2219铝合金FSW焊缝摩擦塞补焊接头性能分析

孙转平, 杨新岐, 杜波, 刘凯旋, 宋建岭

孙转平, 杨新岐, 杜波, 刘凯旋, 宋建岭. 2219铝合金FSW焊缝摩擦塞补焊接头性能分析[J]. 焊接学报, 2019, 40(5): 143-147. DOI: 10.12073/j.hjxb.2019400142
引用本文: 孙转平, 杨新岐, 杜波, 刘凯旋, 宋建岭. 2219铝合金FSW焊缝摩擦塞补焊接头性能分析[J]. 焊接学报, 2019, 40(5): 143-147. DOI: 10.12073/j.hjxb.2019400142
shu
SUN Zhuanping, YANG Xingqi, DU Bo, LIU Kaixuan, SONG Jianling. Investigation on mechanical properties of friction plug welded joints for 2219 friction stir welds[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(5): 143-147. DOI: 10.12073/j.hjxb.2019400142
Citation: SUN Zhuanping, YANG Xingqi, DU Bo, LIU Kaixuan, SONG Jianling. Investigation on mechanical properties of friction plug welded joints for 2219 friction stir welds[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(5): 143-147. DOI: 10.12073/j.hjxb.2019400142
shu

2219铝合金FSW焊缝摩擦塞补焊接头性能分析

  • 1.

    天津大学, 天津 300072;天津航天长征火箭制造有限公司, 天津 300451

  • 2.

    天津大学, 天津 300072

  • 3.

    天津航天长征火箭制造有限公司, 天津 300451

Investigation on mechanical properties of friction plug welded joints for 2219 friction stir welds

  • 1.

    Tianjin University, Tianjin 300072, China;Tianjin Changzheng Rocket Manufacturing Co., Ltd., Tianjin 300451, China

  • 2.

    Tianjin University, Tianjin 300072, China

  • 3.

    Tianjin Changzheng Rocket Manufacturing Co., Ltd., Tianjin 300451, China

摘要

    摘要
  • 摘要: 采用顶锻式摩擦塞补焊方法，对8 mm厚2219-T87铝合金FSW焊缝进行了摩擦塞补焊试验研究，深入探讨摩擦塞补焊接头的微观组织、常温和低温力学性能、硬度及断口形貌变化特征. 结果表明，摩擦塞补焊接头具有明显的组织不均匀性，主要由塞棒区、塞棒热力影响区、再结晶区、母材热力影响区、热影响区和母材区组成；母材热力影响区晶粒具有显著变形特征, 其硬度最低为85 HV，是整个接头的薄弱部分. 摩擦塞补焊接头的常温和低温抗拉强度均达到FSW接头的80%以上，断后伸长率达到70%以上，其断裂模式为韧性特征.
    Abstract: Based on the friction push plug welding method, the investigations of friction plug welding experiments for 2219-T87 friction stir welds with 8 mm thickness by using the 2219-T6 plugs have been performed. The varying features of microstructures, mechanical properties at room, low temperature conditions, micro-hardness profiles and fracture modes have been analyzed in details. The results show that the microstructures of FPW joints was obviously inhomogeneous. The joints are mainly composed of plug zone, plug thermo-mechanical affected zone, recrystallization zone, base metal thermo-mechanical affected zone, heat affected zone and base material. The grains in the thermo-mechanically affected zone of base metal is the weakest areas of whole FPW joints at which the grains have the obviously deformed features and the lowest micro-hardness of 85 HV, which are the tensile strength of FPW joints at room and low temperatures can reach above 80% of FSW joint, the elongation can reach above 70%, and the fracture modes of FPW joints are possessed of ductile features.
    • HTML全文
    • 参考文献(10)
  • [1] 彭杏娜,曲文卿,张国华,等.焊接方法对2219铝合金性能及组织的影响[J].航空材料学报, 2009, 29(2):57-60 Peng Xingna, Qu Wenqing, Zhang Guohua, et al. Influence of welding processes on mechanical properties of aluminum alloy 2219[J]. Journal of Aeronautical Materials, 2009, 29(2):57-60
    [2] 金淳,黄亮,李建军,等.不同热处理状态下成形速率对2219铝合金成形极限的影[J].塑性工程学报, 2017, 24(1):125-132 Jin Chun, Huang Liang, Li Jianjun, et al. Influence of forming rate on forming limit of 2219 aluminum alloy under different heat treatment conditions[J]. Journal of Plasticity Engineering, 2017, 24(1):125-132
    [3] 林一桐,王东坡,王颖.基于Neuber公式的焊接制造对运载火箭储箱承载力的影响[J].焊接学报, 2016, 37(1):51-54 Lin Yitong, Wang Dongpo, Wang Ying. Effect of welding on bearing capacity of launch vehicle tank based on Neuber formula[J]. Transactions of the China Welding Institution, 2016, 37(1):51-54
    [4] Balasubramanian V, Lakshminarayanan A K. The mechanical properties of the GMAW, GTAW and FSW joints of the RDE-40 aluminum alloy[J]. International Journal of Microstructure and Materials Properties, 2008, 3(6):837-853.
    [5] Beamish K. Friction taper plug welding of 10 mm AA6082-T6[R]. TWI Report, No. 768, 2003.
    [6] Andrews R E, Mitchell J S. Underwater repair by friction stitch welding[J]. Metals and Materials, 1990, 6(12):796-797.
    [7] Delano A D. Friction welding with conoids:US patent, No. 6638641[P]. 2003-10-28.
    [8] Coletta E R, Cantrell M A. Friction pull plug welding, top hat plug design:US patent, No. 6386419[P]. 2002-05-14.
    [9] 杜波,孙转平,杨新岐,等.异种铝合金摩擦塞补焊接头微观组织及性能[J].机械工程学报, 2017, 53(4):44-48 Du Bo, Sun Zhuanping, Yang Xinqi, et al. Microstructures and properties of friction stir welded aluminum alloy[J]. Journal of Mechanical Eneineering, 2017, 53(4):44-48
    [10] Metz D F. Experimental and numerical characterization of the fatigue and fracture properties of friction plug welds in 2195-T8 dissimilar aluminum lithium alloy[D]. Tuscaloosa:the University of Alabama, 2013.
