不锈钢高频复合双钨极氩弧焊接工艺方法

吴统立,王克鸿,孔见,高琼

吴统立,王克鸿,孔见,高琼. 不锈钢高频复合双钨极氩弧焊接工艺方法[J]. 焊接学报, 2018, 39(10): 20-24. DOI: 10.12073/j.hjxb.2018390242
引用本文: 吴统立,王克鸿,孔见,高琼. 不锈钢高频复合双钨极氩弧焊接工艺方法[J]. 焊接学报, 2018, 39(10): 20-24. DOI: 10.12073/j.hjxb.2018390242
WU Tongli, WANG Kehong, KONG Jian, GAO Qiong. High frequency hybrid twin-electrode TIG welding process for stainless steel[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2018, 39(10): 20-24. DOI: 10.12073/j.hjxb.2018390242
Citation: WU Tongli, WANG Kehong, KONG Jian, GAO Qiong. High frequency hybrid twin-electrode TIG welding process for stainless steel[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2018, 39(10): 20-24. DOI: 10.12073/j.hjxb.2018390242

不锈钢高频复合双钨极氩弧焊接工艺方法

High frequency hybrid twin-electrode TIG welding process for stainless steel

  • 摘要: 针对双钨极TIG焊存在的电弧压力小、焊缝熔深浅等问题,提出了一种新型焊接工艺方法——高频复合双钨极TIG焊(high frequency hybrid twin-electrode TIG welding, HFHT-TIG焊),在双钨极氩弧焊的一个钨极上通以高频脉冲电流,达到提高电弧压力和挺度、搅拌熔池、细化晶粒、改善接头组织和力学性能的目的. 采用HFHT-TIG焊进行了6 mm厚奥氏体不锈钢焊接工艺试验,并与双钨极TIG焊接头进行对比. 结果表明,HFHT-TIG焊能够显著提高电弧挺度和电弧压力,焊缝表面成形更佳,横截面对称性更好,焊缝区的树枝晶组织更加细小,断口韧窝更加均匀和细密,接头的抗拉强度和断后伸长率分别提高了12.1%和30.2%.
    Abstract: In order to solve the problems of small arc pressure and depth of weld in twin-electrode TIG welding, a new type gas tungsten arc welding process of high frequency hybrid twin-electrode TIG welding (HFHT-TIG) was put forward. A high frequency pulse current was added on one tungsten electrode of twin-electrode TIG welding to achieve the purpose of improving the arc pressure and stiffness, stirring the molten pool, refining the grains, improving the microstructure and mechanical properties of the joint. The 6 mm thick austenitic stainless steel welding process test was carried out by HFHT-TIG welding and compared with twin-electrode TIG welding. The results show that HFHT-TIG could significantly increase the arc stiffness and pressure. The surface forming and cross-section symmetry of the weld was better. The microstructure of the weld was tinier. The dimples in the fracture were more uniform and fine. The joint tensile strength and break elongation increased by 12.1% and 30.2%, respectively.
  • [1] Nguyen T C, Weckman D C, Johnson D A, et al. The humping phenomenon during high speed gas metal arc welding[J]. Science and Technology of Welding and Joining, 2005, 10(4): 447 ? 459.
    [2] 齐铂金, 许海鹰, 黄松涛, 等. 超音频脉冲TIG焊电源拓扑及电弧焊适用性[J]. 北京航空航天大学学报, 2009, 35(1): 61 ? 64
    Qi Bojin, Xu Haiying, Huang Songtao, et al. Ultrasonic frequency pulse tungsten inert gas welding power source topology and welding applicability[J]. Journal of Beijing University of Aeronautics and Astronautics, 2009, 35(1): 61 ? 64
    [3] Fujii H, Sato T, Lu S, et al. Development of an advanced A-TIG (AA-TIG) welding method by control of Marangoni convection[J]. Materials Science and Engineering A, 2008, 495(1-2): 296 ? 303.
