船用耐蚀钢DH36光纤激光-MIG复合焊接头组织和性能

高艳, 崔丽, 常耀卿, 顾长石, 贺定勇

高艳, 崔丽, 常耀卿, 顾长石, 贺定勇. 船用耐蚀钢DH36光纤激光-MIG复合焊接头组织和性能[J]. 焊接学报, 2019, 40(5): 60-66. DOI: 10.12073/j.hjxb.2019400128
引用本文: 高艳, 崔丽, 常耀卿, 顾长石, 贺定勇. 船用耐蚀钢DH36光纤激光-MIG复合焊接头组织和性能[J]. 焊接学报, 2019, 40(5): 60-66. DOI: 10.12073/j.hjxb.2019400128
shu
GAO Yan, CUI Li, CHANG Yaoqing, GU Changshi, HE Dingyong. Microstructures and properties of fiber laser-MIG hybrid welded joints for marine corrosion resistant steel DH36[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(5): 60-66. DOI: 10.12073/j.hjxb.2019400128
Citation: GAO Yan, CUI Li, CHANG Yaoqing, GU Changshi, HE Dingyong. Microstructures and properties of fiber laser-MIG hybrid welded joints for marine corrosion resistant steel DH36[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(5): 60-66. DOI: 10.12073/j.hjxb.2019400128
shu

船用耐蚀钢DH36光纤激光-MIG复合焊接头组织和性能

  • 1.

    北京工业大学, 北京 100124

  • 2.

    上海船舶工艺研究所, 上海 200032

基金项目: 国家自然科学基金资助项目（51475006）

Microstructures and properties of fiber laser-MIG hybrid welded joints for marine corrosion resistant steel DH36

  • 1.

    Beijing University of Technology, Beijing 100124, China

  • 2.

