水下局部干法焊接预热技术及专用排水罩的研制

沈相星1,程方杰1,2,邸新杰1,王东坡1,2,曹军3

沈相星1,程方杰1,2,邸新杰1,王东坡1,2,曹军3. 水下局部干法焊接预热技术及专用排水罩的研制[J]. 焊接学报, 2018, 39(3): 112-116. DOI: 10.12073/j.hjxb.2018390080
引用本文: 沈相星1,程方杰1,2,邸新杰1,王东坡1,2,曹军3. 水下局部干法焊接预热技术及专用排水罩的研制[J]. 焊接学报, 2018, 39(3): 112-116. DOI: 10.12073/j.hjxb.2018390080
shu
SHEN Xiangxing1, CHENG Fangjie1,2, DI Xinjie1, WANG Dongpo1,2, CAO jun3. Local-dry underwater welding preheating technology and development of special drain cover[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2018, 39(3): 112-116. DOI: 10.12073/j.hjxb.2018390080
Citation: SHEN Xiangxing1, CHENG Fangjie1,2, DI Xinjie1, WANG Dongpo1,2, CAO jun3. Local-dry underwater welding preheating technology and development of special drain cover[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2018, 39(3): 112-116. DOI: 10.12073/j.hjxb.2018390080
shu

水下局部干法焊接预热技术及专用排水罩的研制

Local-dry underwater welding preheating technology and development of special drain cover

