钛锆钼合金与钨铼合金的SPS扩散焊接
Diffusion bonding between TZM alloy and WRe alloy by spark plasma sintering
-
摘要: 采用放电等离子烧结(SPS)技术对TZM合金与WRe合金进行固相扩散焊接，研究了TZM/WRe接头的微观组织、力学性能和热疲劳性能. 结果表明，SPS扩散焊接技术在1 500 ℃保温30 min成功实现了TZM合金与WRe合金的高效连接，焊缝平整，无微裂纹、微孔洞和未焊合等焊接缺陷；TZM合金与WRe合金扩散焊接过程中均发生了再结晶，与W和Re相比，Mo具有较低的自扩散激活能，导致Mo的扩散深度大于W和Re在TZM合金中的扩散深度；TZM/WRe接头经历100次热震试验后，焊缝完好无裂纹，且部分再结晶Mo晶粒跨界生长；TZM/WRe接头的抗弯强度和抗剪强度分别为910 MPa±65 MPa，497 MPa±50 MPa，断裂失效发生在TZM合金一侧，断裂模式主要为穿晶解理断裂.Abstract: Solid-state diffusion bonding of TZM alloy to WRe alloy was performed using spark plasma sintering (SPS). The microstructure, mechanical properties and thermal fatigue of the TZM/WRe joint were investigated in detail. The results showed that successful solid-state diffusion bonding was achieved between TZM alloy and WRe alloy using SPS at temperature of 1 500 °C for 30 min. The TZM/WRe interface is free from discontinuities or microcracks. Recrystallization occurs in both the TZM alloy and WRe alloy during diffusion bonding. comparison with W and Re, the diffuse depth of Mo is greater than that of W and Re in the TZM alloy, due to its lower self-diffusion activation energy. The TZM/WRe joint shows excellent resistant ability to thermal shock and part of Mo grains grow through the TZM/WRe interface after enduring 100-cycles thermal shock. The bending strength and shearing strength of the TZM/WRe joint are 910 MPa±65 MPa, 497 MPa±50 MPa, respectively. Fracture occurs in the TZM alloy, and the fracture mode is dominated by transgranular cleavage fracture.
-
-
[1] 康轩齐, 王快社, 张 郑, 等. 掺镧方式对La-TZM合金性能的影响[J]. 稀有金属材料与工程, 2015, 44(5): 1254 ? 1258
Kang Xuanqi, Wang Kuaishe, Zhang Zheng, et al. Effect of lanthanum doping method on properties of La-TZM alloy[J]. Rare Metal Materials and Engineering, 2015, 44(5): 1254 ? 1258[2] 王 峰, 郑 欣, 李来平, 等. 钨铼合金制备方法和高温力学性能的研究进展[J]. 中国钨业, 2014, 29(2): 37 ? 40
Wang Feng, Zheng Xin, Li Laiping, et al. Research advances on the preparation technology and high temperature mechanical properties of tungsten rhenium alloy[J]. China Tungsten Industry, 2014, 29(2): 37 ? 40[3] 王跃明, 陈梦华, 李 月, 等. W-Re合金构件气氛保护等离子喷涂成形技术[J]. 航空材料学报, 2016, 36(4): 24 ? 34
Wang Yueming, Chen Menghua, Li Yue, et al. Near-net-shape tungsten-rhenium alloy parts produced by shrouded plasma spray forming[J]. Journal of Aeronautical Materials, 2016, 36(4): 24 ? 34[4] Rieth M, Dudarev S L, de Vicente S M G, et al. Recent progress in research on tungsten materials for nuclear fusion applications in Europe[J]. Journal of Nuclear Materials, 2013, 432: 482 ? 500. [5] 刘 奇, 刘庆宾, 陈德茂, 等. 高均匀性W3Re热电偶材料的制备及性能研究[J]. 材料导报, 2010, 24(15): 369 ? 371
Liu Qi, Liu Qingbin, Chen Demao, et al. Study on preparation and properties of a W3Re thermocouple material with high uniformity[J]. Materials Review, 2010, 24(15): 369 ? 371[6] 张国栋, 洪 敏, 张建强, 等. 基于SPS技术的异种钢焊接[J]. 焊接学报, 2009, 30(2): 141 ? 144
Zhang Guodong, Hong Min, Zhang Jianqiang, et al. Research on dissimilar steel welding via spark plasma sintering[J]. Transactions of The China Welding Institution, 2009, 30(2): 141 ? 144[7] Grasso S, Sakka Y, Maizza G. Electric current activated/assisted sintering (ECAS): a review of patents 1906-2008[J]. Science and Technology of Advanced Materials, 2009, 10(5): 053001. [8] Munir Z A, Quach D V, Ohyanagi M. Electric current activation of sintering: a review of the pulsed electric current sintering process[J]. Journal of American Ceramic Society, 2011, 94(1): 1 ? 19. [9] R?thel J, Herrmann M, Beckert W. Temperature distribution for electrically conductive and non-conductive materials during field assisted sintering (FAST)[J]. Journal of the European Ceramic Society, 2009, 29(8): 1419 ? 1425. [10] Nagasaki S, Hirabayashi M. Binary alloy phase-diagrams[M]. Tokyo: AGNE Gijutsu Center, Co., Ltd., 2002. -
