基于FLUENT软件的GMAW焊熔池动态行为数值分析模型

张世亮1,胥国祥2,曹庆南2,潘海潮2,李鹏飞2

张世亮1,胥国祥2,曹庆南2,潘海潮2,李鹏飞2. 基于FLUENT软件的GMAW焊熔池动态行为数值分析模型[J]. 焊接学报, 2018, 39(2). DOI: 10.12073/j.hjxb.2018390045
引用本文: 张世亮1,胥国祥2,曹庆南2,潘海潮2,李鹏飞2. 基于FLUENT软件的GMAW焊熔池动态行为数值分析模型[J]. 焊接学报, 2018, 39(2). DOI: 10.12073/j.hjxb.2018390045

基于FLUENT软件的GMAW焊熔池动态行为数值分析模型

  • 摘要: 基于FLUENT软件,建立了适用的熔化极气体保护焊(gas metal arc welding, GMAW)熔池动态行为数值分析模型,该模型考虑了气—液—固三相耦合. 将电弧热输入视为双椭球体热源模型,将电弧等离子体描述为高速流向熔池的氩气,其流速呈高斯分布,流速峰值依据焊接电流确定,电弧压力与电弧等离子体对熔池表面的切应力在计算过程中获得;将熔滴过渡视为高温液态金属从熔池上部一定区域以一定速度流入熔池过程,通过对流速施加时间脉冲函数表征熔滴过渡频率. 利用该模型对不同条件下GMAW焊熔池热场及流场进行模拟计算,并分析其流体动力学特征. 结果表明,模型能够合理地反映熔池动力学特征,同时还提高了计算效率.
  • [1] 武传松. 焊接热过程与熔池形态[M]. 北京:机械工业出版社,2008.[2] 孙俊生,武传松. 电弧热流分布模式对GMAW焊接温度场的影响[J]. 焊接学报,1998,19(4): 255-260.Sun Junsheng, Wu Chuansong. Modeling the weld pool behaviors in GMA welding[J]. Transactions of the China Welding Institution, 1998, 19(4): 255-260.[3] 陈 姬,武传松, Pitter A, 等. ForceArc 双面焊熔池流场与温度场的数值模拟[J]. 焊接学报,2015, 36(7): 9-12.Chen Ji, Wu Chuansong, Pitter A, et al. Numerical simulation of fluid flow and temperature fields for double-sided ForceArc welding[J]. Transactions of the China Welding Institution, 2015, 36(7): 9-12.[4] Kumar A, Tebroy T. Toward a unified model to prevent humping defects in gas tungsten arc welding[J]. Welding Journal, 2006(12): 292-304.[5] Cho J H, Na S J. Three-dimensional analysis of molten pool in GMA-laser hybrid welding[J]. Welding Journal, 2009, 88(4): 35-43.[6] Hu J, Tsai H L. Heat and mass transfer in gas metal arc welding. Part I: The arc[J]. International Journal of Heat and Mass Transfer, 2007, 50(5): 833-846.[7] Hu J, Tsai H L. Heat and mass transfer in gas metal arc welding. Part Ⅱ: The metal[J]. International Journal of Heat and Mass Transfer, 2007, 50(6): 808-820.[8] 胥国祥, 张卫卫, 马学周, 等. 激光+GMAW复合热源焊流体流动数值分析模型[J]. 焊接学报,2015, 36(7): 51-54.Xu Guoxiang, Zhang Weiwei, Ma Xuezhou, et al. Numerical analysis model for fluid flow in laser+GMAW hybrid welding[J]. Transactions of the China Welding Institution, 2015, 36(7): 51-54.[9] Kim C H, Zhang W, Debroy T. Modeling of temperature field and solidified surface profile during gas metal arc fillet welding[J]. Journal of Applied Physics, 2003, 94(4): 2667-2679.
