石墨烯包覆泡沫铜复合中间层钎焊碳/碳复合材料与铌的工艺与性能

王泽宇,霸金,亓钧雷,冯吉才

王泽宇,霸金,亓钧雷,冯吉才. 石墨烯包覆泡沫铜复合中间层钎焊碳/碳复合材料与铌的工艺与性能[J]. 焊接学报, 2018, 39(10): 71-74. DOI: 10.12073/j.hjxb.2018390251
引用本文: 王泽宇,霸金,亓钧雷,冯吉才. 石墨烯包覆泡沫铜复合中间层钎焊碳/碳复合材料与铌的工艺与性能[J]. 焊接学报, 2018, 39(10): 71-74. DOI: 10.12073/j.hjxb.2018390251
shu
WANG Zeyu, BA Jin, QI Junlei, FENG Jicai. Graphene-coated Cu foam interlayer for brazing C/C composite and Nb[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2018, 39(10): 71-74. DOI: 10.12073/j.hjxb.2018390251
Citation: WANG Zeyu, BA Jin, QI Junlei, FENG Jicai. Graphene-coated Cu foam interlayer for brazing C/C composite and Nb[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2018, 39(10): 71-74. DOI: 10.12073/j.hjxb.2018390251
shu

石墨烯包覆泡沫铜复合中间层钎焊碳/碳复合材料与铌的工艺与性能

Graphene-coated Cu foam interlayer for brazing C/C composite and Nb

摘要

    摘要
  • 摘要: 针对石墨烯增强相在焊缝中难以分散均匀、结构完整性差、易团聚等问题. 采用等离子增强化学气相沉积(PECVD)方法在泡沫铜表面原位制备高质量石墨烯，得到石墨烯增强泡沫铜复合中间层. 使用该复合中间层钎焊碳/碳(C/C)复合材料与铌(Nb). 采用Raman, SEM, HRTEM方法表征石墨烯以及钎焊接头的微观组织结构. 结果表明，泡沫铜独特的多孔网络结构使其表面原位生长的高质量石墨烯在焊缝中均匀分布. 同时，石墨烯优异的化学惰性保证了泡沫铜骨架的完整性，并协同石墨烯自身的低线膨胀系数充分发挥了缓解残余应力的作用，有效提高了接头的抗剪强度.
    Abstract: In order to solve the problems such as poor structural integrity, inhomogeneous dispersion and agglomeration of graphene in the brazing seam, PECVD process was utilized for in-situ preparation of high-quality graphene-coated Cu foam composite interlayer prior to being applied to braze C/C composite and Nb. Raman, SEM, HRTEM tests were carried out to characterize the prepared graphene and the brazed joints. The results show that graphene acquired even distribution in the brazing seam with the help of Cu foam, which owned interconnected porosity. Simultaneously, the excellent chemical inertia of graphene inhibited the collapse of Cu foam. Furthermore, based on the synergistic reinforcement effect of Cu foam, with good plastic deformation capacity, and graphene, with extremely low coefficient of linear expansion, the thermal residual stress in the joint has been effectively mitigated. The average shear strength of the joint was evidently improved.
    • HTML全文
    • 参考文献(13)
  • [1] 黄 超, 林铁松, 何 鹏, 等. TiBw/TC4钛合金与C/C复合材料钎焊接头的界面组织结构[J]. 焊接学报, 2011, 32(7): 39 ? 43
    Huang Chao, Lin Tiesong, He Peng, et al. Microstructure of TiBw/TC4 alloy and C/C composite brazed joint[J]. Transactions of the China Welding Institution, 2011, 32(7): 39 ? 43
    [2] 吴永智, 李海刚, 宁利芹, 等. C/C复合材料与高温合金钎焊接头微观组织与性能分析[J]. 宇航材料工艺, 2015(1): 69 ? 72
    Wu Yongzhi, Li Haigang, Ning Liqin, et al. Microstructure and property analysis of the vacuum brazed carbon-carbon composites and high temperature alloys joint[J]. Aerospace Materials & Technology, 2015(1): 69 ? 72
    [3] Zhao L, Hou B J, Li X H. Interfacial structure and mechanical property of Al2O3 and Invar brazed joint[J]. China Welding, 2016, 25(4): 68 ? 73.
    [4] Zhao L M, Yu Hai, Ran W F. Influence of holding time on microstructure and shear strength of Mg alloy/steel joint diffusion bonded with Zn-5Al interlayer[J]. China Welding, 2017, 26(1): 1 ? 8.
    [5] Zhou Y H, Liu D, Niu H W, et al. Vacuum brazing of C/C composite to TC4 alloy using nano-Al2O3 strengthened AgCuTi composite filler[J]. Materials and Design, 2016, 93: 347 ? 356.
    [6] Shirzadi A A, Zhu Y, Bhadeshia H K D H. Joining ceramics to metals using metallic foam[J]. Materials Science & Engineering A, 2008, 496: 501 ? 506.
    [7] Zhu Y, Qi D, Guo W, et al. The braze joint between Al2O3 to 1Cr18Ni9Ti using a nickel foam[J]. Welding in the World, 2015, 59(4): 491 ? 496.
    [8] Lin J H, Luo D L, Chen S L, et al. Control interfacial microstructure and improve mechanical properties of TC4-SiO2f/SiO2 joint by AgCuTi with Cu foam as interlayer[J]. Ceramics International, 2016, 42(15): 16619 ? 16625.
    [9] Hu X, Chan Y C, Zhang K L, et al. Effect of graphene doping on microstructural and mechanical properties of Sn-8Zn-3Bi solder joints together with electromigration analysis[J]. Journal of Alloys and Compounds, 2013, 580: 162 ? 171.
    [10] Song X R, Li H J, Zeng X R, et al. Brazing of C/C composites to Ti6Al4V using graphene nanoplatelets reinforced TiCuZrNi brazing alloy[J]. Materials Letters, 2016, 183: 232 ? 235.
    [11] Lin J H, Jia H N, Cai Y F, et al. Modifying the electrochemical performance of vertically-oriented few-layered graphene through rotary plasma processing[J]. Journal of Materials Chemistry A, 2018, 6(3): 908 ? 917.
    [12] 徐新邦, 刘培生, 崔 光, 等. 泡沫金属力学性能研究的分析概述[J]. 金属功能材料, 2012, 19(6): 46 ? 50
    Xu Xinbang, Liu Peisheng, Cui Guang, et al. Analysis into study on mechanical properties of metal foams[J]. Metallic Functional Materials, 2012, 19(6): 46 ? 50
    [13] Fedele R, Ciani A, Galantucci L, et al. Characterization of innovative CFC/Cu joints by full-field measurements and finite elements[J]. Materials Science & Engineering A, 2014, 595: 306 ? 317.
