纳米铝颗粒增强Sn1.0Ag0.5Cu钎料性能及机理

孙磊1,陈明和1,谢兰生1,张亮2,朱建东3

孙磊1,陈明和1,谢兰生1,张亮2,朱建东3. 纳米铝颗粒增强Sn1.0Ag0.5Cu钎料性能及机理[J]. 焊接学报, 2018, 39(8): 47-50. DOI: 10.12073/j.hjxb.2018390199
引用本文: 孙磊1,陈明和1,谢兰生1,张亮2,朱建东3. 纳米铝颗粒增强Sn1.0Ag0.5Cu钎料性能及机理[J]. 焊接学报, 2018, 39(8): 47-50. DOI: 10.12073/j.hjxb.2018390199
shu
SUN Lei1, CHEN Minghe1, XIE Lansheng1, ZHANG Liang2, ZHU Jiandong3. Properties and mechanism of nano Al particles reinforced Sn1.0Ag0.5Cu solders[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2018, 39(8): 47-50. DOI: 10.12073/j.hjxb.2018390199
Citation: SUN Lei1, CHEN Minghe1, XIE Lansheng1, ZHANG Liang2, ZHU Jiandong3. Properties and mechanism of nano Al particles reinforced Sn1.0Ag0.5Cu solders[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2018, 39(8): 47-50. DOI: 10.12073/j.hjxb.2018390199
shu

纳米铝颗粒增强Sn1.0Ag0.5Cu钎料性能及机理

  • 1. 南京航空航天大学 机电学院, 南京 210016;
    2. 江苏师范大学 机电工程学院, 徐州 221116;
    3. 哈尔滨工业大学 先进焊接与连接国家重点实验室, 哈尔滨 150001

基金项目: 国家自然科学基金资助项目（51475220）；江苏省“六大人才高峰”高层次人才资助项目（XCL022）；江苏省“青蓝工程”中青年学术带头人计划；新型钎焊材料与技术国家重点实验室开放课题资助项目（郑州机械研究所SKLABFMT201503）；南京航空航天大学博士学位论文创新与创优基金（BCXJ18-06）；江苏省研究生科研与实践创新计划资助项目（KYCX18_0318）

Properties and mechanism of nano Al particles reinforced Sn1.0Ag0.5Cu solders

  • 1. College of Mechanical & Electrical Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China;
    2. School of Mechanical and Electrical Engineering, Jiangsu Normal University, Xuzhou 221116, China;
    3. State Key Laboratory of Advanced Welding and Joining, Harbin Institute of Technology, Harbin 150001, China

