焊接电流对M51/B318异种金属精密电阻焊接头质量的影响
Effect of welding current on welding quality of M51/B318 dissimilar metal joint using resistance welding
-
摘要: 文中采用精密电阻焊进行高速钢M51与高强度弹簧钢B318异种钢材焊接，着重分析了焊接电流对接头特性四个指标(接头剪断力、热影响区大小、挤出熔渣量、有无飞溅情况)的影响. 结果表明，焊接电流与接头剪断力呈抛物线关系，焊接电流自900 A上升到1 300 A时，接头剪断力随之增加并达到峰值，当焊接电流达到1 400 A时，由于焊接能量过大出现熔渣飞溅现象，接头剪断力下降；随着焊接电流增加，热影响区的大小及挤出熔渣量也呈现先增大后减小的趋势. 文中还结合微观组织分析了焊接电流对焊缝质量的影响机理.Abstract: In this study, dissimilar steels of high speed steel M51 and high strength spring steel B318 was welded by the precision resistance welding method. The influence of welding current on four indexes of joint characteristics (shear force, heat influence zone, extrusion slag amount and splash condition) is analyzed emphatically. The results show that the welding current is in parabolic relationship with the shear force of the joint. When the welding current rises from 900 A to 1 300 A, the shear force of the joint increases to a peak value, and when the welding current reaches 1 400 A, the shear force of the joint decreases due to slag spatter result from excessive welding energy. With the increase of welding current. The size of heat affected zone and the amount of molten slag in extrusion increase firsty and then decrease. Finally, the influence of welding current on weld quality is analyzed with microstructure.
-
-
[1] Bayock F N, Kah P, Mvola B, et al. Experimental review of thermal analysis of dissimilar welds of high-strength steel[J]. Reviews on Advanced Materials Science, 2019, 58(1):38-49. [2] O'Brien A, Guzman C. Welding handbook:welding processes[M]. Miami, Florida:American Welding Society, 2007. [3] Fang Y J, Jiang X S, Mo D F, et al. A review on dissimilar metals'welding methods and mechanisms with interlayer[J]. International Journal of Advanced Manufacturing Technology, 2019, 102(9-12):2845-2863. [4] 徐慨. YG12硬质合金与W18Cr4V钢钎焊工艺及机理研究[D].哈尔滨:哈尔滨工业大学, 2014. [5] 杨全毅.异种金属M42高速钢与X32高强度钢激光焊接行为研究[D].长沙:湖南大学, 2013. [6] 贾寓真,吴懿萍,匡旭光,等.双金属带锯条制造工艺研究进展[J].工具技术, 2017, 51(10):3-10 Ja Yuzhen, Wu Yiping, Kuang Xuguang, et al. Progress of Bi-metal bandsaw blade on manufacturing process[J]. Tool Engineering, 2017, 51(10):3-10 [7] 陈刚,杨全毅,周明哲,等. M42/X32异种金属CO2激光焊接接头组织和性能的研究[J].湖南大学学报(自然科学版), 2013, 40(11):89-95 Chen Gang, Yang Quanyi, Zhou Mingzhe, et al. Study of the microstructure and properties of M42/X32 dissimilar metal CO2 laser welding joints[J]. Journal of Hunan University (Natural Sciences), 2013, 40(11):89-95 [8] 陈国庆,刘政,张秉刚,等. W6高速钢/16Mn钢电子束焊接接头组织及性能分析[J].焊接学报, 2018, 39(11):1-5 Chen Guoqing, Liu Zheng, Zhang Binggang, et al. Study on microstructure and properties of W6 high speed steel/16Mn electron beam welded joint[J]. Transactions of the China Welding Institution, 2018, 39(11):1-5 [9] 李辉,彭动军,韩季初,等.一种独立焊接磨齿型双金属带锯条的制造方法:CN103357958A[P]. 2013–10–23. [10] Xu Guocheng, Wang Chunsheng, Zhao Xihua, et al. Relationship between microstructures and mechanical properties of resistance spot welded joint of spring steel[J]. China Welding, 2006(3):38-40. [11] Zhang Yueying, Sun Daqian, Li Hongmei, et al. Effects of nugget alloying on microstructures and properties of resistance spot welded joints of aluminum and steel[J]. China Welding, 2016, 25(3):36-41. [12] 陈龙.双金属带锯条精密焊接电源及实验研究[D].广州:广东工业大学, 2018. -
