高频交变磁场对大电流GMAW熔滴过渡和飞溅率的影响

樊丁, 杨文艳, 肖磊, 黄健康

樊丁, 杨文艳, 肖磊, 黄健康. 高频交变磁场对大电流GMAW熔滴过渡和飞溅率的影响[J]. 焊接学报, 2019, 40(7): 1-5. DOI: 10.12073/j.hjxb.2019400172
引用本文: 樊丁, 杨文艳, 肖磊, 黄健康. 高频交变磁场对大电流GMAW熔滴过渡和飞溅率的影响[J]. 焊接学报, 2019, 40(7): 1-5. DOI: 10.12073/j.hjxb.2019400172
shu
FAN Ding, YANG Wenyan, XIAO Lei, HUANG Jiankang. Effect of high frequency longitudinal alternating magnetic field on droplet transfer and spatter rate in high current GMAW welding[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(7): 1-5. DOI: 10.12073/j.hjxb.2019400172
Citation: FAN Ding, YANG Wenyan, XIAO Lei, HUANG Jiankang. Effect of high frequency longitudinal alternating magnetic field on droplet transfer and spatter rate in high current GMAW welding[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(7): 1-5. DOI: 10.12073/j.hjxb.2019400172
shu

高频交变磁场对大电流GMAW熔滴过渡和飞溅率的影响

  • 1.

    兰州理工大学 材料科学与工程学院, 兰州 730050;兰州理工大学 省部共建有色金属先进加工与再利用国家重点实验室, 兰州 730050

  • 2.

    兰州理工大学 材料科学与工程学院, 兰州 730050

基金项目: 国家自然科学基金项目（51775256）；甘肃省基础研究创新群体计划项目（17JR5RA107）；甘肃省高校协同创新团队项目（2017C-07）

Effect of high frequency longitudinal alternating magnetic field on droplet transfer and spatter rate in high current GMAW welding

  • 1.

    School of Materials Science and Engineering, Lanzhou University of Technology, Lanzhou 730050, China;State Key Laboratory of Advanced Processing and Reuse of Nonferrous Metals, Lanzhou University of Technology, Lanzhou 730050, China

  • 2.

    School of Materials Science and Engineering, Lanzhou University of Technology, Lanzhou 730050, China