摘要

    摘要
  • 摘要: 研制开发了一种带有预热功能的水下局部干法焊接专用排水罩. 该排水罩具有水下预热功能，适用于水下局部干法药芯焊丝半自动焊工艺，预热温度可达60～80℃. 排水罩内设计有一块覆盖于坡口周围的预热钢板，正式焊接前首先在该板上进行预热焊接，通过热传导来实现对焊接坡口的预热作用. 使用该排水罩在水池中进行了模拟焊接试验. 结果表明，焊接接头质量达到AWS D3.6M:2010规定的A级焊缝的各项性能要求. 与其它水下焊接方法的试验结果对比发现，采用所研制的带预热功能的固定式排水罩进行水下局部干法焊接时接头的最大硬度显著降低，韧性也有明显提高.
    Abstract: A kind of special fixed drain cover used for local-dry underwater welding has been developed. The drain cover can be used for semi-automatic local-dry underwater welding process with flux-cored wire and had the function of underwater preheating before welding, by which preheating temperature can range from 60 to 80 ℃. Preheating welding was performed before groove welding by heat conduction from preheating plate covered on the groove in the drainage cover. The welding experiment results carried out in a pool using the drain cover indicated that the welding joint quality reached class A according to AWS D3.6M standard. The maximum hardness of welding joint decreased significantly, while toughness improved dramatically by using fixed drainage cover with preheating function compared with other underwater welding methods.
    • HTML全文
    • 参考文献(1)
  • [1] Nixon J H. Development of underwater welding[J]. Welding and Metal Fabrication, 1991, 59(4): 174-177.[2] Tang Deyu, Niu Huli, Xue Long. Study on underwater hyperbaric dry GMAW welding[J]. Electric Welding Machine, 2012, 42(12): 1-6.[3] Labanowski J. Development of under-water welding techniques[J]. Welding International, 2011, 25(12): 933-937.[4] Maksimov S Yu, Lyakhovaya I V. Wet underwater welding of low-alloy steels of increased strength[J]. Paton Welding Journal, 2013(8): 42-45.[5] 宋宝天， 宋 炀. 我国水下焊接与切割技术发展概况[C]∥中国航海学会救助打捞专业委员会. 救捞专业委员会2002年学术交流会论文集. 深圳： 中国航海学会， 2002： 91-93.[6] Masubuchi K. Review of underwater welding technology[J]. Oceans, 1981, 81: 649-651.[7] 林尚扬， 宋宝天， 宋天虎. 水下局部排水CO2半自动焊接技术的研究和应用[J]. 焊接学报， 1981， 2(1)： 9-20.Lin Shangyang, Song Baotian, Song Tianhu. A study and application of local dry CO2gas shielded semi-automatic underwater welding[J]. Transactions of the China Welding Institution. 1981, 2(1): 9-20.[8] 宋宝天. NBS-500型水下局部排水半自动焊机[J]. 电工技术， 1986(2)： 47-48.Song Baotian. NBS-500 semi-automatic welding machine for underwater local drainage[J]. Electric Engineering, 1986(2): 47-48.[9] 宋宝天， 王连东， 宋 炀. 渤海六号钻井平台水下焊接修复[J]. 焊接， 1996(3)： 9-12.Song Baotian, Wang Liandong, Song Yang. Underwater repair welding for Bohai sea drilling platform[J]. Welding & Joining, 1996(3): 9-12.[10] 佚 名. 水下局部排水CO2半自动焊接的研究[J]. 焊接， 1979(4)： 17-23.Anonymous. Study on semi-automatic CO2welding of underwater local drainage[J]. Welding & Joining, 1979(4): 17-23.[11] 朱加雷， 焦向东， 王 飞， 等. 气室式局部干法水下焊接试验系统[J]. 上海交通大学学报， 2012， 46(S9)： 69-71.Zhu Jialei, Jiao Xiangdong, Wang Fei,et al. Research on chamber test system for local dry underwater welding[J]. Journal of Shanghai Jiaotong University, 2012, 46(S9): 69-71.[12] 朱加雷， 焦向东， 金 枫. 局部干法自动水下焊接系统的研究[J]. 电焊机， 2009， 39(8)： 10-13.Zhu Jialei, Jiao Xiangdong, JinFeng. Research on local dry automatic underwater welding system[J]. Electric Welding Machine, 2009, 39(8): 10-13.[13] 朱加雷， 王殿舒， 焦向东， 等. 气室式局部干法水下焊接[J]. 上海交通大学学报， 2015， 49(3)： 329-332.Zhu Jialei, Wang Dianshu, Jiao Xiangdong,et al. A chamber local dry underwater welding[J]. Journal of Shanghai Jiaotong University, 2015, 49(3): 329-332.[14] 朱加雷， 焦向东， 沈秋平，等. 核电厂检修局部干法自动水下焊接实验[J]. 上海交通大学学报， 2008, 42(S11)： 126-128.Zhu Jialei, Jiao Xiangdong, Shen qiuping,et al. Study on local dry auto underwater welding in nuclear power plant repair[J]. Journal of Shanghai Jiaotong University， 2008, 42(S11): 126-128.[15] 张 彤， 钟继光， 王国荣. 药芯焊丝微型排水罩局部干法水下焊接的研究[C]∥中国机械工程学会焊接学会. 第九次全国焊接会议论文集. 哈尔滨： 中国机械工程焊接学会， 1990： 358-361.[16] 古志明， 李尚周， 梅福欣. 同轴式水下局部干法TIG电弧焊接[J]. 华南理工大学学报， 1988， 16(3)： 1-8.Gu Zhiming， Li Shangzhou， Mei Fuxin. A study of local dry TIG underwater welding with coaxial vision way[J]. Journal of South China University of Technology, 1988, 16(3): 1-8.[17] American welding society. AWS D3.6M: 2010 Underwater weld code[S]. America: American National Standard Institute, 2010.[18] 黄江中， 高文斌， 赵翠华， 等. DH36水下湿法焊接接头组织和力学性能分析[J]. 电焊机， 2014， 44(6)： 107-112.Huang Jiangzhong， Gao Wenbin， Zhao Cuihua,et al. Analysis on microstructure and mechanical properties of DH36 underwater wet welding joints[J]. Electric Welding Machine, 2014, 44(6): 107-112.[19] 殷亚运， 杨新岐， 崔 雷， 等. DH36高强度钢摩擦柱塞焊工艺与接头组织性能[J]. 焊接学报， 2014， 35(9)： 109-112.Yin Yayun, Yang Xinqi, Cui Lei,et al. Friction hydro pillar processing and joint structure property of DH36 high strength steel[J]. Transactions of the China Welding Institution, 2014, 35(9): 109-112.
