采用两种银基活性钎料钎焊AlN陶瓷与可伐合金的接头组织与性能

朱成俊,李成思,董雪花

朱成俊,李成思,董雪花. 采用两种银基活性钎料钎焊AlN陶瓷与可伐合金的接头组织与性能[J]. 焊接学报, 2018, 39(10): 16-19. DOI: 10.12073/j.hjxb.2018390241
引用本文: 朱成俊,李成思,董雪花. 采用两种银基活性钎料钎焊AlN陶瓷与可伐合金的接头组织与性能[J]. 焊接学报, 2018, 39(10): 16-19. DOI: 10.12073/j.hjxb.2018390241
shu
ZHU Chengjun, LI Chengsi, DONG Xuehua. Microstructure and strength of AlN/Kovar alloy joints brazed with two Ag-based active filler metals[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2018, 39(10): 16-19. DOI: 10.12073/j.hjxb.2018390241
Citation: ZHU Chengjun, LI Chengsi, DONG Xuehua. Microstructure and strength of AlN/Kovar alloy joints brazed with two Ag-based active filler metals[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2018, 39(10): 16-19. DOI: 10.12073/j.hjxb.2018390241
shu

采用两种银基活性钎料钎焊AlN陶瓷与可伐合金的接头组织与性能

Microstructure and strength of AlN/Kovar alloy joints brazed with two Ag-based active filler metals

摘要

    摘要
  • 摘要: 采用Ag-Cu-Ti和Ag-Cu-In-Ti两种活性钎料箔带，分别在860℃/10 min和760℃/10 min两种规范下对AlN与可伐合金(4J29)进行了真空钎焊连接，获得了冶金质量良好的接头. 对接头室温抗剪强度进行了测试，AlN/Ag-Cu-Ti/4J29和AlN/Ag-Cu-In-Ti/4J29两种接头强度分别为126和113 MPa. 微观分析结果表明，两种接头中靠近陶瓷母材附近生成了连续的扩散反应层，结合XRD结果，该层主要由TiN相组成，反应层的厚度对接头强度有影响；钎缝基体区由铜基固溶体、银基固溶体和复杂的Ni(Fe，Co)-Ti化合物组成.
    Abstract: Ag-Cu-Ti and Ag-Cu-In-Ti active filler metals were used to braze AlN ceramic and Kovar alloy in the vacuum brazing furnace. The corresponding brazing parameters were 860 °C/10 min and 760 °C/10 min, respectively, and sound AlN/ Kovar alloy joints were obtained. The shear strengths of AlN/Ag-Cu-Ti/4J29 and AlN/Ag-Cu-In-Ti/4J29 joints were 126 and 113 MPa, respectively. The microanalysis results show that a continuous diffusion layer formed near the ceramic substrate. The TiN phase was detected in the layer by XRD. The thickness of the diffusion layer had obvious effect on the joint strength. Cu(s,s), Ag(s,s) and Ni(Fe, Co)-Ti compounds formed in the brazing seam matrix.
    • HTML全文
    • 参考文献(14)
  • [1] Cao C W, Feng Y B, Qiu T, et al. Effects of isothermal annealing on the oxidation behavior, mechanical and thermal properties of AlN ceramics[J]. Ceramics International, 2017, 43(5): 9334 ? 9342.
    [2] 钟 伟, 邹桂娟. 氧化铝陶瓷金属化层温度分析研究[J]. 真空科学与技术学报, 2016, 36(6): 718 ? 722
    Zhong Wei, Zou Guijuan. Modeling and simulation of temperature field in Al2O3 ceramic metallization[J]. Chinese Journal of Vacuum Science and Technology, 2016, 36(6): 718 ? 722
    [3] 陈 波, 熊华平, 毛 唯, 等. 采用Au基钎料真空钎焊Al2O3陶瓷[J]. 焊接学报, 2016, 37(11): 47 ? 50
    Chen Bo, Xiong Huaping, Mao Wei, et al. Vacuum brazing of Al2O3 ceramic using Au-based brazing filler[J]. Transactions of the China Welding Institution, 2016, 37(11): 47 ? 50
    [4] 鲁燕萍, 高陇桥. AlN陶瓷的薄膜金属化及其与金属的焊接研究[J]. 真空科学与技术学报, 2000, 20(2): 190 ? 193
    Lu Yanping, Gao Longqiao. Surface metallization and welding of aluminum nitride ceramic[J]. Chinese Journal of Vacuum Science and Technology, 2000, 20(2): 190 ? 193
    [5] Zhao L, Hou J B, Li X H. Interfacial structure and mechanical property of A12O3 and Invar brazed joint[J]. China Welding, 2016, 25(4): 68 ? 73.
    [6] Sun Z, Zhang L X, Zhang Z H, et al. Microstructure and mechanical response of the SiO2f/SiO2 composite and Invar alloy joints brazed with an AgCuTi alloy[J]. Materials & Design, 2016, 111: 239 ? 247.
    [7] Guedes A, Pires Pinto A M. Active metal brazing of machinable aluminum nitride-based ceramic to stainless steel[J]. Journal of Materials Engineering and Performance, 2012, 21(5): 671 ? 677.
    [8] 张玲艳, 秦明礼, 曲选辉, 等. AIN/Mo-Ni-Cu的活性封接研究[J]. 稀有金属材料与工程, 2009, 38(12): 2159 ? 2162
    Zhang Lingyan, Qin Mingli, Qu Xuanhui, et al. Study on active brazing of AlN ceramics and Mo-Ni-Cu alloy[J]. Rare Metal Materials and Engineering, 2009, 38(12): 2159 ? 2162
    [9] 刘 鑫, 张小勇, 陆艳杰, 等. AlN陶瓷与无氧铜的活性封接[J]. 真空电子技术, 2007(4): 56 ? 58
    Liu Xin , Zhang Xiaoyong , Lu Yanjie, et al. Active brazing of AlN and oxygen-free copper[J]. Vacuum Electronics, 2007(4): 56 ? 58
    [10] Chou T T, Tuan W H, Nishikawa H, et al. Brazing graphite to aluminum nitride for thermal dissipation purpose[J]. Advanced Engineering Materials, 2017, 19(7): 1600876.
    [11] Palit D, Meier A M. Reaction kinetics and mechanical properties in the reactive brazing of copper to aluminum nitride[J]. Journal of Materials Science, 2006, 41(21): 7197 ? 7209.
    [12] 张玲艳, 秦明礼, 曲选辉, 等. AlN陶瓷与可伐合金的活性封接[J]. 真空电子技术, 2009(4): 4 ? 7
    Zhang Lingyan, Qin Mingli, Qu Xuanhui,et al. Active brazing of AlN ceramic with Kovar alloy[J]. Vacuum Electronics, 2009(4): 4 ? 7
    [13] Kara-Slimane A, Juve D, Leblond E, et al. Joining of AlN with metals and alloys[J]. Journal of the European Ceramic Society, 2000, 20(11): 1829 ? 1836.
    [14] 朱成俊, 尚长沛. 采用AgCuTi活性钎料真空钎焊MgAl2O4透明陶瓷[J]. 焊接学报, 2015, 36(4): 101 ? 105
    Zhu Chengjun, Shang Changpei. Vacuum brazing of MgAl2O4 transparent ceramics with AgCuTi active filler metal[J]. Transactions of the China Welding Institution, 2015, 36(4): 101 ? 105
