黄铜与304不锈钢的电阻软钎焊封装工艺

孙志超, 桑健, 隋英杰, 王波, 张洪涛

孙志超, 桑健, 隋英杰, 王波, 张洪涛. 黄铜与304不锈钢的电阻软钎焊封装工艺[J]. 焊接学报, 2019, 40(5): 137-142. DOI: 10.12073/j.hjxb.2019400141
引用本文: 孙志超, 桑健, 隋英杰, 王波, 张洪涛. 黄铜与304不锈钢的电阻软钎焊封装工艺[J]. 焊接学报, 2019, 40(5): 137-142. DOI: 10.12073/j.hjxb.2019400141
shu
SUN Zhichao, SANG Jian, SUI Yingjie, WANG Bo, ZHANG Hongtao. Study on brass and 304 stainless steel packaging process by resistance soldering[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(5): 137-142. DOI: 10.12073/j.hjxb.2019400141
Citation: SUN Zhichao, SANG Jian, SUI Yingjie, WANG Bo, ZHANG Hongtao. Study on brass and 304 stainless steel packaging process by resistance soldering[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(5): 137-142. DOI: 10.12073/j.hjxb.2019400141
shu

黄铜与304不锈钢的电阻软钎焊封装工艺

  • 1.

    哈尔滨工业大学(威海), 威海 264209

  • 2.

    威海职业学院, 威海 264200

  • 3.

    哈尔滨工业大学(威海), 威海 264209;山东船舶技术研究院, 威海 264209

基金项目: 泰山学者青年专家支持计划（tsqn20161062）；山东省重点研发计划（2018GGX103032）；山东省自然科学基金资助项目（ZR2018MEE027）；哈尔滨工业大学科研创新基金资助项目（HIT.NSRIF.201707）

Study on brass and 304 stainless steel packaging process by resistance soldering

  • 1.

    Harbin Institute of Technology at Weihai, Weihai 264209, China

  • 2.

    Weihai Vocational College, Weihai 264200, China

  • 3.

    Harbin Institute of Technology at Weihai, Weihai 264209, China;Shandong Institute of Shipbuilding Technology, Weihai 264209, China

摘要

    摘要
  • 摘要: 针对某热量表的温度传感器中由于尼龙成分的存在导致其构成材料黄铜和304不锈钢不能在高温下焊接的问题，采用电阻软钎焊的低温连接方法进行焊接试验，以实现密封连接效果. 结果表明，在0.3 MPa的焊接压力下，当焊接电流设定为26 kA时，以双层Sn-Pb箔片为钎料的焊件进行的试验效果良好，达到了可靠的连接，且黄铜中心尼龙成分未受到焊接温度的影响而损坏. 在扫描电镜下观察到钎料与不锈钢和黄铜均发生了表面扩散. 将焊接后的样品置于水中进行密封性试验，结果显示焊缝区域实现了可靠地连接，达到了密封防水效果.
    Abstract: Aiming at the failure to join for the constituent materials brass and 304 stainless steel using resistance soldering at high temperatures, due to the presence of a nylon component, welding experiments were conducted using low-temperature connection method of resistance soldering so as to achieve sealing effect. The results show that under the pressure 0.3 MPa and the welding current 26 kA, the joining with double-layer Sn-Pb foil as brazing filler is available, and the brass center nylon component is not damaged. Observed by scanning electron microscope, surface diffusion occurred between solder and stainless steel or brass. The results of sealing test in water show that the weld area is sealed and the waterproof effect is achieved.
    • HTML全文
    • 参考文献(14)
  • [1] 高振永.紫铜/黄铜焊接接头微观组织及力学性能研究[D].哈尔滨:哈尔滨工业大学, 2009.
    [2] 管永星. 304不锈钢软钎焊用钎剂研究[D].南京:南京航空航天大学, 2013.
    [3] 张志强,荆洪阳,徐连勇,等.双相不锈钢多层多道焊接接头微观组织表征[J].焊接学报, 2017(5):83-86 Zhang Zhiqiang, Jing Hongyang, Xu Lianyong, et al. Microstructural characterization of multi-phase stainless steel multi-layer welded joints[J]. Transactions of the China Welding Institution, 2017(5):83-86
    [4] Yang Ke, Zhang Zhixi, Jiang Yongfeng, et al. Microstructure and corrosion resistance of 304 stainless steel electroslag strip cladding[J]. China Welding, 2016, 25(1):15-20.
    [5] 宫文彪,毛亚芬,张秋征,等. H62黄铜搅拌摩擦焊接头微观结构及性能[J].焊接学报, 2014, 35(2):83-86 Gong Wenbiao, Mao Yafen, Zhang Qiuzheng, et al. Microstructure and properties of H62 brass friction stir welded joints[J]. Transactions of the China Welding Institution, 2014, 35(2):83-86
    [6] Tasak E, Stankiewicz M, Gierlicki R, et al. Properties of joints welded in dissimilar materials[J]. Welding International, 2003, 17(4):293-297.
    [7] Li G, Lu X F, Zhu X L, et al. Fiber laser butt joining of AZ31B alloy to 304 stainless steels with copper foil[J]. Optics and Laser Technology, 2019, 117:215-226.
    [8] Shakhmatov M V, Shakhmatov D M. Features of resistance butt welding of cast iron[J]. Welding International, 2004, 18(9):737-741.
    [9] Sidyakin V A, Danilov A I. Low-pressure arc butt welding of steel and nickel alloy pipes in power engineering[J]. Welding International, 2004, 18(4):324-329.
    [10] Veselov V A. Butt welding with the heating by the low pressure arc of steel-aluminium pipe transition pieces for cryogenic systems and equipment[J]. Avt Svarka, 1990, 22(4):50-55.
    [11] 林茂广,王海龙.奥氏体不锈钢与纯铜的真空钎焊工艺研究[J].热加工工艺, 2013, 42(9):176-178 Lin Maoguang, Wang Hailong. Research on vacuum brazing process of austenitic stainless steel and pure copper[J]. Thermal Engineering Technology, 2013, 42(9):176-178
    [12] 郭红.铜与不锈钢的真空钎焊[D].武汉:武汉理工大学, 2003.
    [13] Tosto S, Nenci F, Hu J, et al. Microstructure of copper-AISI type 304L electron beam welded alloy[J]. Materials Science and Technology, 2003, 19(4):519-522.
    [14] Magnabosco I, Ferro P, Bonollo F, et al. An investigation of fusion zone microstructures in electron beam welding of copper-stainless steel[J]. Materials Science&Engineering A, 2006, 424(1-2):163-173.
