BNi68CrWB钎焊GH648/K42异种高温合金接头的组织与性能

杨敏旋, 马瑞, 刘春凤, 张杰, 孙妍

杨敏旋, 马瑞, 刘春凤, 张杰, 孙妍. BNi68CrWB钎焊GH648/K42异种高温合金接头的组织与性能[J]. 焊接学报, 2017, 38(4): 107-110. DOI: 10.12073/j.hjxb.20170425
引用本文: 杨敏旋, 马瑞, 刘春凤, 张杰, 孙妍. BNi68CrWB钎焊GH648/K42异种高温合金接头的组织与性能[J]. 焊接学报, 2017, 38(4): 107-110. DOI: 10.12073/j.hjxb.20170425
YANG Minxuan, MA Rui, LIU Chunfeng, ZHANG Jie, SUN Yan. Microstructure and properties of dissimilar high-temperature alloy joints (GH648/K42) brazed with BNi68CrWB filler metal[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(4): 107-110. DOI: 10.12073/j.hjxb.20170425
Citation: YANG Minxuan, MA Rui, LIU Chunfeng, ZHANG Jie, SUN Yan. Microstructure and properties of dissimilar high-temperature alloy joints (GH648/K42) brazed with BNi68CrWB filler metal[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(4): 107-110. DOI: 10.12073/j.hjxb.20170425

BNi68CrWB钎焊GH648/K42异种高温合金接头的组织与性能

Microstructure and properties of dissimilar high-temperature alloy joints (GH648/K42) brazed with BNi68CrWB filler metal

  • 摘要: 采用BNi68CrWB钎料粉末对K24和GH648异种高温合金进行钎焊连接,分析了钎焊温度、保温时间、装配间隙等钎焊工艺参数对接头组织和性能的影响规律.结果表明,在钎焊接头可观察到三个特征组织区域:共晶区、等温凝固区和扩散区;钎焊温度过高,接头内部W-Cr-Ni脆性相增多,接头性能下降.保温时间延长可以促进钎料与母材之间元素的扩散,有利于获得均匀的固溶体组织,接头强度提高,但时间过长,性能略有下降.钎焊间隙在0.05~0.15 mm范围,钎焊温度1 150℃,保温时间30 min所得接头性能较高,约600 MPa.
    Abstract: Dissimilar high-temperature alloys (K24 and GH648) were joined by using BNi68CrWB filler metal. Influence of brazing temperature, holding time and fit-up gap on microstructure and properties of joints were studied. It indicated that three typical microstructure areas were observed in the joints, e.g. eutectic area, isothermal solidification area and diffusion area. When brazing temperature was too high, the counts of W-Cr-Ni phase increased and then the mechanical properties decreased. Prolonging the holding time promoted the diffusion between brazing filler metal and matrix, and did benefit to obtain uniform solid-solution, and consequently the strength of joints increased. However, overlong holding caused the strength of joints decreased. The fit-up gap had little influence on the joints. Maximum strength value could be reached for the joints with fir-up gap of 0.05~0.10 mm brazed at 1 150 ℃ for 30 min.
  • [1] 张丽霞, 冯吉才. K24镍基合金钎焊接头热应力的有限元模拟[J]. 焊接学报, 2009, 30(9): 29-33. Zhang Lixia, Feng Jicai. Finite element simulation of thermal stress on brazed K24 nickel-based joint[J]. Transactions of the China Welding Institution, 2009, 30(9): 29-33.
    [2] 周轶群, 马惠萍. 鞠 泉, 等. 三种热处理制度对GH648合金组织和性能的影响[J]. 钢铁研究学报, 2007, 19(12): 45-48. Zhou Yiqun, Ma Huiping, Ju Quan, et al. Effects of three kinds of heat treatment on microstructure and mechanical properties of alloy GH648[J]. Journal of Iron and Steel Research, 2007, 19(12): 45-48.
    [3] 韩 峰, 王 斌, 孔庆吉, 等. K465合金及K465与GH3039异种合金的钎焊[J]. 焊接技术, 2011, 40(5): 26-29. Han Feng, Wang Bin, Kong Qingji, et al. Brazing of K465 to itself and to GH3039 alloy[J]. Welding Technology, 2011, 40(5): 26-29.
    [4] Liu J, Cao J, Lin X, et al. Microstructure and mechanical properties of diffusion bonded single crystal to polycrystalline Ni-based superalloys joint[J]. Materials & Design, 2013, 49: 622-626.
    [5] Guoge Z, Chandel R S, Pheow S H, et al. Effect of bonding temperature on the precipitation of δ phase in diffusion bonded inconel 718 joints[J]. Materials and Manufacturing Processes, 2006, 21(5): 453-457
    [6] 冯威琦, 张云丰, 陶 汪, 等. 高温合金/不锈钢异种材料 T 型接头激光穿透焊工艺研究[J]. 中国激光, 2013, 39(10): 40-46. Feng Weiqi, Zhang Yunfeng, Tao Wang, et al. Dissimilar metals combination of superalloy/stainless steel in T-shape by laser penetration welding[J]. Chinese Journal of Lasers, 2013, 39(10): 40-46.
    [7] Pouranvari M, Ekrami A, Kokabi A H. Microstructure development during transient liquid phase bonding of GTD-111 nickel-based superalloy[J]. Journal of Alloys and Compounds, 2008, 461(1): 641-647.
    [8] Wu X W, Chandel R S, Seow H P, et al. Wide gap brazing of stainless steel to nickel-based superalloy[J]. Journal of Materials Processing Technology, 2001, 113(1-3): 215-221.
    [9] 刘文慧, 郭绍庆, 叶 雷, 等. 采用BNi68CrWB钎料钎焊GH783的接头组织与性能[J]. 材料工程, 2010(6): 73-77. Liu Wenhui, Guo Shaoqing, Ye Lei, et al. Microstructure and property of the GH783 joint brazed with BNi68CrWB[J]. Journal of Materials Engineering, 2010(6): 73-77.
    [10] 张启运, 庄鸿寿. 钎焊手册[M]. 北京: 机械工业出版社, 2008.