    Shipbuilding Technology Research Institute, Shanghai 200032, China

摘要

    摘要
  • 摘要: 为探索12 mm厚DH36船用耐蚀钢对接用光纤激光-MIG复合焊接工艺，分析了四种不同送丝速度对接头成形、微观组织、拉伸性能及腐蚀性能的影响. 结果表明，在送丝速度为8.5 m/min时可获得成形优良的接头，随着送丝速度的增加，电弧区和激光区焊缝的熔宽均增加.焊缝区主要由针状铁素体、先共析铁素体和一定量的贝氏体组成，送丝速度对针状铁素体的形态和数量有显著的影响.增加送丝速度对接头抗拉强度的影响不大，但减小了断后伸长率，接头断后伸长率最高达16.5%.接头极化曲线测试表明，当送丝速度为7.5 m/min时，自腐蚀电流密度最小，腐蚀倾向最低.
    Abstract: The marine corrosion resistant steel DH36 plates of 12 mm thickness were welded by using fiber laser-MIG hybrid welding process. The effects of wire feeding speeds on the cross section shapes, microstructures, mechanical properties and corrosion resistance of the joints were studied. The results show that with the wire feeding speed increasing from 7.0 m/min to 8.5 m/min, the weld width of arc zone rises from 8.44 mm to 10.03 mm while the weld width of laser zone increases from 1.63 mm to 2.09 mm. The wire feeding speeds have no obvious influence on the phase types of weld microstructures, which consists predominantly of acicular ferrite (AF), pro-eutectoid ferrite (GBF) and a small amount of bainite (B). As the wire feeding speed increases, the morphology and amount of AF were changed. The microstructure of the HAZ of the joint was composed of ferrite (F), pearlite (P) and a small amount of bainite (B). In addition, the increase of wire feeding speeds has little effect on the joint strength, but has an significant effect on the elongation of the joints. Increasing the wire feeding speed reduces the elongation of the joints, and when the wire feeding speed is 7.0 m/min, the elongation is up to 16.5%. The polarization curves of the joints showed that the corrosion tendency was the lowest when the wire feed speed was 7.5 m/min and the corrosion tendency was the highest when the wire feed speed was 7.0 m/min.
    • HTML全文
    • 参考文献(21)
  • [1] Sun F, Li X, Zhang F. Corrosion mechanism of corrosion-resistant steel developed for bottom plate of cargo oil tanks[J]. Acta Metallurgica Sinica (English Letters), 2013, 26:257-264.
    [2] 张国宏,成林,李钰,等.海洋耐蚀钢的国内外进展[J].中国材料进展, 2014, 33(7):426-435 Zhang Guohong, Cheng Lin, Li Yu, et al. Process of corrosion resistant steel at home and abroad[J]. Materials China, 2014, 33(7):426-435
    [3] Ito M, Kaneko M, Nishimura S, et al. Development of corrosion resistant steel for bottom plates of crude oil tanks and onboard evaluation results[C]//Proceedings of the ASME 31st International Conference on Ocean, Offshore and Arctic Engineering. Brazil:ASME, 2012:223-228.
    [4] 顾长石,邱盛兴,闫璐,等.基于IMO标准的船用耐蚀钢研究综述[J].船舶工程, 2015, 37(10):1-20 Gu Cangshi, Qiu Shengxing, Yan Lu, et al. Research summary of marine corrosion resistant steel based on IMO standard[J]. Ship Engineering, 2015, 37(10):1-20
    [5] 柳伟,樊学华,李少飞,等.油轮舱CO2-O2-H2S-SO2湿气环境中低合金钢的腐蚀行为[J].北京科技大学学报, 2011, 33(1):33-39 Liu Wei, Fan Xuehua, Li Shaofei, et al. Corrosion behavior of low alloy steels in a CO2-O2-H2S-SO2 wet gas environment of crude oil tanks[J]. Journal of University of Science and Technology Beijing, 2011, 33(1):33-39
    [6] 罗小兵,柴锋,苏航,等.含H2S干湿交替环境下船用耐蚀钢研究[J].钢铁研究学报, 2013, 25(8):51-53 Luo Xiaobing, Chai Feng, Su Hang, et al. Marine corrosion resistant steel research under dry-wet alternating environment with H2S[J]. Journal of Iron and Steel Research, 2013, 25(8):51-53
    [7] 梁金明,唐荻,武会宾,等.基于IMO标准的E36级低合金船板钢货油舱上甲板环境全周期腐蚀行为与机理[J].材料研究学报, 2014, 28(6):433-442 Liang Jinming, Tang Di, Wu Huibin, et al. Cyclic corrosion behavior of E36 low-alloy steel in a simulated cargo oil tank upper deck environment corresponding to IMO standard[J]. Chinese Journal of Materials Research, 2014, 28(6):433-442
    [8] 陶乃旺,黄淑珍,黄宏钢. IMO油船货油舱涂层及耐蚀钢试验方法及性能要求[J].中国涂料, 2011, 26(10):23-25 Tao Naiwang, Huang Shuzhen, Huang Honggang. Test methods and performance requirements for coating and corrosion resistant steel for cargo tank[J]. China Coatings, 2011, 26(10):23-25
    [9] 冯向阳,齐彦昌,彭云,等.货油舱用耐蚀钢焊接接头的耐腐蚀性能[J].钢铁研究学报, 2012, 24(3):44-49 Feng Xiangyang, Qi Yanchang, Peng Yun, et al. Corrosion resistance of corrosion resistant steel welded joints for cargo tanks[J]. Journal of Iron and Steel Research, 2012, 24(3):44-49
    [10] 杨建祎,许静,曹建平,等.原油船货油舱用耐蚀钢及焊接接头的腐蚀性能研究[J].腐蚀与防护, 2012, 33(2):39-43 Yang Jianyi, Xu Jing, Cao Jianping, et al. Corrosion behavior of corrosion resistant steel and welded joints for cargo tank of crude oil ship[J]. Corrosion and Protection, 2012, 33(2):39-43
    [11] Wei Jinshan, Qi Yanchang, Tian Zhiling, et al. Corrosion behavior of welded joints for cargo oil tanks of crude oil carrier[J]. Journal of Iron and Steel Research International, 2016, 23(9):955-962.
    [12] 崔丽,高艳,顾长石,等.微量元素Cr对船用耐蚀钢焊接接头组织和性能的影响[J].北京工业大学学报, 2018, 44(6):953-960 Cui Li, Gao Yan, Gu Changshi, et al. Effect of trace element Cr on microstructures and properties of welded joints of marine corrosion resisting steels[J]. Journal of Beijing University of Technology, 2018, 44(6):953-960
    [13] 雷正龙,陈彦宾,李俐群,等. CO2激光-MIG复合焊接射滴过渡的熔滴特性[J].应用激光, 2004, 24(6):361-364 Lei Zhenglong, Chen Yanbin, Li Liqun, et al. Characteristics of droplet transfer in CO2 laser-MIG hybrid welding with projected mode[J]. Applied Laser, 2004, 24(6):361-364
    [14] Chang Y F, Lei Z, Wang X Y, et al. Characteristic of laser-MIG hybrid welding with filling additional cold wire for aluminum alloy[J]. China Welding, 2018, 27(3):35-41.
    [15] 李晓延,武传松,李午申.中国焊接制造领域学科发展研究[J].机械工程学报, 2012, 48(6):19-31 Li Xiaoyan, Wu Chuansong, Li Wushen. Study on the progress of welding science and technology in China[J]. Journal of Mechanical Engineering, 2012, 48(6):19-31
    [16] 刘巨峰.厚板碳钢激光-MAG复合焊接工艺研究及接头组织性能分析[D].武汉:华中科技大学, 2015.
    [17] 刘凤德,张宏,王宇琪,等.面能量对激光-电弧复合焊接焊缝及熔滴过渡的影响[J].机械工程学报, 2012, 48(14):84-90 Liu Fengde, Zhang Hong, Wang Yuqi, et al. Influence of area energy for welding seam and droplet transfer on hybrid laser-arc welding[J]. Journal of Mechanical Engineering, 2012, 48(14):84-90
    [18] 杜则裕,李亚江,邹增大.焊接科学基础[M].北京:机械工业出版社, 2012.
    [19] 常丽艳,宋西平,张敏,等.基于原位SEM的激光-MIG复合焊接7075-T6铝合金疲劳裂纹扩展行为[J].焊接学报, 2016, 37(5):85-88 Chang Liyan, Song Xiping, Zhang Min, et al. In situ SEM based fatigue crack propagation behavior of hybrid laser welded 7075-T6[J]. Transactions of the China Welding Institution, 2016, 37(5):85-88
    [20] Zhang M, Wang X, Zhu G. Effect of laser welding process parameters on microstructure and mechanical properties on butt joint of new hot-rolled nano-scale precipitation-strengthened steel[J]. Acta Metallurgica Sinica (English Letters), 2014, 27:521-529.
    [21] 黄安国,李志远,余圣甫,等.低合金钢焊缝金属的腐蚀行为[J].焊接学报, 2005, 26(11):30-34 Huang Anguo, Li Zhiyuan, Yu Shengfu, et al. Corrosion behavior of weld metal of low alloy steel[J]. Transactions of the China Welding Institution, 2005, 26(11):30-34
