Mechanism and mechanical property of Si-glass-Si anodic bonding process
-
摘要: 采用两步法阳极键合技术成功实现了硅-玻璃-硅的连接. 两次键合过程中,电流特征有明显差异,第一次键合电流先迅速增大到峰值电流,然后迅速衰减至一较小值. 受先形成Na+离子耗尽层的影响,第二次键合电流从峰值电流衰减的过程中,出现二次增大然后衰减的现象. 利用扫描电镜对键合界面进行观察,结果表明玻璃两侧界面均键合良好,玻璃表面可观察到大量析出物. 利用万能材料试验机对键合强度进行测试,结果表明,界面强度随着键合电压的升高而增大. 断裂主要发生在玻璃基体内部靠近第二次键合界面一侧.Abstract: Si-glass-Si was successfully bonded together through a two-step anodic bonding process. The bonding current in each step of the two-step bonding process was investigated, and found to be quite different. The first bonding current decreased quickly to a relatively small value. But for the second bonding step, there were two current peaks, the current varified as decrease-increase-decreased rule. SEM was conducted to investigate the interfacial structure of the Si-glass-Si samples. Tensile tests indicated that the fracture occurred at the glass substrate and bonding strength increased with the increment of the bonding voltage.
-
Keywords:
- anodic bonding /
- Si-glass-Si /
- electronic packaging /
- bonding strength
-
-
[1] Wallis G, Pomerantz I. Field assisted glass-metal sealing[J]. Journal of Applied Physics, 1969, 40(10): 3946 − 3949.
[2] Liu Cuirong, Meng Qingsen, Hu Lifang, et al. Microstructure and bonding mechanism of anodic bonded interface between Pyrex glass and Kovar alloy[J]. Transactions of the China Welding Institution, 2008, 29(2): 73 − 76
[3] Yin Xu, Liu Cuirong, Du Chao, et al. Solid electrolyte and anodic properties of the polymer Al[J]. Transactions of the China Welding Institution, 2015, 136(11): 37 − 40
[4] Xiong D, Cheng J, Li H, et al. Anodic bonding of glass–ceramics to stainless steel coated with intermediate SiO2 layer[J]. Microelectronic Engineering, 2010, 87(9): 1741 − 1746.
[5] Qin Huifeng, Meng Qingsen. Mechanism analysis of anodic bonding between glass/aluminum/glass layer[J]. Ordnance Material Science and Engineering, 2012, 35(1): 32 − 34
[6] Joyce R, Singh K, Varghese S, et al. Stress reduction in silicon/oxidized silicon–Pyrex glass anodic bonding for MEMS device packaging: RF switches and pressure sensors[J]. Journal of Materials Science Materials in Electronics, 2014, 26(1): 411 − 423.
[7] Hsu Y W, Chen J Y, Chien H T, et al. New capacitive low-g triaxial accelerometer with low cross-axis sensitivity[J]. Journal of Micromechanics & Microengineering, 2010, 20(5): 477 − 480.
[8] Gopal R. Fabrication of MEMS xylophone magnetometer by anodic bonding technique using SOI wafer[J]. Springer-Verlag, 2017, 23(1): 81 − 90.
[9] 刘翠荣, 孟庆森, 胡立方, 等. Pyrex玻璃与Kovar合金阳极键合界面微观结构及其形成机制[J]. 焊接学报, 2008, 29(2): 73 − 76 [10] Yang C R, Wu J W, Chang L Y. Design and implementation of a novel conical electrode for fast anodic bonding[J]. Journal of Micromechanics & Microengineering, 2014, 24(10): 105003.
[11] Tang J, Cai C, Ming X, et al. Morphology and stress at silicon-glass interface in anodic bonding[J]. Applied Surface Science, 2016, 387: 139 − 148.
[12] 阴 旭, 刘翠荣, 杜 超, 等. 无机填料对高分子固体电解质与金属铝键合性能的影响[J]. 焊接学报, 2015, 136(11): 37 − 40 [13] Daschner R, Baur H, Pfau T. Triple stack glass-to-glass anodic bonding for optogalvanic spectroscopy cells with electrical feedthroughs[J]. Applied Physics Letters, 2014, 105(4): 041107 − 041107–4.
[14] 秦会峰, 孟庆森. 玻璃/铝/玻璃三层结构阳极键合机理分析[J]. 兵器材料科学与工程, 2012, 35(1): 32 − 34 [15] 陆春意. 基于电流控制的阳极键合工艺方法及实验研究[D]. 苏州: 苏州大学, 2015. [16] Albaugh K B, Rasmussen D H. Rate processes during anodic bonding[J]. Journal of the American Ceramic Society, 1992, 75(75): 2644 − 2648.
-
