Fe-Al金属间化合物对铝/钢钎焊接头力学性能的影响

张满1,张军1,蒋腾1,张临财2,杨大春1,侯宇1,吴静1

张满1,张军1,蒋腾1,张临财2,杨大春1,侯宇1,吴静1. Fe-Al金属间化合物对铝/钢钎焊接头力学性能的影响[J]. 焊接学报, 2018, 39(1): 61-64. DOI: 10.12073/j.hjxb.2018390014
引用本文: 张满1,张军1,蒋腾1,张临财2,杨大春1,侯宇1,吴静1. Fe-Al金属间化合物对铝/钢钎焊接头力学性能的影响[J]. 焊接学报, 2018, 39(1): 61-64. DOI: 10.12073/j.hjxb.2018390014
ZHANG Man1, ZHANG Jun1, JIANG Teng1, ZHANG Lincai2, YANG Dachun1, HOU Yu1, WU Jing1. Effect of Fe-Al intermetallic compound on mechanical property of aluminum/steel brazed joint[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2018, 39(1): 61-64. DOI: 10.12073/j.hjxb.2018390014
Citation: ZHANG Man1, ZHANG Jun1, JIANG Teng1, ZHANG Lincai2, YANG Dachun1, HOU Yu1, WU Jing1. Effect of Fe-Al intermetallic compound on mechanical property of aluminum/steel brazed joint[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2018, 39(1): 61-64. DOI: 10.12073/j.hjxb.2018390014

Fe-Al金属间化合物对铝/钢钎焊接头力学性能的影响

Effect of Fe-Al intermetallic compound on mechanical property of aluminum/steel brazed joint

  • 摘要: 研究了Zn-Al钎料钎焊铝/钢接头的铺展性能、钎焊接头力学性能与显微组织. 铺展试验结果表明,随着钎料中铝含量的增加,钎料在3003铝合金、Q235钢表面的铺展面积均增大,铝含量为15%(质量分数)时,在3003铝合金与Q235钢表面的铺展面积均达到最大值,继续增加铝含量,钎料铺展性能降低. 钎焊接头力学性能试验结果表明,随着钎料中铝含量的增加,钎焊接头强度提高,铝含量为12%(质量分数)时,88Zn-12Al钎料铝/钢钎焊接头强度最高,继续增加铝含量,钎焊接头强度降低. 综合考虑铺展性能及接头力学性能,88Zn-12Al钎料钎焊铝/钢接头性能最佳.
    Abstract: 3003 Al-alloy/Q235 steel dissimilar metals were brazed by Zn-Al filler metals with different Al contents. The spreading experiment results indicate that the spreadability improves with the increase of Al content in the filler metal on 3003 Al-alloy substrate and Q235 steel substrate. When Al content is 15%, the filler metal presents the best spreadability on 3003 Al-alloy substrate and Q235 steel substrate.However,the spreadability gradually deteriorates when Al content exceeds 15% in Zn-Al filler metal. In addition, the shear strength of the brazed joint was measured. The results show the joint strength improves with the increase of Al content in the filler metal. When Al content is 12%, the shear strength of the brazed joint gets highest. However,when Al content exceeds 12% in Zn-Al filler metal, the joint strength gradually decreases. The optimum content possessing best comprehensive properties is 88Zn-12Al filler metal.
  • [1] 雷 振, 秦国粱, 林尚扬, 等. 铝与钢异种金属焊接的研究与发展概况[J]. 焊接, 2006(4): 16-20.Lei Zhen, Qin Guoliang, Lin Shangyang,et al. Research and developments of dissimilar metals welding of aluminum and steel[J]. Welding & Joining, 2006(4): 16-20.[2] Song J L, Lin S B, Yang C L,et al. Effects of Si additions on intermetallic compound layer of aluminum-steel TIG welding-brazing joint[J]. Journal of Alloys & Compounds, 2009, 488(1): 217-222.[3] 石 玗, 李 杰, 黄健康, 等. Si和Zn对铝/钢异种金属熔钎焊接头界面组织的影响[J]. 中国有色金属学报, 2015, 25(1): 30-35.Shi Yu, Li Jie, Huang Jiankang,et al. Effects of Si and Zn on interface microstructures of aluminum/steel welding-brazing joint[J]. The Chinese Journal of Nonferrous Metals, 2015, 25(1): 30-35.[4] 崔佃忠, 芦 笙, 崔晴晴, 等. 焊接热输入对铝/镀锌钢CMT熔-钎焊接头组织与性能的影响[J]. 焊接学报, 2014, 35(9): 82-86.Cui Dianzhong, Lu Sheng, Cui Qingqing,et al. Effect of heat input on microstructure and mechanical properties of CMT welding-brazing joint between 5052 aluminum alloy and galvanized Q235 steel[J]. Transactions of the China Welding Institution, 2014, 35(9): 82-86.[5] 高 伟, 阎 启, 黄 坚. 钢/铝异种金属激光填丝熔钎焊对接接头组织与性能分析[J]. 中国激光, 2014, 41(6): (0603006-1)-(0603006-6).Gao Wei, Yan Qi, Huang Jian. Microstructure and mechanical property of laser wire fusion brazing welded butt joints of steel/aluminum dissimilar metal[J]. Chinese Journal of Lasers, 2014, 41(6): (0603006-1)-(0603006-6).[6] 宋建岭, 林三宝, 杨春利, 等. 特种钎剂辅助铝、 钢异种合金TIG熔-钎焊[J]. 焊接学报, 2010, 31(2): 45-48.Song Jianling, Lin Sanbao, Yang Chunli,et al. TIG welding-brazing of special flux assisted aluminum-steel dissimilar alloys[J]. Transactions of the China Welding Institution, 2010, 31(2): 45-48.[7] Xiong J T, Li J L, Qian J W,et al. High strength lap joint of aluminium and stainless steels fabricated by friction stir welding with cutting pin[J]. Science and Technology of Welding and Joining, 2012, 17(3): 196-201.[8] 王希靖, 张亚州, 张忠科, 等. 铝/钢无匙孔搅拌摩擦点焊焊接性分析[J]. 焊接学报, 2015, 36(1): 1-4.Wang Xijing, Zhang Yazhou, Zhang Zhongke,et al. Welding analyses of friction stir spot welding without key-hole between aluminum alloy and zinc-coated steel[J]. Transactions of the China Welding Institution, 2015, 36(1): 1-4.[9] 杨金龙, 薛松柏, 薛 鹏, 等. 铝/钢异种金属火焰钎焊接头组织和性能[J]. 焊接学报, 2015, 36(1): 63-66.Yang Jinlong, Xue Songbai, Xue Peng,et al. Microstructure and mechanical properties of aluminum/stainless steel brazed joint with torch brazing[J]. Transactions of the China Welding Institution, 2015, 36(1): 63-66.
