基于压焊原理的搅拌摩擦焊匙孔填补技术

邓黎鹏, 柯黎明, 刘金合

邓黎鹏, 柯黎明, 刘金合. 基于压焊原理的搅拌摩擦焊匙孔填补技术[J]. 焊接学报, 2019, 40(6): 107-111. DOI: 10.12073/j.hjxb.2019400163
引用本文: 邓黎鹏, 柯黎明, 刘金合. 基于压焊原理的搅拌摩擦焊匙孔填补技术[J]. 焊接学报, 2019, 40(6): 107-111. DOI: 10.12073/j.hjxb.2019400163
shu
DENG Lipeng, KE Liming, LIU Jinhe. A key-hole filling technology for friction stir welding based on the theory of pressure welding[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(6): 107-111. DOI: 10.12073/j.hjxb.2019400163
Citation: DENG Lipeng, KE Liming, LIU Jinhe. A key-hole filling technology for friction stir welding based on the theory of pressure welding[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(6): 107-111. DOI: 10.12073/j.hjxb.2019400163
shu

基于压焊原理的搅拌摩擦焊匙孔填补技术

  • 1.

    西北工业大学, 西安 710072;南昌航空大学, 南昌 330063

  • 2.

    南昌航空大学, 南昌 330063

  • 3.

    西北工业大学, 西安 710072

A key-hole filling technology for friction stir welding based on the theory of pressure welding

  • 1.

    Northwestern Polytechnical University, Xi'an, 710072, China;Nanchang Hangkong University, Nanchang 330063, China

  • 2.

    Nanchang Hangkong University, Nanchang 330063, China

  • 3.

