P-GMAW电源外特性对焊接过程稳定性的影响
Influence of power source output characteristic on stability of P-GMAW process
-
摘要: 设计了一套具有阶梯外特性的脉冲熔化极气体保护焊(P-GMAW)电源，可根据负载工作点自动选择恒流、恒压、短路或空载特性. 研究了P-GMAW电源外特性对Q235低碳钢焊接过程稳定性的影响. 结果表明，基值为恒压特性时，电弧稳定性差，易熄弧或短路. 基值为恒流特性可减少飞溅及熄弧现象，但不能消除短路倾向. 基值为阶梯外特性，可有效减少甚至消除短路或熄弧现象，焊接过程稳定性好. 采用基值阶梯特性加峰值恒压特性组合时电弧稳定，抗干扰能力强，无飞溅及断弧现象，焊缝成形均匀.Abstract: A pulsed gas metal arc welding (P-GMAW) power source with stepped external characteristic was developed using a BUCK main circuit topology. The external characteristic was set automatically to be constant current, constant voltage, short circuit or open circuit according to the arc working point. Experiments were carried out on Q235 mild steel to investigate the influence of different output characteristics on P-GMAW process. The results indicated that the arc was lack of stability when applying constant voltage characteristic at background time, making it easy to occur arc extinction or short-circuiting. When constant current characteristic was applied during background time, on the other hand, arc extinguishment and spatters were reduced, but short-circuiting still existed. However, adopting stepped characteristic could effectively decline or even eliminate short-circuiting and arc extinguishment phenomena, resulting in pleasant stability. Using stepped characteristic at background time and constant voltage characteristic at peak time, the arc had strong interference resistant capability, and the welding process is most stable among the experiments resulting in a uniform weld appearance without any spatter and arc interruption.
-
-
[1] ?Kah P, Suoranta R, Martikainen J. Advanced gas metal arc welding processes[J]. International Journal of Advanced Manufacturing Technology, 2013, 67(1–4): 655 ? 674. [2] Praveen P, Yarlagadda P K D V, Kang M J. Advancements in pulse gas metal arc welding[J]. Journal of Materials Processing Technology, 2005, 164(20): 1113 ? 1119. [3] Ghosh P K, Dorn L, Hübner M, et al. Arc characteristics and behaviour of metal transfer in pulsed current GMA welding of aluminium alloy[J]. Journal of Materials Processing Technology, 2007, 194(1–3): 163 ? 175. [4] Castner H R. Gas metal arc welding fume generation using pulsed current[J]. Welding Journal, 1995, 74(2): 59s ? 68s. [5] Thamodharan M, Beck H P, Wolf A. Steady and pulsed direct current welding with a single converter[J]. Welding Journal, 1999, 78(3): 75s ? 79s. [6] 胡绳荪. 现代弧焊电源及其控制[M]. 北京: 机械工业出版社, 2015. [7] 丁 韦, 侯启孝, 董玲萱, 等. 铝合金脉冲MIG焊电弧稳定性[J]. 焊接学报, 1996, 17(2): 116 ? 121
Ding Wei, Hou Qixiao, Dong Lingxuan, et al. Arc stability of aluminium alloy pulsed MIG welding[J]. Transactions of the China Welding Institution, 1996, 17(2): 116 ? 121[8] 文元美, 黄石生, 薛家祥, 等. 脉冲MIG焊不稳定过渡过程的观察与分析[J]. 焊接学报, 2008, 29(4): 13 ? 17
Wen Yuanmei, Huang Shisheng, Xue Jiaxiang, et al. Observation and analysis of unstable metal transfer process in pulsed MIG welding[J]. Transactions of the China Welding Institution, 2008, 29(4): 13 ? 17[9] 潘际銮. 现代弧焊控制[M]. 北京: 机械工业出版社, 2000. [10] 王 强. 超音频复合脉冲GMAW电源及电弧稳定性研究[D]. 北京: 北京航空航天大学, 2018. [11] 王 强, 齐铂金, 王义朋,等. 超音频复合脉冲GMAW电源设计[J]. 北京航空航天大学学报, 2017, 43(10): 1953 ? 1959
Wang Qiang, Qi Bojin, Wang Yipeng, et al. Design of hybrid ultrasonic frequency pulsed GMAW power source[J]. Journal of Beijing University of Aeronautics and Astronautics, 2017, 43(10): 1953 ? 1959 -