    [4] Kobayashi K, Nishimura Y, Iijima T, et al. Practical application of high efficiency twin-arc TIG welding method (sedar-TIG) for Pclng storage tank[J]. Welding in the World, 2013, 48(7-8): 35 ? 39.
    [5] Kobayashi K, Yuki M, Tejima A, et al. Development of high efficiency TIG welding method (SEDAR-TIG)[J]. Ishikawajima-Harima Giho, 2002, 35(42): 137 ? 142.
    [6] 吴敏生, 段向阳, 李路明, 等. 电弧超声的激发及其特性研究[J]. 清华大学学报, 1999, 39(6): 110 ? 112
    Wu Minsheng, Duan Xiangyang, Li Luming, et al. Study of arc-ultrasonic excitation and its characteristics[J]. Journal of Tsinghua University: Science and Technology, 1999, 39(6): 110 ? 112
    [7] 吴敏生, 张春雷, 段向阳. 电弧超声的频率响应特性及其谐振机理[J]. 清华大学学报(自然科学版), 1999, 39(11): 97 ? 99
    Wu Minsheng, Zhang Chunlei, Duan Xiangyang. Frequent characteristic and resonant mechanism of arc-excited ultrasonic[J]. Journal of Tsinghua University: Science and Technology, 1999, 39(11): 97 ? 99
    [8] 吴敏生, 何龙标, 李路明, 等. 电弧超声焊接技术[J]. 焊接学报, 2005, 26(6): 40 ? 44
    Wu Minsheng, He Longbiao, Li Luming, et al. Study on the welding technology of arc-ultrasonic[J]. Transactions of the China Welding Institution, 2005, 26(6): 40 ? 44
    [9] 赵家瑞, 孙 栋, 胡绳荪. 高频脉冲TIG焊电弧的阳极行为[J]. 焊接学报, 1992, 13(1): 59 ? 66
    Zhao Jiarui, Sun Dong, Hu Shengsun. Anode behaviour of high frequency pulse TIG welding arc[J]. Transactions of the China Welding Institution, 1992, 13(1): 59 ? 66
    [10] 齐铂金, 许海鹰, 周兴国, 等. 快变换超音频直流脉冲TIG焊[J]. 焊接学报, 2009, 30(7): 57 ? 60
    Qi Bojin, Xu Haiying, Zhou Xingguo, et al. Fast transform ultra-sonic pulse TIG welding[J]. Transactions of the China Welding Institution, 2009, 30(7): 57 ? 60
    [11] 黄鹏飞, 丁 斌, 胡伊通, 等. 超高频脉冲TIG焊电弧形态分析[J]. 焊接学报, 2018, 39(2): 29 ? 32
    Huang Pengfei, Ding Bin, Hu Yitong, et al. Study on arc profile of high frequency TIG welding[J]. Transactions of the China Welding Institution, 2018, 39(2): 29 ? 32
    [12] Yang M, Zheng H, Qi B, et al. Effect of arc behavior on Ti-6Al-4V welds during high frequency pulsed arc welding[J]. Journal of Materials Processing Technology, 2017, 243(5): 9 ? 15.
    [13] Wang F, Wang E, Zhang L, et al. Influence of electromagnetic stirring (EMS) on the microstructure and mechanical property of Incoloy825 super alloy[J]. Journal of Manufacturing Processes, 2017, 26(5): 364 ? 371.
    [14] Yang M, Yang Z, Qi B. Effect of fluid in molten pool on the welds with Ti-6Al-4V during pulsed arc welding[J]. International Journal of Advanced Manufacturing Technology, 2015, 81(5-8): 1007 ? 1016.
    [15] 齐铂金, 许海鹰, 张 伟. 0Cr18Ni9Ti超音频脉冲TIG焊接接头组织与性能[J]. 北京航空航天大学学报, 2009, 35(2): 132 ? 136
    Qi Bojin, Xu Haiying, Zhang Wei. Microstructure and property analysis of 0Cr18Ni9Ti joints welded by ultra-sonic pulse tungsten inert gas welding technology[J]. Journal of Beijing University of Aeronautics and Astronautics, 2009, 35(2): 132 ? 136
