WxC增强镍基合金等离子堆焊层组织与空蚀性能

刘舜尧, 张松, 崔文东, 张春华, 吴臣亮, 孙足来

刘舜尧, 张松, 崔文东, 张春华, 吴臣亮, 孙足来. WxC增强镍基合金等离子堆焊层组织与空蚀性能[J]. 焊接学报, 2017, 38(4): 39-42. DOI: 10.12073/j.hjxb.20170409
引用本文: 刘舜尧, 张松, 崔文东, 张春华, 吴臣亮, 孙足来. WxC增强镍基合金等离子堆焊层组织与空蚀性能[J]. 焊接学报, 2017, 38(4): 39-42. DOI: 10.12073/j.hjxb.20170409
LIU Shunyao, ZHANG Song, CUI Wendong, ZHANG Chunhua, WU Chenliang, SUN Zunlai. Microstructure and cavitation erosion performance of WxC reinforced Ni-base alloy composite coating by plasma transferred arc welding[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(4): 39-42. DOI: 10.12073/j.hjxb.20170409
Citation: LIU Shunyao, ZHANG Song, CUI Wendong, ZHANG Chunhua, WU Chenliang, SUN Zunlai. Microstructure and cavitation erosion performance of WxC reinforced Ni-base alloy composite coating by plasma transferred arc welding[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(4): 39-42. DOI: 10.12073/j.hjxb.20170409

WxC增强镍基合金等离子堆焊层组织与空蚀性能

基金项目: 国家重点研发计划资助项目(2016YFB1100204,2013ZX06002-002);国家自然科学基金资助项目(51271126);沈阳市科技计划资助项目(F16-032-0-00)

Microstructure and cavitation erosion performance of WxC reinforced Ni-base alloy composite coating by plasma transferred arc welding

  • 摘要: 采用等离子堆焊技术在316L不锈钢表面原位合成WxC增强镍基复合材料涂层,对涂层显微组织、相组成、硬质增强相的分布、显微硬度以及空蚀性能进行了分析.结果表明,Colmonoy 88合金等离子堆焊成形性良好,组织致密;堆焊层组织主要由γ-Ni固溶体,原位合成多角形、颗粒状WxC及少量的Cr7C3,Fe3W3C,CrB2相组成.堆焊过程中,熔池温度低于1 655 K时,原位生成WC和W2C,温度高于1 655 K时,原位生成的WC发生了分解.镍基合金堆焊层平均硬度可达1 619 HV,为基材的8倍以上,在3.5% NaCl溶液中镍基复合材料抗空蚀性能为316L不锈钢基材的5倍.
    Abstract: In-situ synthesis of WxC particle reinforced Ni-base composite coating was synthesized on 316L stainless steel by plasma transferred arc welding. Microstructure, phase constitent, the distribution of reinforced particle, microhardness and cavitation erosion property were investigated by using SEM, EDS, XRD, microhardness tester and ultrasonic vibrator, respectively. Results indicate that Colmonoy 88 coating exhibits a perfect plasma hardfacing tracks and the microstructure is dense. When the molten pool temperature is below 1 655 K, WC and W2C reinforced particles are in situ synthesized during the melting process. When the molten pool temperature is higher than 1 655 K, the in situ synthesized WC particles are dissolved. The phase constituents of the coating are mainly composed of γ-Ni solid solution, in-situ synthesized WxC particles and a small amount of Cr7C3, Fe3W3C and CrB2. The average microhardness of the coating is 1 619 HV, which is 8 times than that of the substrate. The cavitation erosion resistance of the Ni based composite material is 5 times than that of the substrate in 3.5% NaCl solution.
  • [1] Zhang S, Wu C L, Zhang C H, et al. Laser surface alloying of FeCoCrAlNi high-entropy alloy on 304 stainless steel to enhance corrosion and cavitation erosion resistance[J]. Optics & Laser Technology, 2016, 84: 23-31.
    [2] 张 松, 李 涛, 关 锰, 等. 316L不锈钢表面B-RE共渗层组织及磨蚀性能[J]. 材料热处理学报, 2016, 37(5): 180-185. Zhang Song, Li Tao, Guan Meng, et al. Microstructure and wear resistance of B-RE penetrating layer on 316L stainless steel[J]. Transactions of Materials and Heat Treatment, 2016, 37(5): 180-185.
    [3] 夏 铭, 李改叶, 王泽华, 等. NiCrWFeSiBCCo合金涂层的组织与耐空蚀性[J]. 焊接学报, 2016, 37(1): 111-114. Xia Ming, Li Gaiye, Wang Zehua, et al. Microstructure and cavitation erosion resistance of NiCrW-FeSiBCCo coatings [J]. Transactions of the China Welding Institution, 2016, 37(1): 111-114.
    [4] 杜宝帅, 李清明, 王新洪, 等. 激光熔覆原位自生TiC-VC颗粒增强Fe基金属陶瓷涂层[J]. 焊接学报, 2007, 28(4): 65-68. Du Baoshuai, Li Qingming, Wang Xinhong, et al. In situ synthesis of TiC-VC particles reinforced Fe-based metal matrix composite coating by laser cladding[J]. Transactions of the China Welding Institution, 2007, 28(4): 65-68.
    [5] 陈丽丽, 王振廷, 杨德云. 原位自生ZrC-ZrB2/铁基氩弧熔覆层[J]. 焊接学报, 2014, 35(12): 89-92. Chen Lili, Wang Zhenting, Yang Deyun.In-situ synthesis of Fe-based ZrC-ZrB2 composite coating produced by GTAW [J]. Transactions of the China Welding Institution, 2014, 35(12): 89-92.
    [6] 傅 卫, 王惜宝, 陈国喜. 镍基WC等离子弧熔敷层的组织和高温磨损性能[J]. 焊接学报, 2009, 30(5): 65-67. Fu Wei, Wang Xibao, Chen Guoxi.Microstructure and high temperature abrasion resistance of Ni-based WC composite layer deposited by plasma arc[J]. Transactions of the China Welding Institution, 2009, 30(5): 65-67.
    [7] ASTM Standard. A G32-92, Standard method of vibratory cavitation erosion test[S]. USA, American Society for Testing and Material, 1994.
    [8] 郝士明, 蒋 敏, 李洪晓. 材料热力学(第二版)[M]. 北京: 化学工业出版社, 2010.
    [9] 叶大伦. 实用无机物热力学数据手册(第二版)[M]. 北京: 冶金工业出版社, 2002.
    [10] Sudha C, Shankar P, Rao R V S, et al. Microchemical and microstructural studies in a PTA weld overlay of Ni-Cr-Si-B alloy on AISI 304L stainless steel[J]. Surface & Coatings Technology, 2008, 202(10): 2103-2112.
    [11] 左亚天. 挤压辊修复用耐磨堆焊合金与45钢母材的结合强度研究[D]. 吉林: 吉林大学, 2013.
