1060Al高频微振激光焊接接头气孔及组织

蔡遵武,卢庆华,张成,张巍

蔡遵武,卢庆华,张成,张巍. 1060Al高频微振激光焊接接头气孔及组织[J]. 焊接学报, 2019, 40(1): 53-58. DOI: 10.12073/j.hjxb.2019400011
引用本文: 蔡遵武,卢庆华,张成,张巍. 1060Al高频微振激光焊接接头气孔及组织[J]. 焊接学报, 2019, 40(1): 53-58. DOI: 10.12073/j.hjxb.2019400011
shu
CAI Zunwu, LU Qinghua, ZHANG Cheng, ZHANG Wei. Porosity and microstructure characteristic of 1060Al laser welded joint under high frequency micro-vibration condition[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(1): 53-58. DOI: 10.12073/j.hjxb.2019400011
Citation: CAI Zunwu, LU Qinghua, ZHANG Cheng, ZHANG Wei. Porosity and microstructure characteristic of 1060Al laser welded joint under high frequency micro-vibration condition[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(1): 53-58. DOI: 10.12073/j.hjxb.2019400011
shu

1060Al高频微振激光焊接接头气孔及组织

Porosity and microstructure characteristic of 1060Al laser welded joint under high frequency micro-vibration condition

摘要

    摘要
  • 摘要: 采用激光和高频微振相耦合的方法焊接5 mm厚的1060Al，研究振动对焊缝成形、气孔尺寸、数量和分布、显微组织及显微硬度的影响规律，并研究了熔池的流动状态对气孔位置分布的影响. 结果表明，当其它激光工艺参数一定，振动频率为1 173 Hz时，组织晶粒细化最为明显，焊缝宏观成形较好，焊接接头可获得最佳表面外观，焊缝中心平均显微硬度从无振动条件下的27.2 HV增加到有振动条件下的29.4 HV，提高8.1%. 振动频率为923 Hz时，气孔能够有效地得到抑制. 振动影响熔池的流动与激光匙孔的稳定性，与焊缝气孔形成具有一定的相关性，表现在气孔逐渐向焊缝表面逸出.
    Abstract: The 5 mm thick 1060Al was welded by the coupling of laser and high-frequency vibration. Vibration effect on welding formation, size, quantity and distribution of porosities, microstructure and microhardness of the joint were researched. The influence of the flow of the molten pool on the hole position distribution was also studied. The results showed that the best welding formation could be got with 1 173 Hz vibration frequency. The grain refinement was the most obvious. The best surface appearance could be obtained. The average value of welding zone microhardness increased from 27.2 HV without vibration to 29.4 HV with vibration, which increased by 8.1%. Under the condition that vibration frequency was 923 Hz, the porosities were effectively suppressed. The flow of the molten pool and the stability of laser keyhole were influenced by frequency of micro-vibration which had certain relevance with the welding porosity formation. The pores were gradually gathered to the welding surface with frequency of vibration increasing.
    • HTML全文
    • 参考文献(17)
  • [1] 卢庆华, 陈立功, 于治水. 基于内耗的振动焊接焊缝力学分析[J]. 机械工程学报, 2010, 46(20): 97 ? 100
    Lu Qinghua, Chen Ligong, Yu Zhishui. Mechanical analysis of vibration welding seam based on internal friction[J]. Journal of Mechanical Engineering, 2010, 46(20): 97 ? 100
    [2] Lu Q H, Chen L G, Ni C Z. Improving welded valve quality by vibratory weld conditioning[J]. Materials Science and Engineering A, 2007, 457(1?2): 246 ? 253.
    [3] Tsai T C, Chou C C, Tsai D M, et al. Modeling and analyzing the effects of heat treatment on the characteristics of magnesium alloy joint welded by the tungsten-arc inert gas welding[J]. Materials and Design, 2011, 32(8?9): 4187 ? 4194.
