Mathematical model of rotating arc sensor based on actual deposited metal of the weld pool
-
摘要: 旋转电弧传感器数学模型是提高焊接质量、旋转电弧信号处理和焊缝偏差提取的理论基础, 焊接熔敷金属堆积形状是决定旋转电弧长度主要因素之一，影响其数学模型精确度. 采用双线结构光传感系统对焊接收弧阶段焊缝进行三维重建获得焊接熔池熔敷形状，运用单纯形法最优化电弧长度，在此基础上建立了旋转电弧传感器数学模型及仿真模型. 结果表明，该数学模型相对于假设的三角锥熔敷形状数学模型，消除了焊接过程工件变形引起的电流信号误差，减小了焊缝转角和焊缝偏差检测误差，提高了旋转电弧传感器数学模型精度.Abstract: Mathematical model of rotating arc welding system is the theoretical basis of obtaining better welding quality, rotating arc signal processing and welding seam deviation extraction. The shape of weld pool has a great effect on the length of welding arc, thus affecting the accuracy of the mathematical model. Using double line structured-light vision sensor scanned the weld shape of weld ending stage and then reconstructed three-dimensional deposited metal shape of weld pool shape, selecting the simplex method to solve the length of welding arc. On this basis, the mathematical model of the rotating arc welding system and simulation model is established. The results showed that compared with the mathematical model based on triangular cone weld pool shape, the one based on the shape of the actual deposited metal of weld pool can effectively eliminate the current signal error caused by the deformation of the work piece during the welding process and decrease the error of weld rotation and weld seam deviation identification, thus the mathematical model of rotating arc welding is improved.
-
-
[1] Wu Shide, Liao Baojian, Pan Jiluan. High speed rotating arc sensor[J]. Transactions of the China Welding Institution, 1997, 18(1): 63 − 68
[2] Halmoy E. Simulation of rotational arc sensing in gas metal arc welding[J]. Science and Technology of Welding and Joining, 1999, 4(6): 347 − 351.
[3] Shi Yonghua, Wang Guorong, YOO Won-Sang, et al. Mathematical model of high speed rotational arc sensor[J]. Journal of Mechanical Engineering, 2007, 43(11): 217 − 223
[4] Pan J L. Arc sensing system for automatic weld seam tracking(Ⅰ)-mathematic model[J]. Science in China(Series E: Technological Sciences), 2001, 44(03): 252 − 257.
[5] Shi Yonghua, Zeng Shengsong, Wang Guorong. Sensing signal pattern analysis of high-speed rotational arc in GMAW[J]. Transactions of the China Welding Institution, 2010, 31(6): 33 − 36
[6] 吴世德, 廖宝剑, 潘际銮. 高速旋转电弧传感器[J]. 焊接学报, 1997, 18(1): 63 − 68 [7] Zhou Longzao, Liu Shunhong, Ding Dongping. Rapid prototyping technology based on three-dimensional welding deposition[J]. Electromachining & Mould, 2004, 39(4): 1 − 5
[8] Kim C H, Na S J. A study of an arc sensor model for gas metal arc welding with rotating arc - part 1: dynamic simulation of wire melting[J]. Proceedings of the Institution of Mechanical Engineers - Part B, London, 2001, 215(9): 1271 − 1279.
[9] Mao Zhiwei, Zhou Shaoling, Zhao Bin, et al. Welding torch position and seam orientation deviation based on two stripes laser vision sensing[J]. Transactions of the China Welding Institution, 2015, 36(2): 35 − 38
[10] Kim C H, Na S J. A study of an arc sensor model for gas metal arc welding with rotating arc-part 2: dynamic simulation of wire melting[J]. Proceedings of the Institution of Mechanical Engineers-Part B, London, 2001, 215(9): 1281 − 1288.
[11] 石永华, 王国荣, YOO Won-Sang, 等. 高速旋转电弧传感器的数学模型[J]. 机械工程学报, 2007, 43(11): 217 − 223 [12] 石永华, 曾盛松, 王国荣. GMAW焊高速旋转电弧传感信号特征分析[J]. 焊接学报, 2010, 31(6): 33 − 36 [13] 周龙早, 刘顺洪, 丁冬平. 基于三维焊接熔敷的快速成形技术[J]. 电加工与模具, 2004, 39(4): 1 − 5 [14] 毛志伟, 周少玲, 赵 滨, 等. 双线激光传感焊枪定位与焊缝走向识别[J]. 焊接学报, 2015, 36(2): 35 − 38 [15] 毛志伟. 交叉式双线激光视觉传感焊枪高度实时识别系统及识别方法:中国, 201510050920.9[P]. 2015-02-02.