    Northwestern Polytechnical University, Xi'an, 710072, China

摘要

    摘要
  • 摘要: 搅拌摩擦焊焊缝尾部匙孔是阻碍搅拌摩擦焊应用推广的主要问题之一，文中提出并研究了一种基于压焊原理的匙孔填补技术.以三相次级整流电阻点焊机为试验平台，2024-T4铝合金3.0 mm+3.0 mm的搅拌摩擦点焊匙孔为填补对象，具体研究了匙孔填补后各区域的硬度、微观组织及其与塞棒的连接机理.结果表明，引入压焊原理，采用电阻点焊机可以实现匙孔填补，填补后匙孔可分为熔合区、压合区、熔化区及塑性变形区，塞棒与匙孔之间的连接形式以扩散焊接形式为主，局部有熔化焊接形式，且填补过程未对匙孔周围组织及硬度产生明显影响.
    Abstract: The key-hole in the end of friction stir welding (FSW) joint is one of the application and promotion barriers. For overcoming the barrier, a new technology based on the theory of pressure welding for filling key-hole is invented and researched on the three phase secondary rectifier resistance spot welder in the paper. The key-hole in the friction stir spot welding lap joint of 3.0 mm + 3.0 mm thickness 2024-T4 aluminum alloy is filled. In the paper, micro hardness and micro structure about the filled joint are all studied, and the bonding mechanism is analyzed according the welding theory and crystallography. The results prove that the filled joint including the fusion welding zone, pressure welding zone, plastic deformation zone and melted stopper zone. The diffusion welding is the major metallurgy bond and fusion welding is the minor form of bond between the stopper and key-hole. The micro hardness and structure around the filled key-hole are not changed by the high-efficiency filling technology.
    • HTML全文
    • 参考文献(20)
  • [1] Thomas W M, Nicholas E D, Dawes C J. Friction stir butt welding UK:9125978.8[P]. 1991−12−06.
    [2] Aonuma M, Nakata K. Dissimilar meatl Joining of 2024 and 7075 aluminium alloys to titanium alloys by friction stir welding[J]. Materials Transaction, 2011(52):948-952.
    [3] Cavaliere P, Cerri E, Squillace A. Mechanical response of 2024-7075 aluminium alloys joined by friction stir welding[J]. Journal of Materials Science, 2005(40):3669-3676.
    [4] 栾国红,郭德伦,张田仓,等.搅拌摩擦焊在飞机制造工业中的应用[J].航空制造技术, 2002(11):11-20 Luan Guohong, Guo Delun, Zhang Tiancang, et al. Application of friction stir welding to aircraft manufacturing industry[J]. Aeronautical Manufacturing Technology, 2002(11):11-20
    [5] Li Ying, Trillo E A, Murr L E. Friction-stir welding of aluminum alloy 2024 to silver[J]. Journal of Materials Science Letters, 2000, 19:1047-1051.
    [6] 董春林,栾国红,关桥.搅拌摩擦焊在航空航天工业的应用发展现状与前景[J].焊接, 2008(11):25-30 Dong Chunlin, Luan Guohong, Guan Qiao. Prospects of application and development of friction stir welding in aerospace and aviation industry[J]. Welding&Joining, 2008(11):25-30
    [7] 栾国红.搅拌摩擦焊匙孔去除技术[J].现代焊接, 2006(10):34-35 Luan Guohong. A technology for removing the keyhole of friction stir welding[J]. Modern Welding, 2006(10):34-35
    [8] 李宝华,陈莹,唐众民,等.搅拌摩擦焊收焊匙孔填补的研究[J].热加工工艺, 2010, 39(23):144-146 Li Baohua, Chen Ying, Tang Zhongmin, et al. Study on filling keyhole during friction stir welding[J]. Hot Working Technology, 2010, 39(23):144-146
    [9] Schilling C, Santos J. Method and device for joining at least two adjoining work pieces by friction welding:US 6, 722, 556 B2[P], 2004-04-20.
    [10] Unfried J S, Paes M T P, Hermenegildo T F C, et al. Study of microstructural evolution of friction taper plug welded joints of C-Mn steels[J]. Science and Technology of Welding&Joining, 2010, 15(6):506-513.
    [11] 季亚娟.摩擦塞焊及其研究现状[J].航空制造技术, 2008(24):74-75 Ji Yajuan. The current state of FPW[J]. Aeronautical Manufacturing Technology, 2008(24):74-75
    [12] Du Bo, Sun Zuanping, Yang Xinqi, et al. Characteristics of friction plug welding to 10mm thick AA2219-T87 sheet:weld formation, microstructure and mechanical property[J]. Materials Science Engineering A, 2016, 654:21-29.
    [13] 栾国红,季亚娟,董春林,等. LY12铝合金摩擦塞焊接头组织分析[J].焊接学报, 2006, 27(10):1-3 Luan Guohong, Ji Yajuan, Dong Chunlin, et al. Microstructure of LY12 aluminium alloy welded joint of friction plug welding[J]. Transactions of the China Welding Institution, 2006, 27(10):1-3
    [14] Huang Y X, Han B, Tian Y, et al. New technique of filling friction stir welding[J]. Science and Technology of Welding and Joining, 2011, 16(6):497-501.
    [15] Zhou L, Liu D, Nakata K, et al. New technique of self-refilling friction stir welding to repair keyhole[J]. Science and Technology of Welding and Joining, 2012, 17(8):649-655.
    [16] Han Bing, Huang Yongxian, Lü Shixiong, et al. AA7075 bit for repairing AA2219 keyhole by filling friction stir welding[J]. Materials&Design, 2013, 51(10):25-33.
    [17] Zhang G F, Jiao W M, Zhang J X. Filling friction stir weld keyhole using pin free tool and T shaped filler bit[J]. Science and Technology of Welding and Joining, 2014, 19(2):98-104.
    [18] 刘杰,张力,杨景宏.厚板铝合金搅拌摩擦焊匙孔修补焊方法,中国专利:201110373891.1[P]. 2011-11-22.
    [19] Martin R, Thomas G, Uceu S, et al. Keyhole closure using friction spot welding in aluminium alloy 6061-T6[J]. Journal of Materials Processing Technology, 2016(237):12-18.
    [20] Deng Lipeng, Ke Liming, Liu Jinhe, et al. Effect of upsetting force on microstructure of welds in resistance spot welding of 400 MPa ultra-fine grain steel[J]. China Welding, 2016, 25(2):76-82.
