Brazing ZTA ceramic to TC4 alloy using Ag-Cu filler metal
-
摘要: 使用Ag-Cu钎料钎焊ZTA陶瓷与TC4钛合金，利用扫描电子显微镜(SEM)、能谱分析仪(EDS)和X射线衍射仪(XRD)等设备分析了钎焊接头界面组织，阐明了反应机理，并研究了钎焊温度对接头界面组织和力学性能的影响. 结果表明，钎焊接头的界面结构为ZTA陶瓷/TiO+Ti3(Cu,Al)3O/Ag(s,s)/Ti2Cu3/TiCu/Ti2Cu/α+β-Ti/TC4合金. 随着钎焊温度的升高，钎缝中Ag基固溶体层变薄，Ti-Cu金属间化合物层变厚，当钎焊温度达到890 ℃时，Ti-Cu金属间化合物几乎占据整了个钎缝区域. 随着温度的升高，接头抗剪强度先增大后减小，在钎焊温度为890 ℃时，接头的室温抗剪强度达到最大值，其值为43.2 MPa.Abstract: Ag-Cu filler was used to braze ZTA ceramic and TC4 alloy. Scanning electron microscopy, energy disperse spectroscopy and X ray diffraction were used to identify the interfacial microstructure and the reaction mechanism of the joints was clarified. The typical interfacial microstructure was ZTA ceramic/TiO+Ti3(Cu,Al)3O/Ag(s,s)/Ti2Cu3/TiCu/Ti2Cu/α+β-Ti/TC4 alloy. The experiments were carried at the brazing temperature from 810 °C to 910 °C. The results indicated that as the brazing temperature increased, Ag-based solid solution layer thinned and Ti-Cu intermetallic compound layers thickened. When brazed at 890 °C for 10 min, Ti-Cu intermetallic compounds occupied almost the entire brazing area, and the shear strength of the joints reached the highest value of 43.2 MPa.
-
Keywords:
- ZTA ceramic /
- TC4 alloy /
- brazing /
- interface microstructure
-
-
[1] Wen Ruilong, Fang Minghao, Min Xin, et al. Effect of ZrO2 additive amount on mechanical properties and erosion wear behavior of ZTA ceramics[J]. Journal of Synthetic Crystals, 2013, 42(2): 257 − 261
[2] 文瑞龙, 房明浩, 闵 鑫, 等. ZrO2添加量对ZTA陶瓷力学性能及冲蚀磨损行为的影响[J]. 人工晶体学报, 2013, 42(2): 257 − 261 [3] Li Zhuoran, Gu Wei, Feng Jicai. Research status of ceramic and metal connection[J]. Welding & Joining, 2008(3): 55 − 60
[4] 李卓然, 顾 伟, 冯吉才. 陶瓷与金属连接的研究现状[J]. 焊接, 2008(3): 55 − 60 [5] Liu Huijie, Feng Jicai. Method and application of ceramic and metal connection[J]. Welding & Joining, 1999(6): 5 − 9
[6] Fernie J A, Drew R A L, Knowles K M. Joining of engineering ceramics[J]. Metallurgical Reviews, 2009, 54(5): 283 − 331.
[7] Yang Minxuan, Lin Tiesong, Han Chun, et al. Effects of process parameters on the interface structure and mechanical properties of Al2O3/TC4 alloy joints[J]. Transactions of the China Welding Institution, 2012, 33(8): 53 − 56
[8] Rohde M, Südmeyer I, Urbanek A, et al. Joining of alumina and steel by a laser supported brazing process[J]. Ceramics International, 2009, 35(1): 333 − 337.
[9] Zhu Dingyi, Wang Yonglan. Mechanism and thermodynamic calculation of interface reaction between Ti filler and Al2O3[J]. Ordnance Material Science and Engineering, 1998, 21(2): 22 − 26
[10] 刘会杰, 冯吉才. 陶瓷与金属的连接方法及应用[J]. 焊接, 1999(6): 5 − 9 [11] Yang Z, Lin J, Wang Y, et al. Characterization of microstructure and mechanical properties of Al2O3/TiAl joints vacuum-brazed with Ag-Cu-Ti+W composite filler[J]. Vacuum, 2017, 143: 294 − 302.
[12] Lin G, Huang J, Zhang H. Joints of carbon fiber-reinforced SiC composites to Ti-alloy brazed by Ag–Cu–Ti short carbon fibers[J]. Journal of Materials Processing Technology, 2007, 189(1): 256 − 261.
[13] 杨敏旋, 林铁松, 韩 春, 等. 工艺参数对 Al2O3/TC4合金接头界面组织及力学性能的影响[J]. 焊接学报, 2012, 33(8): 53 − 56 [14] Dai Xiangyu, Cao Jian, Wang Dong, et al. Interfacial reaction behavior and mechanical characterization of ZrO2/TC4 joint brazed by Ag–Cu filler metal[J]. Materials Science and Engineering: A, 2015, 646: 182 − 189.
[15] 朱定一, 王永兰. 含Ti钎料与Al2O3界面反应的机理及热力学计算[J]. 兵器材料科学与工程, 1998, 21(2): 22 − 26 [16] Kozlova O, Braccini M, Voytovych R, et al. Brazing copper to alumina using reactive cuagti alloys[J]. Acta Materialia, 2010, 58(4): 1252 − 1260.
-
