Fe-Cr-C-B-Nb堆焊合金的显微组织和耐磨性
Microstructure and wear resistance of Fe-Cr-C-B-Nb hardfacing alloy
-
摘要: 采用明弧自保护法制备Fe-Cr-C-B-Nb系耐磨堆焊合金，借助光学显微镜(OM)、扫描电镜(SEM)和X射线衍射(XRD)等手段，分析堆焊层中的物相组成，探究熔池中硬质相析出顺序，研究B和Nb元素含量对其显微组织和耐磨性影响. 结果表明，制备的堆焊合金显微组织为马氏体+残余奥氏体+ M23(C,B)6+NbC,NbC先于M23(C,B)6生成. 当堆焊层中B元素含量为0.21%，Nb元素含量为1.44%时，可以使堆焊合金有较高的硬度和耐磨性. 洛氏硬度可达69 HRC±1.5 HRC，磨损量为0.037 6 g. 过量的B元素不利于NbC析出，而使Nb元素固溶强化硼化物和基体. 耐磨性试验结果表明，M23(C,B)6和NbC两种硬质相显著改善了Fe-Cr-C-B-Nb系堆焊合金的耐磨性.
-
关键词:
- 药芯焊丝 /
- 明弧堆焊 /
- Fe-Cr-C-B-Nb /
- 耐磨性 /
- 显微组织
Abstract: Fe-Cr-C-B-Nb wear resistant flux cored wire was deposited by self-shield open arc welding. The phase composition and precipitation sequence of hard phases in the surfacing layer were analyzed. And the effect of B and Nb content on microstructure and wear resistance were also studied by optical microscopy (OM), scanning electron microscopy (SEM) and X-ray diffractometer (XRD). The experimental results showed that the microstructure consisted of the martensite, retained austenite, M23(C,B)6and NbC phase. NbC phase was precipitated preferentially than M23(C,B)6phase. When the content of B and Nb element reached 0.21% and 1.44% in the surfacing layer respectively, the hardfacing alloy indicated a high hardness and wear resistance. Therefore, the macro-hardness could reach 69 HRC±1.5 HRC and the wear loss was 0.037 6 g for the Fe-Cr-C-B-Nb hardfacing alloy. The excess B was not conducive to the precipitation of NbC phase, resulting in the solid solution strengthening of boride and matrix by Nb element. The results of abrasion test indicated that the exist of M23(C,B)6and NbC significantly improved the abrasion resistance of Fe-Cr-C-B-Nb hardfacing alloys. -
-
[1] 马 立, 胡绳荪, 申俊琦. 退火工艺对26% Cr超级铁素体不锈钢组织性能的影响[J]. 材料热处理学报, 2015, 36(11): 132-137.Ma Li, Hu Shengsun, Shen Junqi. Effect of hot property treatment process on microstructure and of 26%Cr super ferritic stainless steel[J]. Transaction of Materials and Heat Treatment, 2015, 36(11): 132-137.[2] 龚建勋, 肖逸锋, 张清辉, 等. Fe-C-Cr-V高铬堆焊合金的M7C3型碳化物及耐磨性[J]. 焊接学报, 2010, 31(1): 33-36.Gong Jianxun, Xiao Yifeng, Zhang Qinghui,et al. M7C3-type carbide and abrasion resistance of Fe-C-Cr-V high chromium hardfacing alloys[J]. Transactions of the China Welding Institution, 2010, 31(1): 33-36.[3] 宗 琳, 刘政军, 李乐成. 多元陶瓷复合相显微组织对耐磨性能的影响[J]. 焊接学报, 2012, 33(2): 61-64.Zong Lin,Liu Zhengjun, Li Lecheng. Effect of microstructure on wear resistance for multiple ceramic phases[J]. Transactions of the China Welding Institution, 2012, 33(2): 61-64.[4] Eroglu M. Boride coatings on steel using shielded metal arc welding electrode: microstructure and hardness[J]. Surface and Coatings Technology, 2009, 203(16): 2229-2235.[5] 刘大双, 刘仁培, 邱 悦, 等. 无渣含铌自保护堆焊药芯焊丝的研制[J]. 焊接学报, 2012, 33(9): 73-76.Liu Dashuang, Liu Renpei, Qiu Yue,et al. Development of slag-free self-shielded flux cored wire with niobium addition for hardfacing[J]. Transactions of the China Welding Institution, 2012, 33(9): 73-76.[6] 曹雅彬. 高Nb微合金钢中Nb的溶解/析出及其对组织演变影响的研究[D]. 秦皇岛: 燕山大学, 2012. -
