异厚度铝钢电弧辅助激光对接熔钎焊温度场和应力应变场数值模拟

刘剑1,樊丁1,陈秀娟2,黄健康1,余淑荣2

刘剑1,樊丁1,陈秀娟2,黄健康1,余淑荣2. 异厚度铝钢电弧辅助激光对接熔钎焊温度场和应力应变场数值模拟[J]. 焊接学报, 2018, 39(2). DOI: 10.12073/j.hjxb.2018390036
引用本文: 刘剑1,樊丁1,陈秀娟2,黄健康1,余淑荣2. 异厚度铝钢电弧辅助激光对接熔钎焊温度场和应力应变场数值模拟[J]. 焊接学报, 2018, 39(2). DOI: 10.12073/j.hjxb.2018390036

异厚度铝钢电弧辅助激光对接熔钎焊温度场和应力应变场数值模拟

  • 摘要: 以厚度2 mm的 5A06铝合金板和1 mm热镀锌ST04Z钢对接熔钎焊试验为研究对象. 采用ANSYS有限元软件,选用高斯函数分布的热源模型模拟TIG电弧和三维锥体热源模型模拟激光的不重合组合热源. 基于所建立的不重合组合热源模型对温度场和应力场进行耦合分析,得到焊接过程中的温度场和应力应变分布. 结果表明,铝钢异厚度熔钎焊在焊缝及其附近区域中的纵向应力是拉应力,钢一侧远离焊缝产生较大的压应力,变形较大;铝合金一侧远离焊缝产生相应的变形,压应力相对较小,温度场、残余应力模拟结果与试验结果吻合较好,证明所建组合热源模型正确.
  • [1] 何康生, 曹 雄. 异种金属焊接[M]. 北京: 机械工业出版社, 1986.[2] J. van, Tienhoven, Pathiraj B, et al. Laser joining of steel-aluminum joints in T configuration[J]. Laser Materials Processing Conference, 2006, 107: 52-58.[3] Hitoshi Ozaki, Muneharu Kutsuna. Laser roll welding of dissimilar metal joint of zinc coated steel and aluminum alloy[J]. Laser Materials Processing Conference, 2006, 505: 298-302.[4] Huseyin Uzun, Claudio Dalle Donne, Alberto Argag-notto, et al. Friction stir welding of dissimilar Al 6013-T4 to X5CrNil8-10 stainless steel[J]. Materials and Design, 2005, 26: 41-46.[5] 樊 丁, 王 斌, 李春玲, 等. 铝/钢异种金属电弧辅助激光对接熔钎焊方法[J]. 焊接学报, 2015, 36(1): 15-18.Fan Ding, Wang Bin, Li Chunling, et al. The method of fusion-brazed butt joint between aluminum alloy and galvanizedsteel by arc-assisted laser[J]. Transactions of the China Welding Institution, 2015, 36(1): 15-18.[6] Eager T W, Tsai N. S. Temperature fields produced by traveling distributed heat sources[J]. Welding Journal,1983, 62(12): 346-355.[7] 武传松. 焊接热过程与熔池形态[M]. 北京: 机械工业出版社, 2008.[8] 田荣璋, 王祝堂. 铝合金及其加工手册[M]. 长沙:中南大学出版社, 2000.[9] 余淑荣, 熊进辉, 樊 丁, 等. 异厚度铝合金薄板激光拼焊温度场数值模拟[J]. 焊接学报, 2007, 28(5): 17-20.Yu Shurong, Xiong Jinhui, Fan Ding, et al. Numerical simulation on temperature field of laser welding aluminum alloy joints with different thickness[J]. Transactions of the China Welding Institution, 2007, 28(5): 17-20.[10] 余淑荣, 樊 丁, 熊进辉, 等. 异厚度铝合金薄板激光拼焊应力应变场数值模拟[J]. 焊接学报, 2008, 29(10): 25-28.Yu Shurong, Fan Ding, Xiong Jinhui, et al. Numerical simulation on stress-strain field of laser welding aluminum alloy joints with different thickness[J]. Transactions of the China Welding Institution, 2008, 29(10): 25-28.
计量
  • 文章访问数:  289
  • HTML全文浏览量:  3
  • PDF下载量:  2
  • 被引次数: 0
出版历程
  • 收稿日期:  2016-07-16
