残余应力对钢轨焊接接头落锤试验性能的影响

朱志明, 范开果, 刘晗, 王永东

朱志明, 范开果, 刘晗, 王永东. 残余应力对钢轨焊接接头落锤试验性能的影响[J]. 焊接学报, 2017, 38(4): 55-58. DOI: 10.12073/j.hjxb.20170413
引用本文: 朱志明, 范开果, 刘晗, 王永东. 残余应力对钢轨焊接接头落锤试验性能的影响[J]. 焊接学报, 2017, 38(4): 55-58. DOI: 10.12073/j.hjxb.20170413
ZHU Zhiming, FAN Kaiguo, LIU Han, WANG Yongdong. Influence of residual stress on drop-weight test performance of rail welded joint[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(4): 55-58. DOI: 10.12073/j.hjxb.20170413
Citation: ZHU Zhiming, FAN Kaiguo, LIU Han, WANG Yongdong. Influence of residual stress on drop-weight test performance of rail welded joint[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(4): 55-58. DOI: 10.12073/j.hjxb.20170413

残余应力对钢轨焊接接头落锤试验性能的影响

基金项目: 国家自然科学基金资助项目(51075231);铁道部科技研究开发计划重大资助项目(2008G001-C);国家科技重大专项资助项目(2012ZX04012011)

Influence of residual stress on drop-weight test performance of rail welded joint

  • 摘要: 对钢轨窄间隙电弧焊接头热处理前后的残余应力分布进行了测量和比较,结合落锤试验结果和断口形貌,分析了焊接残余应力对钢轨接头落锤试验性能的影响.结果表明,热处理前,钢轨接头的轨腰和轨颚部位存在较大残余拉应力,在落锤冲击载荷作用下容易形成裂纹源,并沿轨腰向母材延伸、扩展、断裂;热处理后,钢轨接头的残余应力最大值下降1/2~2/3,抗冲击载荷能力显著提高,落锤试验时的钢轨接头沿焊缝中心或热影响区垂直断裂.钢轨接头存在较大残余应力时,在落锤冲击载荷作用下,容易在残余应力较大的部位产生裂纹,并加速扩展和断裂.
    Abstract: The residual stress distributions of rail joint welded by narrow-gap arc welding are measured before and after heat treatment and are compared, and then the influence of welding residual stress on the drop-weight test performance of rail welded joint is analyzed by combining the drop-weight test results with fracture appearance. The experimental results show that, there exists a comparative large residual tensile stress in the parts of web and jaw of rail welded joint before heat treatment, where the crack source forms easily under the action of shock load from drop weight, afterwards, the crack extends and propagates to base metal along the rail web, until the rail welded joint ruptures. The maximum value of residual stress in rail welded joint declines 1/2~2/3 after heat treatment, the resistant capability of rail welded joint to shock load is improved significantly, and the rail welded joint ruptures vertically along the weld center or heat affected zone during drop weight test. When there is larger residual stress within rail welded joint, the crack is easy to generate and accelerating propagate in the part existing larger residual stress under the action of shock load from drop weight, and resulting in final fracture.
  • [1] 潘建华. 钢轨内残余应力的危害及评价方法[J]. 铁道物资科学管理, 1997, 90(5): 33-34. Pan Jianhua. Harms of the residual stress in the rail and its evaluation methods[J]. Railway Materials Management, 1997, 90(5): 33-34.
    [2] 李 国, 杨贵全. 钢轨残余应力测试方法: 中国, CN103234666A[P]. 2013-08-07.
    [3] TB/T 2344-2012. 中华人民共和国铁道行业标准[S]. 北京: 中华人民共和国铁道部, 2012.
    [4] Tawfik D. Verification of residual stresses in flash-butt-weld rails using neutron diffraction[J]. Physica B, 2006, 385(11): 894-896.
    [5] Skyttebol A. Fatigue crack growth in a welded rail under the influence of residual stresses[J]. Engineering Fracture Mechanics, 2005, 72(2): 271-285.
    [6] Tawfik D. Experimental and numerical investigations: alleviating tensile residual stresses in flash-butt welds by localized rapid post-weld heat treatment[J]. Journal of Materials Processing Technology, 2008, 196(1): 279-291.
    [7] TB/T 1632.2~4-2005. 中华人民共和国铁道行业标准[S]. 北京: 中华人民共和国铁道部, 2005.
    [8] 董平禹, 杨来顺. 钢轨焊接中落锤试验的探讨[J]. 铁道建筑, 2005, (8): 67-68. Dong Pingyu, Yang Laishun. Discussion on drop hammer test used for inspection of rail welding quality[J]. Railway Engineering, 2005(8): 67-68.
    [9] 詹新伟, 周清跃. 钢轨轨底残余应力限定值的研究[J]. 铁道技术监督, 2000, 28(12): 9-11. Zhan Xinwei, Zhou Qingyue. Research of rail base residual stress limit value[J]. Railway Quality Control, 2000, 28(12): 9-11.
    [10] 刘正文. 高速无缝线路钢轨窄间隙自动化电弧焊接关键技术研究[D]. 北京: 清华大学, 2010.
    [11] 顾唯明. 用钻孔应变测量决定残余应力的标准方法—ASTM标准: E837—81[J]. 机械强度, 1986, 8(1): 40-43+81. Gu Weiming. The standard method of residual stress measurement by borehole—ASTM Standard: E837—81[J]. Journal of Mechanical Strength, 1986, 8(1): 40-43+81.
