不扎透上板对2024-T4铝合金搅拌摩擦搭接焊力学性能的影响

叶结和1,刘雪松2,王素环1

叶结和1,刘雪松2,王素环1. 不扎透上板对2024-T4铝合金搅拌摩擦搭接焊力学性能的影响[J]. 焊接学报, 2018, 39(2). DOI: 10.12073/j.hjxb.2018390044
引用本文: 叶结和1,刘雪松2,王素环1. 不扎透上板对2024-T4铝合金搅拌摩擦搭接焊力学性能的影响[J]. 焊接学报, 2018, 39(2). DOI: 10.12073/j.hjxb.2018390044

不扎透上板对2024-T4铝合金搅拌摩擦搭接焊力学性能的影响

  • 摘要: 钩状缺陷是影响搅拌摩擦搭接焊接头性能的重要因素. 为了尽可能的避免钩状缺陷的产生,利用不扎透上板的方式对2024-T4铝合金进行焊接,重点分析不同转速下的接头横截面形貌及力学性能. 结果表明,利用不扎透上板的方式所得搭接界面保持连续且主要呈水平方向分布. 由于搅拌针长度较小,焊核区底部的宽度远大于搅拌针尖端直径,使有效连接宽度增加,导致搭接接头在承受拉剪载荷时呈拉伸断裂模式. 与转速为500 r/min相比,600 r/min下接头的有效连接宽度与剪切拉伸强度均有小幅度地增加,最大剪切拉伸强度为143 MPa.
  • [1] 潘 锐, 王善林, 李建萍, 等. 工艺参数对搅拌摩擦焊变形铝合金接头性能的影响[J]. 焊接学报, 2016, 37(11): 89-92.Pan Rui, Wang Shanlin, Li Jianping, et al. Effect of processing parameters on mechanical properties of aluminum alloy joints welded by friction stir welding[J]. Transactions of the China Welding Institution, 2016, 37(11): 89-92.[2] Zhou Z L, Yue Y M, Ji S D, et al. Effect of rotating speed on joint morphology and lap shear properties of stationary shoulder friction stir lap welded 6061-T6 aluminum alloy[J]. International Journal of Advanced Manufacturing Technology, 2017, 88(5-8): 2135-2141.[3] Liu H J, Zhao Y Q, Hu Y Y, et al. Microstructural characteristics and mechanical properties of friction stir lap welding joint of Alclad 7B04-T74 aluminum alloy[J]. International Journal of Advanced Manufacturing Technology, 2015(78): 1415-1425.[4] Fadaeifard F, Matori K A, Toozandehjani M, et al. Influence of rotational speed on mechanical properties of friction stir lap welded 6061-T6 Al alloy[J]. Transactions of Nonferrous Metals Society of China, 2014, 24(4): 1004-1011.[5] Yazdanian S, Chen Z W. Effects of friction stir lap welding parameters on weld features on advancing side and fracture strength of AA6060-T5 welds[J]. Journal of Materials Science, 2012, 47(3): 1239-1241.[6] 岳玉梅, 周振鲁, 姬书得, 等. 半螺纹搅拌针对2024铝合金搅拌摩擦搭接焊力学性能影响[J]. 焊接学报, 2016, 37(10): 69-72.Yue Yumei, Zhou Zhenlu, Ji Shude, et al. Effect of half-threaded pin on mechanical properties of friction stir lap welded alclad 2024 aluminum alloy[J]. Transactions of the China Welding Institution, 2016, 37(10): 69-72.[7] Babu S, Ram G D J, Venkitakrishnan P V, et al. Microstructure and mechanical properties of friction stir lap welded aluminum alloy AA2014[J]. Journal of Materials Science and Technology, 2012, 28(5): 414-426.[8] Salari E, Jahazi M, Khodabandeh A, et al. Influence of tool geometry and rotational speed on mechanical properties and defect formation in friction stir lap welded 5456 aluminum alloy sheets[J]. Materials & Design, 2014, 58(6): 381-389.[9] Zhang G F, Su W, Zhang J, et al. Effects of shoulder on interfacial bonding during friction stir lap welding of aluminum thin sheets using tool without pin[J]. Transactions of Nonferrous Metals Society of China, 2010, 20(12): 2223-2228.[10] 蒋若蓉, 李文亚, 杨夏炜, 等. 薄板 AA2024铝合金无针搅拌摩擦焊搭接工艺与接头性能[J]. 焊接学报, 2016, 37(4): 98-102.Jiang Ruorong, Li Wenya, Yang Xiawei, et al. Pinless friction stir lap welding of AA2024 alloy sheet: joint formability and property[J]. Transactions of the China Welding Institution, 2016, 37(4): 98-102.[11] 王 月, 姬书得, 李继忠, 等. 2.5 mm厚TC4钛合金搅拌摩擦焊的成形规律研究[J]. 热加工工艺, 2016, 45(15): 171-176.Wang Yue, Ji Shude, Li Jizhong, et al. Research on forming law of 2.5 mm thick TC4 titanium alloy friction stir welded joints[J]. Hot Working Technology, 2016, 45(15): 171-176.[12] Li Z W, Yue Y M, Ji S D, et al. Joint features and mechanical properties of friction stir lap welded alclad 2024 aluminum alloy assisted by external stationary shoulder[J]. Materials & Design, 2016(90): 238-247.
