焊接电弧图像的边缘检测及其批处理算法
Edges detection and batch algorithm for welding arc images
-
摘要: 借助高速摄像捕捉不同时刻的焊接电弧图像,通过图像处理识别其边缘并提取其特征参数,可以实现对电弧燃烧和焊接过程稳定性的量化评价. 在分析电弧图像灰度特征的基础上,基于传统图像处理和形态学图像处理,提出了电弧图像边缘辨识的2种简化算法,并从程序运行时间和边缘检测精度两方面,对比了传统图像处理的Sobel边缘检测算法与形态学边缘检测算法的优劣. 选取传统图像处理简化算法构建了图像批处理程序,通过在原始电弧图像中添加随机高斯噪声和对TIG-MIG复合电弧图像边缘的准确识别来检验程序的性能. 结果表明,所构建的图像批处理程序有良好抗干扰能力和适用性.
-
关键词:
- 电弧形态|高速摄像|电弧图像|边缘检测
Abstract: By capturing the welding arc images at different time with the help of high-speed camera, and then recognizing their edges and extracting their characteristic parameters via images processing, the quantitative evaluation on the stability of arc burning and welding process could be achieved. On the basis of analyzing the grey characteristics of arc images, two simplified algorithms achieving the edge recognition of arc image were proposed based on the traditional and morphological image processing respectively. And the merits of Sobel edge detection algorithm in traditional image processing and the edge detection method in morphological image processing were compared from the two aspects of the program run time and the edge detection precision of arc image. According to the comparison result, the simplified algorithm of traditional image processing was chosen and applied into the construction of image batch processing algorithm. The performance of the program was tested by adding random gaussian noise to the original arc image and accurately identifying the edge of TIG-MIG hybrid arc image. The results showed that the image batch processing algorithm had good anti-interference ability and applicability. -
-
[1] ?谢志孟, 高向东. 基于视觉传感的焊缝跟踪技术研究和展望[J]. 焊接, 2005(4): 5 ? 9
Xie Zhimeng, Gao Xiangdong. Study and prospect of seam-tracking technology based on vision sensors[J]. Welding & Joining, 2005(4): 5 ? 9[2] Gonzalez R C, Woods R E. Woods. Digital image processing [M]. Beijing: Publishing House of Electronics Industry, 2005. [3] 陈 强, 孙振国. 计算机视觉传感技术在焊接中的应用[J]. 焊接学报, 2001, 22(1): 83 ? 90
Chen Qiang, Sun Zhenguo. Computer vision sensing technology and its application in welding[J]. Transactions of the China Welding Institution, 2001, 22(1): 83 ? 90[4] 都 东, 邹怡蓉, 常保华. 焊接视觉传感及自动跟踪技术的现状与发展[J]. 航空制造技术, 2010(9): 40 ? 42
Du Dong, Zou Yirong, Chang Baohua. Current status and development of welding visual sensor and automatic tracking technology[J]. Welding Technology for Aviation and Aerospace Industry, 2010(9): 40 ? 42[5] 刘向军, 李炜荣, 谢宝河. 触头电弧图像面积与电弧功率及其关系[J]. 电工技术学报, 2015, 30(1): 120 ? 126
Liu Xiangjun, Li Weirong, Xie Baohe. Arc image area and arc power of contacts and their correlation[J]. Transactions of China Electrotechnical Society, 2015, 30(1): 120 ? 126[6] 肖天娇. 焊接TIG电弧的导电机构及其能量分布研究[D]. 北京: 北京工业大学, 2013. [7] 王 聪. DE-GMAW电弧图像处理及匹配算法研究[D]. 南昌: 南昌大学, 2013. [8] 张 铮, 薛桂香, 顾泽苍. 数字图像处理与机器视觉[M]. 北京: 人民邮电出版社, 2010. [9] Yao Lang, Dan Zheng. An improved Sobel edge detection operator[C]//MCEI. Advances in Intelligent Systems Research (130). Atlantis Press, 2016: 590-593. [10] 张宏林. 精通Visual C++数字图像处理典型算法及实现[M]. 北京: 人民邮电出版社, 2008. -
