刚性对接裂纹试件和VRC试件拘束度有限元模拟

荆洪阳1,2,徐景景1,2,徐连勇1,2,韩永典1,2,赵雷1,2

荆洪阳1,2,徐景景1,2,徐连勇1,2,韩永典1,2,赵雷1,2. 刚性对接裂纹试件和VRC试件拘束度有限元模拟[J]. 焊接学报, 2018, 39(8): 1-5. DOI: 10.12073/j.hjxb.2018390190
引用本文: 荆洪阳1,2,徐景景1,2,徐连勇1,2,韩永典1,2,赵雷1,2. 刚性对接裂纹试件和VRC试件拘束度有限元模拟[J]. 焊接学报, 2018, 39(8): 1-5. DOI: 10.12073/j.hjxb.2018390190
shu
JING Hongyang1,2, XU Jingjing1,2, XU Lianyong1,2, HAN Yongdian1,2, ZHAO Lei1,2. Finite element simulation of the restraint intensity of rigid butt-jointed cracking specimen and VRC specimen[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2018, 39(8): 1-5. DOI: 10.12073/j.hjxb.2018390190
Citation: JING Hongyang1,2, XU Jingjing1,2, XU Lianyong1,2, HAN Yongdian1,2, ZHAO Lei1,2. Finite element simulation of the restraint intensity of rigid butt-jointed cracking specimen and VRC specimen[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2018, 39(8): 1-5. DOI: 10.12073/j.hjxb.2018390190
shu

刚性对接裂纹试件和VRC试件拘束度有限元模拟

  • 1. 天津大学 材料科学与工程学院, 天津 300350;
    2. 天津市现代连接技术重点试验室, 天津 300350

基金项目: 国家自然科学基金资助项目（51575382）

Finite element simulation of the restraint intensity of rigid butt-jointed cracking specimen and VRC specimen

  • 1. School of Materials Science and Technology, Tianjin University, Tianjin 300350, China;
    2. Tianjin Key Laboratory of Advanced Joining Technology, Tianjin 300350, China

摘要

    摘要
  • 摘要: 采用有限元方法研究了试件尺寸对刚性对接裂纹试件和可变拘束裂纹试件拘束度的影响规律.结果表明，两种试件的拘束度均随着厚度的增加而增大，随着厚度由20 mm增加至50 mm，刚性对接裂纹试件中心拘束度由14.87 kN/（mm·mm）增加至20.72 kN/（mm·mm），可变拘束裂纹试件中心拘束度由10.46 kN/（mm·mm）增加至16.23 kN/（mm·mm）；对于40 mm厚的刚性对接裂纹试件，其拘束试件宽度由125 mm增加至275 mm时，试件的拘束度下降，但拘束试件宽度继续增加，试件的拘束度不再发生显著变化；对于40 mm厚可变拘束裂纹试件，随着拘束试件宽度由125 mm增加至575 mm，其拘束度呈连续下降趋势.
    Abstract: In this paper, finite element method was used to study the influence of specimen size on the restraint intensity of rigid butt-jointed cracking test specimen and variable restraint cracking test specimen. The results show that the restraint intensity increases with the increase of the specimen thickness. With the increase of the thickness from 20 mm to 50 mm, the restraint intensity increases from 14.87 kN/(mm·mm) to 20.72 kN/(mm·mm) for rigid butt-jointed cracking test specimen, and the restraint intensity increases from 10.46 kN/(mm·mm) to 16.23 kN/(mm·mm) for variable restraint cracking test specimen. For the 40 mm thick rigid butt-jointed cracking test specimen, when the width of the restrained specimen increases from 125 mm to 275 mm, the restraint intensity of the specimen decreases. However, with the width of the specimen increases further, the restraint intensity of the specimen does not change significantly. For the 40 mm variable restraint cracking test specimen, with the restraint specimen width from 125 mm to 575 mm, the restraint intensity shows a continuous downward trend.
    • HTML全文
    • 参考文献(15)
  • [1] Sekiguchi H. Fundamental research on the welding heat-affected zone of steel[M]. Tokyo:Nikkan Kogyo Shinbun, 1976.
    [2] 张文铖. 金属熔焊原理及工艺上[M]. 北京:机械工业出版社, 1980.
    [3] 侯文考, 陈邦固, 张文钺. 缝隙型焊接试件拘束应力的分析[J]. 焊接学报, 1994, 15(1):59-66 Hou Wenkao, Chen Banggu, Zhang Wenyue. Analyse on restraint stress of welded joint in slit-type cracking specimen[J]. Transactions of the China Welding Institution, 1994, 15(1):59-66
    [4] Kannengiesser T, Boellinghaus T. Cold cracking tests-an overview of present technologies and applications[J]. Welding in the World, 2013, 57(1):3-37.
    [5] Schwenk C, Kannengiesser T, Rethmeier M. Restraint conditions and welding residual stresses in self-restrained cold cracking tests[C]//8th Interntional Conference on Trends in Welding Research, 2009:766-773.
    [6] Wongpanya P, Boellinghaus T. Residual stress distribution in competing S 1100 QL butt-welds dependent on plate thickness and restraint length[C]//Proceeding of Conference on High Strength Steels for Hydropower Plants, 2009:20-22.
    [7] Kannengiesser I T, Lausch I T, Kromm I A. Effects of heat control on the stress build-up during high-strength steel welding under defined restraint conditions[J]. Welding in the World, 2011, 55(7-8):58-65.
    [8] Rhode M, Kromm A, Kannengießer T. Residual stresses in multi-layer component welds[C]//Trends in Welding Research 2012:Proceedings of the 9th International Conference. ASM International, 2013:48-54.
    [9] Schroepfer D, Kromm A, Kannengiesser T. Improving welding stresses by filler metal and heat control selection in component-related butt joints of high-strength steel[J]. Welding in the World, 2015, 59(3):455-464.
    [10] 崔文媛, 易传宝. 用拘束度与拘束应力对对接接头裂纹试验的评定[J]. 焊接学报, 1985, 6(3):24-30 Cui Wenyuan, Yi Chuanbao. An evaluation for butt joint cracking tests in terms of restraint severity and restraint stress[J]. Transactions of the China Welding Institution, 1985, 6(3):24-30
    [11] 王路强.对接接头拘束度和拘束应力的研究[D]. 天津:天津大学, 1988.
    [12] 吴松林, 龙兴平, 张成杰. 刚性固定对接裂纹试验的拘束度有限元计算分析[J]. 材料开发与应用, 2011, 26(2):1-3 Wu Songlin, Long Xingping, Zhang Chengjie. Finite element analysis for the restraint of restrained-butt joint cracking test[J]. Development and Application of Materials, 2011, 26(2):1-3
    [13] Böllinghaus T, Kannengießer T, Neuhaus M. Effects of the structural restraint intensity on the stress strain build up in butt joints[C]//Mathematical Modelling of Welding Phenomena, Vol. 7, Graz:Graz Technology University, 2005:651-669.
    [14] Satoh K. An analytical approach to the problem of restraint intensity in slit weld[J]. Transactions of JWRI, 1972, 1(1):69-76.
    [15] 陈楚, 汪建华, 唐逸民, 等. 船体焊接接头的拘束度及其对冷裂缝的影响[J]. 造船技术, 1981(3):7-14 Chen Chu, Wang Jianhua, Tang Yimin, et al. Restraint intensity of hull welding joint and its effect on cold crack[J]. Marine Technology, 1981(3):7-14
