薄板对接超声疲劳试样设计方法及其误差分析
Design method and error analysis of thin plate butt welded joint specimen for ultrasonic fatigue test
-
摘要: 采用解析法得到了含中部等截面段狗骨形薄板超声疲劳试样谐振长度的计算公式，并得出沿谐振长度方向的位移及应力幅分布函数. 为了验证上述计算方法用于薄板对接超声疲劳试样设计的精确度，对考虑与不考虑焊缝余高时的薄板试样与薄板对接试样分别建立有限元模型并进行模态分析. 结果表明，采用上述计算方法进行薄板超声疲劳试样设计的频率误差小于1%，且对比得出由于焊缝余高的存在使得其频率误差增大约1.7%. 另外，采用上述方法设计了低合金钢Q345薄板对接超声疲劳试样，通过超声疲劳试验进一步验证了上述方法的精确度.
-
关键词:
- 超声疲劳|试样设计|有限元|误差
Abstract: The calculation formula of the resonance length of the dog-bone-shaped thin plate specimen with middle equal section for ultrasonic fatigue test was obtained by analytical solution, meanwhile the distribution functions of the displacement and stress amplitude along the resonance length were given. Considering weld reinforcement or not, finite element models of thin plate specimen and thin plate butt specimen were built respectively, and then modal results were analyzed. The results showed that the relative frequency error of the analytical method is less than 1%, while the frequency error caused by the weld reinforcement increased by about 1.7%. Moreover, the thin plate butt specimen of low-alloy steel Q345 was designed based on the above method, and then ultrasonic fatigue tests were conducted to verify the accuracy of the resonant frequency. -
-
[1] 霍立兴. 焊接结构的断裂行为及评定[M]. 北京: 机械工业出版社, 2000. [2] 贾安东. 焊接结构与生产[M]. 北京: 机械工业出版社, 2007. [3] 吴良晨,王东坡,王 胜, 等. 超声频分量双周疲劳载荷作用下焊接接头疲劳行为[J]. 焊接学报, 2009, 30(5): 9 ? 12
Wu Liangchen, Wang Dongpo, Wang Sheng, et al. Fatigue behavior of welded joints under combined cycle fatigue with ultrasonic component[J]. Transactions of the China Welding Institution, 2009, 30(5): 9 ? 12[4] 陶 华. 超声疲劳研究[J]. 航空学报, 1998, 19(2): 228 ? 231
Tao Hua. Progress of ultrasonic fatigue[J]. Acta Aeronautica Et Astronautica Sinica, 1998, 19(2): 228 ? 231[5] Wang Q Y, Berard J Y, Bathias C, et al. High-cycle fatigue crack initiation and propagation behaviour of high-strength spring steel wires[J]. Fatigue and Fracture of Engineering Materials and Structures, 1999, 22(8): 673 ? 677. [6] 王清远. 超声加速疲劳实验研究[J]. 四川大学学报, 2002, 34(3): 006 ? 011
Wang Qingyuan. Accelerated fatigue testing by ultrasonic loading[J]. Journal of Sichuan University, 2002, 34(3): 006 ? 011[7] 薛红前. 超声疲劳试样设计[J]. 航空学报, 2004, 25(4): 425 ? 428
Xue Hongqian. The design of specimen for fatigue test at ultrasonic frequency[J]. Acta Aeronautica Et Astronautica Sinica, 2004, 25(4): 425 ? 428[8] Matikas T E. Specimen design for fatigue testing at very high frequencies[J]. Journal of Sound and Vibration, 2001, 247: 673 ? 681. [9] 王 弘. 超声疲劳扭转试样谐振长度的解析法计算[J]. 西南交通大学学报, 2001, 36(6): 595 ? 598
Wang Hong. Analytical solution of the resonance length for ultrasonic torsional fatigue samples[J]. Journal of South west Jiaotong University, 2001, 36(6): 595 ? 598[10] 吴良辰. 超声频分量双周疲劳载荷作用下焊接接头的疲劳性能[D]. 天津: 天津大学, 2008. -