    [4] Puga H, Costa S, Barbosa J, et al. Influence of ultrasonic melt treatment on microstructure and mechanical properties of AlSi9Cu3 alloy[J]. Journal of Materials Processing Technology, 2011, 211(11): 1729 ? 1735.
    [5] 苏允海, 马大海, 林金梁, 等. 高强钢振动焊接工艺参数的优化[J]. 焊接学报, 2014, 35(7): 105 ? 108
    Su Yunhai, Ma Dahai, Lin Jinliang, et al. Optimization of vibration welding parameters for high strength steel[J]. Transactions of the China Welding Institution, 2014, 35(7): 105 ? 108
    [6] Mostafapour A, Gholizadeh V. Experimental investigation of the effect of vibration on mechanical properties of 304 stainless steel welded parts[J]. The International Journal of Advanced Manufacturing Technology, 2014, 70: 1113 ? 1124.
    [7] Kimb J, Sony R, Yunj O, et al. Residual stress relief and redistribution of welded metals by vibratory stress relaxation[J]. Materials Science Forum, 2008, 580: 419 ? 423.
    [8] Govindarao P, Srinivasarao P, Gopalakrishna A, et al. Improvement of tensile strength of butt welded joints prepared by vibratory process[J]. International Journal of Mechanical Engineering and Technology(IJMET), 2013, 4(4): 53 ? 61.
    [9] Govindarao P, Srinivasarao P, Gopalakrishna A, et al. Effect of vibratory process to improve the mechanical properties of butt welded joints[J]. International Journal of Modern Engineering Research, 2012, 2(4): 2766 ? 2770.
    [10] 孟 强, 王怡高, 刘小超, 等. 6061-T6铝合金板超声振动强化搅拌摩擦焊接头组织与性能[J]. 焊接学报, 2015, 36(4): 49 ? 53
    Meng Qiang, Wang Yigao, liu Xiaochao, et al. Microstructure and properties of 6061-T6 aluminum alloy plate reinforced by ultrasonic vibration enhanced friction stir welding[J]. Transactions of the China Welding Institution, 2015, 36(4): 49 ? 53
    [11] Tong W, Liu S , Chen S. Influence of high frequency vibration on microstructure and mechanical properties of TIG welding joints of AZ31 magnesium alloy[J]. Transactions of Nonferrous Metals Society of China, 2015, 25(2): 397 ? 404.
    [12] 龚玉兵, 王善林, 陈玉华, 等. FeSiB非晶薄带激光焊焊缝成形及接头力学性能[J]. 中国激光, 2016, 43(3): 0303001
    Gong Yubing, Wang Shanlin, Chen Yuhua. Weld formation and mechanical properties of FeSiB amorphous ribbons in laser welding[J]. Chinese Journal of Laser, 2016, 43(3): 0303001
    [13] AKuryntsev S V , Gilmutdinov A K. Welding of stainless steel using defocused laser beam[J]. Journal of Constructional Steel Research, 2015, 114: 305 ? 313.
    [14] 彭必荣, 卢庆华, 何晓峰, 等. 机械振动对激光焊接接头组织的影响[J]. 机械工程学报, 2015, 51(20): 94 ? 100
    Peng Birong, Lu Qinghua, He Xiaofeng, et al. Effect of mechanical vibration on microstructure of laser welded joint[J]. Journal of Mechanical Engineering, 2015, 51(20): 94 ? 100
    [15] 卢庆华. 振动对焊接接头组织与性能的影响及其工程应用[D]. 上海: 上海交通大学, 2008.
    [16] 姚良均, 李震夏, 武　恭, 等. 铝及铝合金材料手册[M]. 北京: 科学出版社, 1994.
    [17] Ray C S, Fang X, Day D E. New method for determining the nucleation and crystal-growth rates in glasses[J]. Journal of the American Ceramic Society, 2010, 83(4): 865 ? 872.
