304不锈钢/Q235钢的多层爆炸焊接

杨明,马宏昊,沈兆武,李雪交,王波

杨明,马宏昊,沈兆武,李雪交,王波. 304不锈钢/Q235钢的多层爆炸焊接[J]. 焊接学报, 2019, 40(1): 65-70. DOI: 10.12073/j.hjxb.2019400013
引用本文: 杨明,马宏昊,沈兆武,李雪交,王波. 304不锈钢/Q235钢的多层爆炸焊接[J]. 焊接学报, 2019, 40(1): 65-70. DOI: 10.12073/j.hjxb.2019400013
shu
YANG Ming, MA Honghao, SHEN Zhaowu, LI Xuejiao, WANG Bo. Multi-layer explosive welding of 304 stainless steel to Q235 steel[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(1): 65-70. DOI: 10.12073/j.hjxb.2019400013
Citation: YANG Ming, MA Honghao, SHEN Zhaowu, LI Xuejiao, WANG Bo. Multi-layer explosive welding of 304 stainless steel to Q235 steel[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(1): 65-70. DOI: 10.12073/j.hjxb.2019400013
shu

304不锈钢/Q235钢的多层爆炸焊接

Multi-layer explosive welding of 304 stainless steel to Q235 steel

摘要

    摘要
  • 摘要: 为解决传统爆炸焊接中能量利用率和工作效率较低的问题，提出了一种多层爆炸焊接新方法.以五层爆炸焊接为例，304不锈钢板和Q235钢板分别作为复板和基板，进行了多层爆炸焊接和传统单层爆炸焊接的对比试验，并对爆炸焊接窗口和复板碰撞速度进行了理论计算. 结果表明，与传统爆炸焊接技术相比，五层爆炸焊接中可节省炸药量63%，并且五层爆炸焊接技术通过一次爆炸作业可获得五块焊接板，有利于提高爆炸焊接作业的工作效率. 此外，得到了304不锈钢和Q235钢的爆炸焊接窗口并对结合质量进行了预测，试验和预测结果吻合良好.
    Abstract: In order to solve the problem of low energy efficiency and low work efficiency in existing explosive welding, a new multi-layer explosive welding technology was proposed. In the case of five-layer explosive welding, 304 stainless steel and Q235 steel were used for flyer plate and base plate respectively. Comparison tests of multi-layer explosive welding and existing single-layer explosive welding were carried out. The explosive welding window and the impact velocity of the flyer plate were calculated theoretically. The result showed that energy utilization of the five-layer explosive welding increased by 63% compared to the existing explosive welding technology, and the five-layer explosive welding technology obtained five welded plates through one shot, which improved the working efficiency of the explosive welding. In addition, the explosive welding window of SUS304/Q235 was obtained and the welding quality was predicted, the experiment and prediction were in good agreement.
    • HTML全文
    • 参考文献(20)
  • [1] Kahraman N, Gülen? B. Microstructural and mechanical properties of Cu-Ti plates bonded through explosive welding process[J]. Journal of Materials Processing Technology, 2005, 169(1): 67 ? 71.
    [2] Mousavi S A A A, Sartangi P F. Experimental investigation of explosive welding of cp-titanium/AISI 304 stainless steel[J]. Materials and Design, 2009, 30(3): 459 ? 468.
    [3] 郑远谋. 爆炸焊接和爆炸复合材料的原理及应用[M]. 长沙: 中南大学出版社, 2007.
    [4] Findik F. Recent developments in explosive welding[J]. Materials and Design, 2011, 32(3): 1081 ? 1093.
    [5] 史长根, 尤 峻. 双立式爆炸焊接新方法[J]. 爆破器材, 2008, 37(3): 28 ? 30
    Shi Changgen, You Jun. New technology of double vertical explosive welding[J]. Explosive Materials, 2008, 37(3): 28 ? 30
    [6] 缪广红, 马宏昊, 沈兆武, 等. 蜂窝结构炸药及其应用[J]. 含能材料, 2014, 22(5): 693 ? 697
    Miu Guanghong, Ma Honghao, Shen Zhaowu, et al. Explosive with structure of honeycomb and its application[J]. Chinese Journal of Energetic Materials, 2014, 22(5): 693 ? 697
    [7] 史长根, 汪 育, 徐 宏. 双立爆炸焊接及防护装置数值模拟和试验[J]. 焊接学报, 2012, 33(3): 109 ? 112
    Shi Changgen, Wang Yu, Xu Hong. Numerical simulation and experimental research of double vertical explosive welding and its safeguard[J]. Transactions of the China Welding Institution, 2012, 33(3): 109 ? 112
    [8] Athar M M H, Tolaminejad B. Weldability window and the effect of interface morphology on the properties of Al/Cu/Al laminated composites fabricated by explosive welding[J]. Materials and Design, 2015, 86: 516 ? 525.
    [9] Mendes R, Ribeiro J B, Loureiro A. Effect of explosive characteristics on the explosive welding of stainless steel to carbon steel in cylindrical configuration[J]. Materials and Design, 2013, 51(51): 182 ? 192.
    [10] Li X, Ma H, Shen Z. Research on explosive welding of aluminum alloy to steel with dovetail grooves[J]. Materials and Design, 2015, 87: 815 ? 824.
    [11] Carvalho G H S F L, Mendes R, Leal R M, et al. Effect of the flyer material on the interface phenomena in aluminium and copper explosive welds[J]. Materials and Design, 2017, 122: 172 ? 183.
    [12] 杨 明, 马宏昊, 沈兆武, 等. 304不锈钢/Q235钢的多面约束装药爆炸焊接[J]. 含能材料, 2018, 26(5): 377 ? 382
    Yang Ming, Ma Honghao, Shen Zhaowu, et al. Explosive welding of 304 stainless steel to Q235 steel with multidimensional constraint charge[J]. Chinese Journal of Energetic Materials, 2018, 26(5): 377 ? 382
    [13] Cowan G R, Bergmann O R, Holtzman A H. Mechanism of bond zone wave formation in explosion-clad metals[J]. Metallurgical and Materials Transactions B, 1971, 2(11): 3145 ? 3155.
    [14] Abrahamson G R. Permanent periodic surface deformations due to a traveling jet[J]. Journal of Applied Mechanics, 1961, 83: 519 ? 528.
    [15] Zukas J A, Walters W P. Explosive effects and applications[M]. Springer, 1998.
    [16] Koch A, Arnold N, Estermann M. A simple relation between the detonation velocity of an explosive and its gurney energy[J]. Propellants Explosives Pyrotechnics, 2002, 27(6): 365 ? 368.
    [17] Xia H B, Wang S G, Ben H F. Microstructure and mechanical properties of Ti/Al explosive cladding[J]. Materials and Design, 2014, 56(4): 1014 ? 1019.
    [18] Bina M H, Dehghani F, Salimi M. Effect of heat treatment on bonding interface in explosive welded copper/stainless steel[J]. Materials and Design, 2013, 45: 504 ? 509.
    [19] Acarer M, Gülen? B, Findik F. Investigation of explosive welding parameters and their effects on microhardness and shear strength[J]. Materials and Design, 2003, 24(8): 659 ? 664.
    [20] Hokamoto K, Izuma T, Fujita M. New explosive welding technique to weld[J]. Metallurgical Transactions A, 1993, 24(10): 2289 ? 2297.