摘要

    摘要
  • 摘要: 通过机械混合的方法，制备Sn1.0Ag0.5Cu-xAl复合钎料.采用DSC、STR-1000型微焊点强度测试仪及SEM，研究了纳米铝颗粒对低银Sn1.0Ag0.5Cu钎料组织与性能的影响.结果表明，微量纳米铝颗粒的添加对钎料的熔化温度影响较小，其熔点均在226.9~229.0℃之间.随着纳米Al元素含量的增加，钎料的润湿角逐渐减小，力学性能逐渐增加，当纳米Al元素的添加量为0.1%时，焊点的拉伸力达到最大，为7.1 N.此外，Sn1.0Ag0.5Cu-0.1Al钎料的内部组织得到显著细化，焊点界面金属间化合物的生长也得到明显抑制，主要归因于纳米颗粒对金属间化合物生长的吸附作用.
    Abstract: Sn1.0Ag0.5Cu-xAl composite solders were prepared by mechanically mixing method. The effect of nano Al particles on the microstructure and properties of Sn1.0Ag0.5Cu solder were investigated by differnetial scanning calorimetry, STR-1000 micro-joint strength tester and SEM. The results showed that adding nano Al particles does not cause a considerable change in the melting temperature. All samples ranged from 226.9 to 229℃. With the addition of nano Al particles, the wetting angle was decreased and mechanical property was increased. When the addition of nano Al particles was 0.1%, the pull force of solder joint reached the maximum, which was 7.1 N. In addition, the microstructure of Sn1.0Ag0.5Cu-0.1Al solder was significantly refined, and the thickness of interfacial intermetallic compounds (IMC) was effectively inhibited, which may attributed to the adsorption of nanoparticles.
    • HTML全文
    • 参考文献(14)
  • [1] Sun L, Zhang L, Zhong S J, et al. Reliability study of industry Sn3.0Ag0.5Cu/Cu lead-free soldered joints in electronic packaging[J]. Journal of Materials Science:Materials in Electronics, 2015, 26(11):9164-9170.
    [2] Zhang L, Xue S B, Zeng G, et al. Interface reaction between SnAgCu/SnAgCuCe solders and Cu substrate subjected to thermal cycling and isothermal aging[J]. Journal of Alloys and Compounds, 2012, 510(1):38-45.
    [3] 孙磊, 张亮, 钟素娟, 等. Sn1.0Ag0.5Cu和Sn3.0Ag0.5Cu钎料组织与性能对比研究[J]. 稀有金属, 2015, 39(7):589-593 Sun Lei, Zhang Liang, Zhong Sujuan, et al. Microstructure and Properties of Sn1.0Ag0.5Cu and Sn3.0Ag0.5Cu Lead-Free Solder[J]. Chinese Journal of Rare Metals, 2015, 39(7):589-593
    [4] Hamada N, Uesugi T, Takigawa Y, et al. Effect of addition of small amount of Zinc on microstructural evolution and thermal shock behavior in low-Ag Sn-Ag-Cu solder joints[J]. Materials Transactions, 2013, 54(5):796-805.
    [5] Spinelli E J, Garcia A. Development of solidification microstructure and tensile mechanical properties of Sn-0.7Cu and Sn-0.7Cu-2.0Ag solders[J]. Journal of Materials Science:Materials in Electronics, 2014, 25(1):478-486.
    [6] Bui Q V, Jung S B. Evaluation of mechanical properties of low-Ag ball grid array solder joints using a high-speed ball shear test[J]. Journal of Alloys and Compounds, 2014, 589:590-595.
    [7] Cheng F J, Gao F, Zhang J Y, et al. Tensile properties and wettability of SAC307 and SAC105 low Ag lead-free solder alloys[J]. Journal of Materials Science, 2011, 46(10):3424-3429.
    [8] Shnawah D A A, Said S B M, Sabri M F M, et al. Microstructure, mechanical, and thermal properties of the Sn-1Ag-0.5Cu solder alloy bearing Fe for electronics applications[J]. Materials Science and Engineering A, 2012, 551:160-168.
    [9] Hodulova E, Palcut M, Lechovic E, et al. Kinetics of intermetallic phase formation at the interface of Sn-Ag-Cu-X (X=Bi, In) solders with Cu substrate[J]. Journal of Alloys and Compounds, 2011, 509(25):7052-7059.
    [10] Lin K S, Huang H Y, Chou C P. Interfacial reaction between Sn-1Ag-0.5Cu (-Co) solder and Cu substrate with Au/Ni surface finish during reflow reaction[J]. Journal of Alloys and Compounds, 2009, 471(1-2):291-295.
    [11] Yang L, Ge J G, Zhang Y C, et al. Effect of BaTiO3 on the microstructure and mechanical properties of Sn1.0Ag0.5Cu lead-free[J]. Journal of Materials Science:Materials in Electronics, 2015, 26(1):613-619.
    [12] 张亮, 韩继光, 郭永环, 等. 含纳米铝颗粒SnAgCu钎料组织与性能[J]. 焊接学报, 2013, 34(6):65-68 Zhang Liang, Han Jiguang, Guo Yonghuan, et al. Microstructure and properties of SnAgCu solders bearing Al nano-particles[J]. Transactions of the China Welding Institution, 2013, 34(6):65-68
    [13] Gain A K, Fouzder T, Chan Y C, et al. The influence of addition of Al nano-particles on the microstructure and shear strength of eutectic Sn-Ag-Cu solder on Au/Ni metallized Cu pads[J]. Journal of Alloys and Compounds, 2010, 506(1):216-223.
    [14] Li Y, Zhao X C, Liu Y, et al. Effect of TiO2 addition concentration on the wettability and intermetallic compounds growth of Sn3.0Ag0.5Cu-xTiO2 nano-composite solders[J]. Journal of Materials Science:Materials in Electronics, 2014, 25(9):3816-3827.