摘要

    摘要
  • 摘要: 在熔化极气体保护焊过程中，采用大送丝速度，增大焊接电流和焊丝伸出长度是提高焊接熔敷率的直接途径.但当熔滴过渡转变为旋转射流过渡时，电弧不稳，飞溅增大，焊缝成形变差.施加不同频率的纵向交变磁场，对焊缝成形进行控制.采用高速摄像技术，拍摄焊接过程中的电弧形态和熔滴过渡，研究不同频率的磁场对熔滴过渡和焊接飞溅率的影响规律.结果表明，熔滴过渡形式不同，产生飞溅的机理不同；外加频率为1 000 Hz纵向交变磁场时，电弧的旋转半径减小，电弧的挺度增大，旋转射流过渡时电弧更稳定，焊接飞溅率降低，焊缝成形改善.
    Abstract: In the process of gas shielded arc welding (GMAW), it is a direct way to increase the welding deposit rate by adopting high wire feeding speed, increasing welding current and dry elongation. However, when the droplet transfer is changed into rotating jet transfer, the arc is unstable, the spatter increases and the weld formation becomes worse. A longitudinal alternating magnetic field with different frequencies is applied to control the weld formation. The arc shape and droplet transfer during welding were photographed by high-speed video camera. The effects of magnetic field with different frequencies on droplet transfer and welding spatter rate were studied. The results show that the mechanism of spatter is different with different droplet transfer modes; when the applied frequency is 1 000 Hz longitudinal alternating magnetic field, the rotating radius of arc decreases, the stiffness of arc increases, the arc is more stable, the welding spatter rate decreases, and the weld shape is improved.
    • HTML全文
    • 参考文献(14)
  • [1] 朱胜,王启伟,殷凤良,等.交变纵向磁场作用下MIG焊电弧行为研究[J].材料热处理学报, 2011, 32(11):23-27 Zhu Sheng, Wang Qiwei, Yin Fengliang, et al. Research on MIG welding arc under alternating longitudinal magnetic field[J]. Transactions of Materials and Heat Treatment, 2011, 32(11):23-27
    [2] Zhu S, Wang Q W, Yin F L, et al. Research on droplet transfer of MIG welding with alternating longitudinal magnetic field[J]. Advanced Materials Research, 2011, 189-193:993-996.
    [3] 岳建锋,李亮玉,刘文吉,等.基于外加高频交变磁场下向MAG焊熔池成形控制[J].机械工程学报, 2013, 49(8):65-70 Yue Jianfeng, Li Liangyu, Liu Wenji, et al. Downward welding pool shape control based on exterior high frequency alternative magnetic field[J]. Journal of Mechanical Engineering, 2013, 49(8):65-70
    [4] 华爱兵,殷树言,陈树君,等.纵向磁场对MAG焊电弧及熔滴过渡的控制作用[J].机械工程学报, 2010, 46(14):95-100 Hua Aibing, Yin Shuyan, Chen Shujun, et al. Behavior of arc and transfer of MAG welding controlled by longitudinal magnetic field[J]. Journal of Mechanical Engineering, 2010, 46(14):95-100
    [5] Chang Y L, Che X P, He Y Y, et al. Influence of longitudinal magnetic field on metal transfer in MIG arc welding[J]. China Welding, 2008, 17(2):27-31.
    [6] 常云龙,李海涛,梅强,等.外加纵向磁场对CO2焊接短路液桥的影响[J].沈阳工业大学学报, 2015, 37(6):624-628 Chang Yunlong, Li Haitao, Mei Qiang, et al. Influence of external longitudinal magnetic field on short circuit liquid bridge of CO2 welding[J]. Journal of Shenyang University of Technology, 2015, 37(6):624-628
    [7] 常云龙,李多,李大用,等.纵向磁场作用下MIG焊熔滴过渡过程的分析[J].焊接学报, 2009, 30(3):21-24 Chang Yunlong, Li Duo, Li Dayong, et al. Analyses of process of MIG droplet transfer with longitudinal magnetic[J]. Transactions of the China Welding Institution, 2009, 30(3):21-24
    [8] Nosov D G, Peremitko V V. Influence of frequency and induction of longitudinal magnetic field on the electrode metal loss and its spattering during MAG-welding[J]. IOP Conference Series:Materials Science and Engineering, 2015, 91(1):012011.
    [9] 刘民军.磁控焊接电弧行为及焊缝成形机理的研究[D].沈阳:沈阳工业大学, 2016.
    [10] Fan C, Zhou L, Liu Z, et al. Arc character and droplet transfer of pulsed ultrasonic wave-assisted GMAW[J]. International Journal of Advanced Manufacturing Technology, 2017(1):1-8.
    [11] 武传松,高学松.焊接物理(ⅡW SG-212)研究进展-第70届国际焊接学会年会焊接物理研究组报告评述[J].焊接, 2018(1):1-11, 61 Wu Chuansong, Gao Xuesong. Advances in welding physics (ⅡWSG-212):review of the report of the research group on welding physics at the 70th annual meeting of the international welding society[J]. Welding&Joining, 2018(1):1-11, 61
    [12] Jiang Y, Zhao Z, Li L. Numerical simulation for GMAW with a new model based on phase field model[J]. China Welding, 2018, 27(1):46-52.
    [13] Gao X D, Wen Q, Katayama S. Analysis of high-power disk laser welding stability based on classification of plume and spatter characteristics[J]. Transactions of Nonferrous Metals Society of China, 2013, 23(12):3748-3757.
    [14] 王好猛.熔化极气体保护焊电信号与焊接过程稳定性的相关性研究[D].济南:山东大学, 2015.
