considerations[C]//IEEE International Workshop on Integrated Power Packaging. IEEE, 2015:24-27.
    [9] 王振民,张福彪,王鹏飞,等.全数字机器人VPPA焊接电源[J].焊接学报, 2017, 38(7):5-8,30 Wang Zhenmin, Zhang Fubiao, Wang Pengfei, et al. Research on full digital robot VPPA welding power supply[J]. Transactions of the China Welding Institution, 2017, 38(7):5-8,30
    [10] 邓方雄,钟继光,石永华,等.水下焊接脉动送丝机构的研制[J].电焊机, 2006, 36(7):13-15 Deng Fangxiong, Zhong Jiguang, Shi Yonghua, et al. Study on the pulsed feeding wire system for underwater welding[J]. Electric Welding Machine, 2006, 36(7):13-15
    [11] 吴强,韩震宇,李程.基于增量式PID算法的无刷直流电机PWM调速研究[J].机电工程技术, 2013, 42(3):63-65 Wu Qiang, Han Zhenyu, Li Cheng. Based on the incremental PID algorithm for brushless DC motor PWM speed control research[J]. Mechanical&Electrical Engineering Technology, 2013, 42(3):63-65
